IS200ICIAH1ABB工控模块,备件模块
每个布尔函数96 MHz，80486DX4微处理器支持IC66（可以是IC660或IC661）和IC697 I/O，由MS-DOS软件产品编程，或基于Windows的软件产品，通过以太网TCP/IP或通过SNP端口在Windows 95或Windows NT上运行可配置数据和程序存储器电池支持的日历时钟三位操作模式开关密码控制访问远程编程器钥匙开关内存保护七状态LED软件配置（无DIP开关或跳线）正面参考信息门内系统可升级固件功能CPX 928是一个单槽PLC CPU，通过MS-DOS或基于Windows的编程软件进行编程和配置，以执行机器、过程和材料处理系统的实时控制。它使用VME C.1标准格式通过机架式背板与I/O和智能选件模块通信。支持的选件模块包括LAN接口模块、可编程协处理器、字母数字显示协处理器、用于IC660/661 I/O产品的总线控制器、通信模块、I/O链路接口以及所有IC697系列离散和模拟I/O模块。MEM PROTECT a45724 Y R E B A T模块IC697CPX928标签44A726758–153R01串行端口3仅在插槽1中使用此模块CPX 928关闭顶部远程编程器OK RUN EN ON=OK，已启用，受保护的前部运行，输出已启用运行，输出禁用停止钥匙位置模块功能蓄电池接头在卸下旧蓄电池之前安装新蓄电池。USEIC697ACC701 MEMORY PROTECT RS-485兼容96 MHz 32位中央处理单元P1 P2 P3串行端口2 RS-485兼容工厂测试串行端口1 RS-232 OK RUN EN中央处理器单元MEM PROTECT P1 P2 P3 MS-DOS、Windows、Windows 95和Windows NT是Microsoft Corporation的注册商标。96 MHz、32位、浮点、6 Mbyte（中等）内存中央处理器GFK-1433E 2个PLC CPU 1999年11月系列90-70可编程控制器数据表手册GFK-0600F 21-2 a45677 PLC系统配置示例用户RAM内存CPX928具有内置存储板，带有6 Mbytes电池支持的CMOS RAM内存，用于存储用户数据（程序、配置和寄存器数据）。用户闪存CPX928具有256K内置非易失性闪存，用于存储用户数据（程序、配置和寄存器数据）。此闪存的使用是可选的。闪存中的固件存储此CPU使用闪存存储操作系统固件。这允许在不拆卸模块或更换EPROM的情况下更新固件。通过将PC兼容计算机连接到模块的串行端口并运行固件升级套件中包含的软件来更新操作系统固件。该模块的操作、保护和模块状态操作可通过三位运行/停止开关控制，或通过连接的编程器和编程软件远程控制。程序和配置数据可以通过软件密码或通过内存保护钥匙开关手动锁定。当钥匙处于保护位置时，程序和配置数据只能由仅并联的编程器（与总线变送器模块）更改。CPU的状态由模块前面的七个绿色LED指示。工作温度CPX 928需要强制空气冷却，以便在高于50 C（122 F）的环境温度下正常工作。容量为70 CFM（包括过滤器）的风扇应位于包含CPU的机架的插槽1下方。可以订购风扇组件（IC697ACC 721、IC697ACC724和IC697ACC744），以便直接安装在IC697机架上。参考适用的可编程
per boolean function 96 MHz, 80486DX4 microprocessor Supports IC66 (can be IC660 or IC661) and IC697 I/O Programmed by MS-DOS software products, or Windows based software products running on Windows 95 or Windows NT over Ethernet TCP/IP or through an SNP port Configurable data and program memory Battery-backed calendar clock Three position operation mode switch Password controlled access Remote programmer keyswitch memory protection Seven status LEDs Software configuration (No DIP switches or jumpers) Reference information inside front door In-system upgradable firmware Functions The CPX 928 is a single slot PLC CPU that is programmed and configured by MS-DOS or Windows based programming software to perform real time control of machines, processes and material handling systems. It communicates with I/O and smart option modules over the rack-mounted backplane using the VME C.1 Standard format. Supported option modules include LAN Interface modules, Programmable Coprocessor, Alphanumeric Display Coprocessor, Bus Controller for IC660/661 I/O products, Communications modules, I/O Link Interface, and all of the IC697 family of discrete and analog I/O modules. MEM PROTECT a45724 Y R E B A T T MODULE IC697CPX928 LABEL 44A726758–153R01 SERIAL PORT 3 USE THIS MODULE IN SLOT 1 ONLY CPX 928 OFF ON TOP REMOTE PROGRAMMER OK RUN EN ON = OK, ENABLED, PROTECTED FRONT RUN WITH OUTPUTS ENABLED RUN WITH OUTPUTS DISABLED STOP KEY POSITION MODULE FUNCTION BATTERY CONNECTORS INSTALL NEW BATTERY BEFORE UNPLUGGING OLD BATTERY. USEIC697ACC701 MEMORY PROTECT RS-485 COMPATIBLE 96 MHz 32 BIT CENTRAL PROCESSING UNIT P1 P2 P3 SERIAL PORT 2 RS-485 COMPATIBLE FACTORY TEST SERIAL PORT 1 RS-232 OK RUN EN CENTRAL PROCESSOR UNIT MEM PROTECT P1 P2 P3 MS-DOS, Windows, Windows 95, and Windows NT are registered trademarks of Microsoft Corporation. 96 MHz, 32-Bit, Floating Point, 6 Mbyte (Medium) Memory Central Processing Unit GFK-1433E 2 PLC CPUs November 1999 Series 90-70 Programmable Controller Data Sheet Manual GFK-0600F 21-2 a45677 PLC System Configuration Example User RAM Memory The CPX928 has a built-in memory board with 6 Mbytes of battery-backed CMOS RAM memory for user data (program, configuration, and register data) storage. User Flash Memory The CPX928 has 256K of built-in, non-volatile flash memory for user data (program, configuraton, and register data) storage. Use of this flash memory is optional. Firmware Storage in Flash Memory This CPU uses flash memory for storing the operating system firmware.This allows firmware to be updated without disassembling the module or replacing EPROMs. The operating system firmware is updated by connecting a PC compatible computer to the module’s serial port and running the software included with the firmware upgrade kit. Operation, Protection, and Module Status Operation of this module can be controlled by the three-position RUN/STOP switch or remotely by an attached programmer and programming software. Program and configuration data can be locked through software passwords or manually by the memory protect keyswitch. When the key is in the protected position, program and configuration data can only be changed by a programmer connected parallel only (to the Bus Transmitter module). The status of a CPU is indicated by the seven green LEDs on the front of the module. Operating Temperature The CPX 928 requires forced air cooling for proper operation in ambient temperatures greater than 50C (122F). A fan capable of 70 CFM (including filters) should be located beneath slot 1 of the rack containing the CPU. Fan assemblies (IC697ACC 721, IC697ACC724, and IC697ACC744) can be ordered for direct mounting on the IC697 rack. Refer to the applicable Programmable
