IS200RAPAG1BAA控制器模块
模块可以安装在载体上或在不干扰现场布线的情况下拆除。有三种基本运营商类型：终端型运营商。模块平行于DIN导轨安装。紧凑型终端式载体。模块垂直于DIN导轨安装。连接器式托架。模块垂直于DIN导轨安装。这些载波通常用于插入终端。插入终端的一种类型如下所示：；其他类型也可用。有关VersaMax Carriers的信息，请参阅第4章。端子式载体有36个单独的端子，用于直接连接现场接线。辅助接线板可用于需要额外接线端子的应用。第5章介绍了VersaMax插入端子和辅助端子条。端子型载体紧凑型端子型载体连接器型载体和插入端子辅助端子条1-14 VersaMax模块，电源和托架用户手册GFK-1504N 1可用的托架和端子条端子式托架障碍式端子托架IC200CHS001盒式端子托架IC2000CHS002弹簧式端子托架IC 200CHS005紧凑型端子式托架紧凑型盒式托架IC200CH022紧凑型弹簧式托架IC200HS025连接器式托架连接器式托架IC200CHS003插入式端子，用于连接器式载体屏障式插入式端子IC200CHS011盒式插入式终端IC200CHS012热电偶式插入式接线端IC200CHS014弹簧式插入式接头IC200CHS015断开型插入式接线端子、主底座断开型插塞式接线端子，扩展底座IC200CHS101 IC200CHS102继电器式插入端子、主底座继电器式插入接线端子、扩展底座IC200 CHS111 IC200CHS112保险丝式插入端子，主底座保险丝式插入接线端、扩展底座IC 200CHS121 IC200CHS122电缆，用于连接器式托架2连接器，0.5m，无屏蔽IC200CBL105 2连接器，1.0m，无屏蔽IC200CBL110 2连接器，2.0m，无屏蔽IC200 CBL120 1连接器，3.0m，无屏蔽IC200CBL230辅助接线板，用于端子式载体和插入式端子屏障式辅助接线板IC200TBM001盒式辅助接线条IC200TBR002弹簧式辅助接线片IC200TBL005其他载体通信载体IC200CHS006电源升压载体IC200PWB001 GFK-1504N第1章简介1-15 1扩展模块VersaMax扩展系统有两种基本类型，多机架和双机架本地：多机架：VersaMax PLC或NIU站，带有扩展发射器模块（IC200ETM001）和一到七个扩展“机架”，每个扩展“机架都带有扩展接收器模块（IC20ERM001或IC200ERM002）。如果所有扩展接收器均为隔离型（IC200ERM001），则最大总电缆长度为750米。如果扩展总线包括任何非隔离扩展接收器（IC200ERM002），则最大总电缆长度为15米。PS CPU/NIU PS ERM PS ERM ETM VersaMax ExpansionRack 1终端插头15M，带有任何IC200ERM002 ERM 750M，带有所有IC200ERM 001 ERM VersaMax PLC或站主机架（0）IC200CBL601、VersaMax扩展机架7 602、615双机架本地：CPU或NIU站直接连接到一个扩展机架，带有非隔离扩展接收器模块（IC200ERM2）。最大电缆长度为1米。PS ERM VersaMax扩展机架1 M VersaMax PLC或NIU站主机架PS CPU/NIU IC200CBL601 1-16 VersaMax模块、电源和托架用户手册GFK-1504N 1 VersaMax用于扩展机架的模块所有类型的VersaMax和通信模块均可用于扩展机架。
modules can be installed on carriers or removed without disturbing field wiring. There are three basic Carrier types: Terminal-style carriers. Modules mount parallel to the DIN rail. Compact Terminal-style Carriers. Modules mount perpendicular to the DIN rail. Connector-style Carriers. Modules mount perpendicular to the DIN rail. These carriers are normally used with Interposing Terminals. One type of Interposing Terminals is illustrated below; other types are also available. Refer to chapter 4 for information about VersaMax Carriers. Terminal-style carriers have 36 individual terminals for direct connection of field wiring. Auxiliary Terminal Strips are available for applications requiring additional wiring terminals. Chapter 5 describes the VersaMax Interposing Terminals and Auxiliary Terminal Strips. Terminal-style Carrier Compact Terminalstyle Carrier Connector-style Carrier and Interposing Terminals Auxiliary Terminal Strip 1-14 VersaMax Modules, Power Supplies and CarriersUser Manual GFK-1504N 1 Available Carriers and Terminal Strips Terminal-Style Carriers Barrier-Style Terminal Carrier IC200CHS001 Box-Style Terminal Carrier IC200CHS002 Spring-Style Terminal Carrier IC200CHS005 Compact Terminal-Style Carriers Compact Box-Style Carrier IC200CHS022 Compact Spring-Style Carrier IC200CHS025 Connector-Style Carrier Connector-Style Carrier IC200CHS003 Interposing Terminals for use with Connector-Style Carrier Barrier-Style Interposing Terminals IC200CHS011 Box-Style Interposing Terminals IC200CHS012 Thermocouple-Style Interposing Terminals IC200CHS014 Spring-Style Interposing Terminals IC200CHS015 Disconnect-Style Interposing Terminals, Main Base Disconnect-Style Interposing Terminals, Expansion Base IC200CHS101 IC200CHS102 Relay-Style Interposing Terminals, Main Base Relay-Style Interposing Terminals, Expansion Base IC200CHS111 IC200CHS112 Fuse-Style Interposing Terminals, Main Base Fuse-Style Interposing Terminals, Expansion Base IC200CHS121 IC200CHS122 Cables for use with Connector-Style Carriers 2 connectors, 0.5m, no shield IC200CBL105 2 connectors, 1.0m, no shield IC200CBL110 2 connectors, 2.0m, no shield IC200CBL120 1 connector, 3.0m, no shield IC200CBL230 Auxiliary Terminal Strips for use with Terminal-style Carriers and Interposing Terminals Barrier-Style Auxiliary Terminal Strip IC200TBM001 Box-Style Auxiliary Terminal Strip IC200TBM002 Spring-Style Auxiliary Terminal Strip IC200TBM005 Other Carriers Communications Carrier IC200CHS006 Power Supply Booster Carrier IC200PWB001 GFK-1504N Chapter 1 Introduction 1-15 1 Expansion Modules There are two basic types of VersaMax expansion systems, Multi-Rack and Two-Rack Local: Multi-Rack: A VersaMax PLC or NIU Station with an Expansion Transmitter Module (IC200ETM001) and one to seven expansion “racks”, each with an Expansion Receiver Module (IC200ERM001 or IC200ERM002). If all the Expansion Receivers are the Isolated type (IC200ERM001), the maximum overall cable length is 750 meters. If the expansion bus includes any non-isolated Expansion Receivers (IC200ERM002), the maximum overall cable length is 15 meters. PS CPU/NIU PS ERM PS ERM ETM VersaMax ExpansionRack 1 Terminator Plug 15M with any IC200ERM002 ERMs 750M with all IC200ERM001 ERMs VersaMax PLC or Station Main Rack (0) IC200CBL601, VersaMax ExpansionRack 7 602, 615 Two-Rack Local: A CPU or NIU Station connected directly to one expansion rack with non-isolated Expansion Receiver Module (IC200ERM002). Maximum cable length is 1 meter. PS ERM VersaMax Expansion Rack 1 M VersaMax PLC or NIU Station Main Rack PS CPU/NIU IC200CBL601 1-16 VersaMax Modules, Power Supplies and CarriersUser Manual GFK-1504N 1 VersaMax Modules for Expansion Racks All types of VersaMax and communications modules can be used in expansion racks.
