当以这种形式连接插入式断路器或熔断器底座时，通常不需要额外的跳线。现场接线连接至端子A1-A16（或B1-B16，如适用）。辅助端子通常未连接。GFK-1504N第2章安装2-33 2模块IC200MDL143的接线图示例下图提供了与VersaMax模块一起使用时IC200CHS101或121的现场接线示例。J1 J2 I1 I1 J1 J2 IC200CHS101 IC200CHS121 2-34 VersaMax模块、电源和托架用户手册GFK-1504N 2安装继电器式插入端子IC200CHS111和IC200CHS112继电器式插入终端（IC200CHS 111和IC200 CHS112）均提供能够切换高电流输出（最高8A）的干触点。对于继电器式插入端子，继电器线圈的操作电源必须由外部24 V直流电源提供。该电源必须同时提供给主底座（IC200CHS111）和扩展底座（IC200 CHS112）。该外部电源在端子A17和A18（B17和B18用于扩展底座）处连接。此电源连接仅用于继电器线圈。用户负载必须由外部电源供电。标记为A1-A16的组件对应于Q1-Q16。标记为B1-B16的部件对应于Q17-Q32。每个点与3个端子连接相关联：NO（常开）、C（公共）和NC（常闭）。负载可连接在C和NO、C和NC之间，或两者之间。J1 J2 A16 A15 A14 A13 A12 A11 A10 A9 A8 A7 A6 A5 A4 A3 A2 A1 A16 A14 A14 A12 A10 A10 A8 A8 A6 A5 A3 A1 A18 A17+-24VDC A1 V Q1 NO C NC继电器型插入式端子，端子接线每个端子可容纳：一个实心（横截面0.2至4.0mm2）或绞合（横截面0.2-2.5mm2），AWG#12至AWG#24。在同一位置插入两根电线时，电线必须具有相同的尺寸和类型（实心或绞合），如下所示：刚性或柔性电线：横截面0.2至1.5mm2。带套圈、无塑料套管的绞合线：横截面0.25至0.75mm2带双套圈、带塑料套管的多股绞合线端子螺钉的建议扭矩为0.5至0.6 Nm。GFK-1504N第2章安装2-35 2辅助端子接线辅助端子可用于提供额外的现场接线连接（如果需要）。它们可以连接到终端式载体或插入终端。辅助端子装置可提供18个盒型端子，如下图所示，或18个弹簧型端子或12个屏障型端子。I类2区Ex nA IIC T4 OC Ta Ex nV II T4 Demko端子型载体辅助端子插入端子辅助端子端子电气连接在一起。载波或插入端子与辅助端子之间没有电气连接；必须提供任何必要的电气参考。可以连接多个辅助端子，以提供高密度模块或2线、3线和4线现场设备可能需要的附加接线端子。现场设备图16点模块32点模块盒、弹簧或连接器载体屏障型载体盒、弹簧和连接器载体屏障式
When connecting the Interposing Disconnect or Fuse base in this format, additional jumpers are usually not needed. Field wiring is connected to terminals A1-A16 (or B1-B16 where appropriate). The auxiliary terminals are not generally connected. GFK-1504N Chapter 2 Installation 2-33 2 Example Wiring Diagram for Module IC200MDL143 The following figures provide example field wiring for IC200CHS101 or 121 when used with VersaMax modules without grouped . J1 J2 I1 I1 J1 J2 IC200CHS101 IC200CHS121 2-34 VersaMax Modules, Power Supplies and CarriersUser Manual GFK-1504N 2 Installing Relay-Style Interposing Terminals IC200CHS111 and IC200CHS112 The Relay-Style Interposing Terminals (IC200CHS111 and IC200CHS112) each provide dry contacts capable of switching high current outputs (up to 8A). For the Relay Style Interposing Terminals, power for operation of the relay coils must be provided by an external 24 V DC power supply. This power must be provided to both the main base (IC200CHS111) and the expansion base (IC200CHS112). Connection of this external power supply is made at the terminals A17 and A18 (B17 and B18 for the expansion base). This power connection is for the relay coils only. User loads must be powered by an external source. Components labeled A1-A16 correspond to Q1-Q16. Components labeled B1-B16 correspond to Q17-Q32. Each point is associated with 3 terminal connections: NO (Normally Open), C (Common), and NC (Normally Closed). Loads may be connected between C and NO, C and NC, or both. J1 J2 A16 A15 A14 A13 A12 A11 A10 A9 A8 A7 A6 A5 A4 A3 A2 A1 A16 A15 A14 A13 A12 A11 A10 A9 A8 A7 A6 A5 A4 A3 A2 A1 A18 A17 + - 24VDC A1 V Q1 NO C NC Relay-Style Interposing Terminals, Terminal Wiring Each terminal accommodates: One solid (0.2 to 4.0mm2 cross section) or stranded (0.2 to 2.5mm2 cross section), AWG #12 to AWG #24. When inserting two wires in the same position, the wires must be the same size and type (solid or stranded), as specified below: Rigid or flexible wires: 0.2 to 1.5mm2 cross section. Stranded wires with ferrules, no plastic sleeve: 0.25 to 0.75mm2 cross section Stranded wires with twin ferrule, with plastic sleeve Recommended torque for the terminal screws is 0.5 to 0.6 Nm. GFK-1504N Chapter 2 Installation 2-35 2 Wiring for Auxiliary Terminals Auxiliary Terminals can be used to provide extra field wiring connections if needed. They can be attached to either a terminal-style carrier or to Interposing Terminals. Auxiliary Terminals units are available with 18 boxstyle terminals as displayed in the following figures or with 18 spring-style terminals or 12 barrier-style terminals. CLASS I ZONE 2 Ex nA IIC T4 OC Ta Ex nV II T4 Demko Terminal-Style Carrier Auxiliary Terminals Interposing Terminals Auxiliary Terminals The terminals are electrically tied together. There is no electrical connection from the Carrier or Interposing Terminals to the Auxiliary Terminals; any necessary electrical reference must be provided. Multiple Auxiliary Terminals can be connected to provide the additional wiring terminals that may be needed for high-density modules, or for 2-, 3-, and 4-wire field devices. Field Device Diagram 16 Point Module 32 Point Module Box-, Spring-, or Connector Carrier Barrier-Style Carrier Box-, Spring-, or Connector Carrier Barrier-Style
