IS200VAICH1C IS200VTURH1B系统模块卡件
IC693R590 Series 90-30可编程逻辑控制器的120伏交流输入/继电器模块在同一模块中提供8个输入点和一个电源输入端子以及8个全开继电器。输入s是无功（电阻/电容器）输入，并且被布置为一组8个输入。这些点分为两组，每组四个点。每组有一个电源端子。输入特性与各种用户提供的设备兼容，例如：按钮、限位开关和电子接近开关。通过输入的电流导致输入状态表（%I）中的逻辑1。操作现场设备的电源必须由用户提供。此模块的输入部分需要交流电源，不能与直流电源一起使用。rlly open继电器用于控制用户提供的负载。每个开关的开关容量为2。继电器可以控制各种用户提供的负载设备，例如：电机起动器、螺线管和指示器。夹层继电器的电源由背板上的+24伏直流总线提供。用户必须提供交流或直流电源来操作现场设备。此模块上有保险丝。LED指示灯位于模块顶部，指示每个点的开/关状态。LED布置在两个水平行中，每行中有八个绿色LED。顶行标记为A1至8（输入点1至8），底行标记为B1至B8（中继点1至7）。铰链门的内外表面之间有一个插件。朝向模块内部的表面（当铰链门关闭时）具有接线信息，并且识别信息可以记录在外表面上。插件的左外边缘用红色编码，表示高压模块。该模块可安装在Series 90-30 PLC系统中5或10插槽基板的任何I/O插槽中。8 8-2 90–30系列PLC I/O模块规格–2000 GFK–0898F表8-1。IC693R590输入规格额定电压120伏AC输入电压范围0至132伏每个模块8的AC输入（一组八个输入）场和逻辑侧之间的隔离1500伏RMS输入和逻辑侧输入之间的500伏RMS输入电流12（典型）额定电压输入特性通电状态电压74至132伏AC关断状态电压伏AC通电状态电流6（最小）关断状态电流2.2开启响应时间30 ms典型关闭响应时间45 ms典型额定电压24，120/240 C工作电压5至30伏DC 5至250伏AC，每个模块8 50/60 Hz s（每组两组，每组四个）磁场和逻辑侧之间隔离1500伏RMS，组之间隔离500伏RMS，每个最小负载每4个负载2个负载5个浪涌5个打开响应时间15毫秒关闭响应时间15 ms互锁功耗80（所有I/O均打开），来自+5V背板总线70（所有I/O都打开），继电器+24V背板总线负载电流取决于工作电压，如图所示下表。产品标准和一般规范参见附录B。表8-2。IC693R590负载类型的负载电流限制典型接触寿命电压电阻灯或螺线管（操作次数）对于电感负载，离散组合模块8 GFK–0898F第8章-离散组合模块8-3切换电感负载时，如果使用抑制，继电器接触寿命将接近电阻负载接触寿命。下图是交流和直流负载的典型抑制示例。直流负载典型抑制中所示的1A、100V二极管是行业标准1N4934。用于交流负载抑制的电阻器和电容器是标准组件，可从大多数电子产品分销商获得。直流负载系列90-30继电器COM直流电源1A，100V a4511A负载线圈现场接线信息下图提供了将用户提供的输入和负载设备以及电源连接到120伏输入/继电器模块的接线信息。90-30系列继电器~交流电源.022 COM a4512A交流负载模块规格–2000 GFK–0898F TERMILS现场使用模块或其他S光耦合器N H~继电器
IC693R590 The 120 volt AC Input/Relay module for the Series 90-30 Programble Logic Controller provides 8 input points with one power input termil, and 8 rlly-open relay s in the same module. The input s are reactive (resistor/capacitor) inputs and are arranged as one group of 8 inputs. The points are arranged in two groups of four points each. Each group has a power termil. Input characteristics are compatible with a wide range of user-supplied devices, such as: pushbuttons, limit switches, and electronic proximity switches. Current through an input results in a logic 1 in the input status table (%I). Power to operate the field devices must be supplied by the user. This module’s input section requires an AC power source, it cant be used with a DC power source. The rlly-open relay s are used for controlling loads provided by the user. The switching capacity of each is 2 . The relay s can control a wide range of user-supplied load devices, such as: motor starters, soleids, and indicators. Power for the interl relay s is provided by the +24 volt DC bus on the backplane. The user must supply the AC or DC power to operate field devices. There are fuses on this module. LED indicators which provide the ON/OFF status of each point are located at the top of the module. The LEDs are arranged in two horizontal rows with eight green LEDs in each row. The top row is labeled A1 through 8 (input points 1 through 8) and the bottom row is is labeled B1 through B8 (relay points 1 through 8). An insert goes between the inside and outside surface of the hinged door. The surface towards the inside of the module (when the hinged door is closed) has wiring infortion, and identification infortion can be recorded on the outside surface. The outside left edge of the insert is color-coded red to indicate a high-voltage module. This module can be installed in any I/O slot of a 5 or 10-slot baseplate in a Series 90-30 PLC system. 8 8-2 Series 90–30 PLC I/O Module Specifications – 2000 GFK–0898F Table 8-1. Specifications for IC693R590 Inputs Rated Voltage 120 volts AC Input Voltage range 0 to 132 volts AC Inputs per Module 8 (one group of eight inputs) Isolation 1500 volts RMS between field and logic side 500 volts RMS between inputs Input Current 12 (typical) at rated voltage Input Characteristics On-State Voltage 74 to 132 volts AC Off-State Voltage volts AC On-State Current 6 (minimum) Off-State Current 2.2 On Response Time 30 ms typical Off Response Time 45 ms typical s Rated Voltage 24 , 120/240 C Operating Voltage 5 to 30 volts DC 5 to 250 volts AC, 50/60 Hz s per Module 8 (two groups of four s each) Isolation 1500 volts RMS between field and logic side 500 volts RMS between groups Load 2 per 4 per Minimum Load 10 Inrush 5 On Response Time 15 ms Off Response Time 15 ms Interl Power Consumption 80 (all I/O on) from +5V backplane bus 70 (all s on) from relay +24V backplane bus load current is dependent on operating voltage as shown in the following table. Refer to Appendix B for product standards and general specifications. Table 8-2. Load Current Limitations for IC693R590 Operating Current for Load Type Typical Contact Life Voltage Resistive Lamp or Soleid (number of Operations) For inductive loads Discrete Combition Modules 8 GFK–0898F Chapter 8 – Discrete Combition Modules 8-3 Relay contact life, when switching inductive loads, will approach resistive load contact life if suppression s are used. The following figures are examples of typical suppression s for AC and DC loads. The 1A, 100V diode shown in the DC load typical suppression is an industry standard 1N4934. The resistor and capacitor shown for AC load suppression are standard components, ailable from most electronics distributors. DC LOADS SERIES 90-30 RELAY COM DC SUPPLY 1A, 100V a45151A Load Coil Field Wiring Infortion The following figure provides wiring infortion for connecting user supplied input and load devices, and power source(s) to the 120 Volt Input/Relay module. SERIES 90-30 RELAY ~ AC SOURCE .022 COM a45152A AC LOADS Module Specifications – 2000 GFK–0898F TERMILS FIELD T USED MODULE RY OTHER S OPTICAL COUPLER N H ~ RELAY
