IS200ICBDH1BAA DCS工控模块备件
4通道VersaMax模拟输入RTD模块（IC200ALG620）是一个智能模块，可接受来自多达4个RTD输入设备的输入信号，并提供16位分辨率的输入数据。1234567 831 IC200ALG620模拟输入16BIT RTD 4CH正常此模块无需外部电源。RTD的励磁电流由模块提供，该模块自动将励磁电流与每个配置的RTD类型相匹配。RTD模拟输入模块接受4个独立的3线和/或4线铂、镍、镍/铁或铜RTD的输入。模块功能包括：可选择的电阻测量值，单位为Ω, 十分之一°F或十分之一°C单个通道配置可选电阻范围：0–500Ω 和0-3000Ω 电阻或温度（摄氏度或华氏度）可选择RTD输入报告高/低、低量程/超量程、断线和输入短路报警。基于50 Hz和60 Hz线路频率的两种数据采集速率可配置信道激活GFK-1504N第14章温度传感模块14-3 14 IC200ALG620模拟输入、16位RTD、，4通道LED指示灯正常LED指示模块状态：亮起绿色指示正常运行闪烁绿色指示启动模式或更新闪烁琥珀色指示自诊断错误关闭指示无3.3V背板电源诊断模块报告超出/低于范围、导线开路、非易失性内存存储、高/低报警以及向故障表输入短诊断。校准模块在通电时自动执行A/D校准。然后定期重复自动校准，以补偿环境温度的变化。主机接口RTD输入模块提供4个字的模拟输入数据。兼容性此模块兼容：▪ VersaMax PLC CPU版本IC200CPU001-BC固件版本1.20或更高版本▪ Genius NIU版本IC200GBI001-AB固件版本1.10或更高版本▪ Profibus NIU版本IC200PBI001-BB固件版本1.10或更高版本▪ DeviceNet NIU版本IC200DBI001-AA固件版本1.10或更高版本▪ 以太网NIU版本IC200EBI001-AA固件版本1.00或更高版本14-4 VersaMax模块、电源和载波用户手册GFK-1504N 14 IC200ALG620模拟输入，16位RTD，4信道模块规格模块特性信道4个3线和/或4线RTD模块ID隔离：用户输入到逻辑（光学）和机架接地组到组信道到信道250VAC连续；1500VAC持续1分钟不适用50VDC LED指示灯正常LED指示灯：绿色表示存在背板电源。琥珀色表示模块故障。背板电流消耗5V输出：最大125mA。3.3V输出：125mA外部电源无热降额无配置参数请参阅配置表诊断超出/低于范围、开路、非易失性存储器存储故障、接线故障、高/低报警、输入短路更新率60 Hz：每个通道约210毫秒50 Hz：每个信道约230毫秒正常模式抑制60dB，50/60 Hz，100%量程50/60Hz时共模抑制120 dB，100欧姆不平衡共模电压3V最大正常模式电压5V最大数字分辨率15位加号工作
4 Channels The VersaMax Analog Input RTD Module (IC200ALG620) is an intelligent module that accepts input signals from up to 4 RTD input devices and provides input data with 16 bits of resolution. 1234567 831 IC200ALG620 ANALOG INPUT 16BIT RTD 4CH OK No external power supply is required for this module. The excitation current for the RTDs is provided by the module, which automatically matches the excitation current to each configured RTD type. The RTD Analog Input Module accepts inputs from 4 independent 3-wire and/or 4-wire platinum, nickel, nickel/iron, or copper RTDs. Module features include: Selectable resistance measurements in tenths of Ω, tenths of ° Fahrenheit, or tenths of °Celsius Individual channel configuration Selectable resistance ranges: 0 – 500 Ω and 0 – 3000 Ω Selectable RTD input as resistance or temperature (Celsius or Fahrenheit) Reports high/low, underrange/overrange, open wire and input short alarms. Two data acquisition rates based on 50 Hz and 60 Hz line frequencies Configurable channel activation GFK-1504N Chapter 14 Temperature Sensing Modules 14-3 14 IC200ALG620 Analog Input, 16 Bit RTD, 4 Channels LED Indicators The OK LED indicates module status: On green indicates normal operation Flashing green indicates boot mode or update Flashing amber indicates self-diagnostic error Off indicates no 3.3V backplane power Diagnostics The module reports over/under range, open wire, non-volatile memory storage, high/low alarm, and input short diagnostics to the Fault Table. Calibration The module automatically performs A/D calibration at powerup. Automatic calibration is then repeated periodically to compensate for changes in the ambient temperature. Host Interface The RTD Input module provides 4 words of analog input data. Compatibility This module is compatible with: ▪ VersaMax PLC CPU version IC200CPU001-BC firmware version 1.20 or later ▪ Genius NIU version IC200GBI001-AB Firmware version 1.10 or later ▪ Profibus NIU version IC200PBI001-BB firmware version 1.10 or later ▪ DeviceNet NIU version IC200DBI001-AA Firmware version 1.10 or later ▪ Ethernet NIU version IC200EBI001-AA Firmware version 1.00 or later 14-4 VersaMax Modules, Power Supplies and Carriers User's Manual GFK-1504N 14 IC200ALG620 Analog Input, 16 Bit RTD, 4 Channels Module Specifications Module Characteristics Channels Four 3-wire and/or 4-wire RTDs Module ID Isolation: User input to logic (optical) and to frame ground Group to group Channel to channel 250VAC continuous; 1500VAC for 1 minute Not applicable 50VDC LED indicators OK LED: green indicates backplane power is present. Amber indicates module fault. Backplane current consumption 5V output: 125mA maximum. 3.3V output: 125mA External power supply None Thermal derating None Configuration parameters See configuration table Diagnostics Over/under range, open wire, non-volatile memory storage fault, wiring fault, high/low alarm, input short Update rate 60 Hz: approximately 210 milliseconds per channel 50 Hz: approximately 230 milliseconds per channel Normal mode rejection 60dB, at 50/60 Hz, 100% span Common mode rejection 120 dB at 50/60Hz, 100 ohm imbalance Common mode voltage 3V maximum Normal mode voltage 5V maximum Digital Resolution 15 bits plus sign Operating
