TRANS-200 VME存储公告#8400-816b说明Acromag的XVME-9060扩展模块安装在XVME-6700和XVME-6510单板计算机的上PMC站点中。此扩展模块允许额外的前端I/O扩展，以及可选的存储空间。主要功能和优点前面板上的标准I/O连接器：USB（2）以太网RS-232串行*还接受2 mSATA模块用于板载存储*使用随附的转换电缆订购信息XBRD-9060-LF扩展模块，不包括mSATA驱动器。与XVME SBC无缝集成◆ 提供额外的前端I/O◆ 接受mSATA驱动器XBRD-9060扩展模块所有商标均为其各自所有者的财产。版权所有©Acromag，Inc.2019。数据如有更改，恕不另行通知。2019年9月在美国印刷。电话：248-295-0310solutions@acromag.comwww.acromag.com 30765 Wixom Rd，Wixom，MI 48393 USA 844-878-2352solutions@acromag.comwww.acromag.com 30765 Wixom Rd，Wixom，MI 48393 USA VME后部转换模块公告编号8400-817d描述型号：XVME-9640-1-LF型号：XVME-9640-2-LF acromag的XVME-96-40后部转换模块为XVME-6510和XVME-6700 VME单板计算机添加了各种I/O连接器。XVME-9640模块可以直接安装在XVME-6510/XVME-6700后面的后插槽中，以便轻松访问XVME 6510/XVMSE7700的P2和可选的P0连接器上的所有可用I/O，并允许添加mSATA SSD模块用于存储。XVME-9640包含两个mSATA插槽，允许添加两个SSD驱动器，同时仍保留在单个VME插槽中。使用QM87 PCH的软件RAID功能，如果需要冗余或额外速度，这些驱动器甚至可以设置为RAID0/1阵列。警告：mSATA需要XVME-6500/XVME-6700和XVME-9640上的P0才能正常工作。注意：标准XVME-9640不能用于使用VITA 31.1以太网的背板。有一个自定义构建选项可用于隔离VITA 31.1系统中使用的以太网线路。请向工厂咨询此选项。XVME-9640的前面板上提供I/O：▪ 前面板的可选RJ Point 5连接器上有两个可选千兆以太网端口▪ 一个VGA端口▪ 一个DVI-D端口▪ 两个USB 2.0端口▪ P2 I/O的PMC/XMC I/O可通过XVME-9640上的内部连接器获得：▪ 立体声音频线路输入和线路输出▪ 一个软件可选RS-232/RS-485串行端口▪ 来自RJ0连接器的PMC/XMC I/O可通过两个可选的高速Samtec连接器提供。主要功能和优点可通过标准连接器在板上提供I/O：VGA USB（2）DVI-D来自P2的PMC I/O可通过接头提供：音频RS-232/422/485串行（1）另外提供*：以太网（2）通过RJ Point 5连接器*来自P0的PMC I/O**需要P0连接器订购信息XVME-9640-1-LF带P0的后过渡模块XVME-9640-2-LF后过渡模块不带P0
TRANS-200 VME Storage Bulletin #8400-816b Description Acromag’s XVME-9060 expansion module installs in the upper PMC site of the XVME-6700 and XVME-6510 single board computers. This expansion module allows for additional front I/O expansion, as well as optional storage space. Key Features & Benefits Standard I/O connectors on the front panel: USB (2) Ethernet RS-232 Serial* Also accepts 2 mSATA modules for onboard storage. *by use of included conversion cable Ordering Information XBRD-9060-LF Expansion module, no mSATA drives included. Seamless integration with XVME SBC ◆ Provides additional front I/O ◆ Accepts mSATA drives XBRD-9060 Expansion Module All trademarks are property of their respective owners. Copyright © Acromag, Inc. 2019. Data subject to change without notice. Printed in USA 9/2019. Tel 248-295-0310 solutions@acromag.com www.acromag.com 30765 Wixom Rd, Wixom, MI 48393 USA 844-878-2352 solutions@acromag.com www.acromag.com 30765 Wixom Rd, Wixom, MI 48393 USA VME Rear Transition Modules Bulletin #8400-817d Description Models: XVME-9640-1-LF Models: XVME-9640-2-LF Acromag’s XVME-9640 rear transition module adds a variety of I/O connectors to the XVME-6510 and XVME-6700 VME single board computers. The XVME-9640 module may be installed into the rear slot directly behind the XVME-6510/ XVME-6700 to easily access all of the available I/O on the XVME 6510 / XVME7700’s P2, and optionally P0 connectors, as well as allow mSATA SSD modules to be added for storage. The XVME-9640 contains two mSATA sockets that allow two SSD drives to be added while still remaining within a single VME slot. Using the software RAID functionality of the QM87 PCH, these drives can even be setup as a RAID0/1 array if redundancy or extra speed is desired. WARNING: mSATA requires P0 on both the XVME-6500 / XVME-6700 and XVME-9640 for proper operation. Note: The standard XVME-9640 cannot be used in a backplane that uses VITA 31.1 Ethernet. A custom build option is available that isolates the Ethernet lines for use in a VITA 31.1 system. Please consult factory for this option. I/O is available on the front panel of the XVME-9640: ▪ Two optional Gigabit Ethernet ports are available on the front panel’s optional RJ Point 5 connector ▪ One VGA port ▪ One DVI-D port ▪ Two USB 2.0 ports ▪ PMC/XMC I/O from P2 I/O is available via internal connectors on the XVME-9640: ▪ Stereo Audio Line-In & Line-Out ▪ One software-selectable RS-232/RS-485 serial port ▪ PMC/XMC I/O from RJ0 connector is available via two optional high-speed Samtec connectors Key Features & Benefits I/O available on the board via standard connectors: VGA USB (2) DVI-D PMC I/O from P2 Available via headers: Audio RS-232/422/485 Serial (1) Additionally available*: Ethernet (2) thru RJ Point 5 connector* PMC I/O from P0* *requires P0 connector Ordering Information XVME-9640-1-LF Rear Transition Module with P0 XVME-9640-2-LF Rear Transition Module without P0
