IS200HFPAG2ADC/IS200HFPAG1ADC工控模块卡件
正常模式电压5 V DC最大更新率60 Hz：每个通道大约60毫秒50 Hz：每个信道大约70毫秒GFK-1504N第14章温度传感模块14-13 14 IC200ALG630模拟输入，16位热电偶，7通道可配置参数热电偶输入模块的默认参数可用于许多应用。当模块安装在VersaMax PLC系统或由2.0版或更高版本的NIU控制的工作站中时，可以对其进行软件配置。模块参数描述默认选择模拟输入数据长度模块模拟输入数据的字长。7 1至7模拟输入数据参考模块模拟输入数据的起始偏移。用户可选择的模拟输出数据长度模块可选参考补偿数据的字长。模块可选参考补偿数据的0 0至7模拟输出数据参考起始偏移。用户可选线路频率指定线路频率。模块使用此数据控制采样率。60 Hz 50 Hz，60 Hz抑制开放式热电偶确定模块是否会抑制输入数据上的开放式热电偶诊断。No Yes，No Channel Active指定通道是否应返回数据和报警。如果通道为“非活动”，则仍为其分配空间。活动-非活动（关闭）-活动（打开）工程单位指定模块如何报告输入值1/10°C毫伏、1/10°C、1/10°F热电偶类型每个通道上存在的热电偶类型。J无，J，K，T，S，R范围仅限毫伏输入，每个通道的范围以毫伏为单位。625 19.53, 39.06, 78.125, 156.25, 312.5, 625. R J类型指定通道将如何或是否执行冷结补偿。本地本地、远程、固定、无报警低通道的低报警限值，单位为工程单位2000–32768至+32767警报上限通道的警报上限，单位为工程单位。8000–32768至+32767参考结值如果选择了RJ类型“固定”，则以工程单位指定参考值。250–32768至+32767校正系数指定在配置了以度为单位的转换类型时，要添加到补偿和线性化输入值的可选量。0–32768至+32767通道默认输入指定错误（包括开路错误）时返回的模拟输入。0+32767冷接点默认值250+32767 14-14 VersaMax模块、电源和载波用户手册GFK-1504N 14 IC200ALG630模拟输入、16位热电偶、7信道模块功能信道激活每个信道可以配置为激活或非激活。如果某个通道处于非活动状态，则该通道的过滤、缩放、校准和报警检查将被省略，该通道的值将返回0。Normal mode voltage 5 V DC maximum Update rate 60 Hz: approximately 60 milliseconds per channel 50 Hz: approximately 70 milliseconds per channel GFK-1504N Chapter 14 Temperature Sensing Modules 14-13 14 IC200ALG630 Analog Input, 16 Bit Thermocouple, 7 Channels Configurable Parameters The default parameters of the Thermocouple Input module can be used in many applications. The module can be software-configured when it is installed in a VersaMax PLC system, or an Station controlled by a NIU that is version 2.0 or above. Module Parameter Description Default Choices Analog Input Data Length Word length of the module’s analog input data. 7 1 to 7 Analog Input Data Reference Starting offset for the module’s analog input data. user selectable Analog Output Data Length Word length of the module’s optional Reference Compensation data. 0 0 to 7 Analog Output Data Reference Starting offset for the module’s optional Reference Compensation data. user selectable Line Frequency Specifies the line frequency. The module uses this data to control the sampling rate. 60 Hz 50 Hz, 60 Hz Suppress Open Thermocouple Determines whether or not the module will suppress Open Thermocouple diagnostics on the input data. No Yes, No Channel Active Specifies if the channel should return data and alarms. If a channel is “inactive” space is still allocated for it. Active Inactive (off) Active (on) Engineering Units Specifies how the module will report input values 1/10 °C Millivolts, 1/10 °C, 1/10 ° F Thermocouple Type The type of thermocouple present on each channel. J None, J, K, T, S, R Range For millivolt inputs only, the range for each channel in millivolts. 625 19.53, 39.06, 78.125, 156.25, 312.5, 625. R J Type Specifies how or whether the channel will perform Cold Junction compensation. Local Local, Remote, Fixed, None Alarm Low The low alarm limit for the channel, in engineering units. –2000 –32,768 to +32,767 Alarm High The high alarm limit for the channel, in engineering units. 8000 –32,768 to +32,767 Reference Junction Value Specifies a reference value, in engineering units, if the RJ Type, Fixed, is selected. 250 –32,768 to +32,767 Correction Factor Specifies optional amount to be added to compensated and linearized input value when a Conversion Type in degrees has been configured. 0 –32,768 to +32,767 Channel Default Input Specifies analog input returned upon error (including open circuit errors). 0 +32,767 Cold Junction Default 250 +32,767 14-14 VersaMax Modules, Power Supplies and Carriers User's Manual GFK-1504N 14 IC200ALG630 Analog Input, 16 Bit Thermocouple, 7 Channels Module Features Channel Active Each channel can be configured as either active or inactive. If a channel is inactive, the filtering, scaling, calibration, and alarm checks are omitted for that channel, and a value of 0 is returned for the channel.
