MPL-B980E 2750 13.0 0.0354（0.313）141.0（1250）237.0（2100）105.0 230.0*所示转子惯性值适用于非制动编码器电机。制动器和分解器版本的电机的惯量更高。增量编码器和解析器版本的尺寸有限。出版物MP-PP001O-EN-P–2012年3月版权所有©2012 Rockwell Automation，Inc.保留所有权利。在美国印刷，取代出版物MP-P001N-EN-P–2008年12月连接器和电缆MP系列低惯量电机的新型SpeedTEC DIN连接器版本，允许连接器灵活定向，并可将单个电缆系列用于所有MP系列电机。SpeedTEC DIN连接器旨在提供快速的四分之一圈连接。这提供了一个简单而安全的伺服连接。连接器符合广泛的规范和标准要求：符合UL认证NFPA 79的DESINA电缆护套着色托盘电缆额定值RoHS和REACH 600V绝缘额定值电机电缆罗克韦尔自动化公司为您的MP系列电机提供全面的电源、反馈和制动电缆选择。配件包括标准和连续流动电缆，长度从1米到90米不等。连续流动的电源和制动电缆符合RoHS和NFPA-79托盘额定值，由UL认证的散装电缆组成。护套颜色符合DESINA规范。电机附件轴封套件适用于MP系列低惯量电机的所有框架尺寸。如果安装正确，密封件在轴上的防护等级为IP66。注意，轴封是需要定期更换的易损件。
特定电机选择轴封套件。大多数MP系列电机可使用电机端连接器套件。客户选择自己制造电缆时使用这些电缆。该套件采用金属后壳，压缩式密封电缆护套，并根据套件采用焊接式或压接式连接器插座。罗克韦尔自动化公司为压接式插座提供压接工具。有关更多信息，请访问我们的网站www.ab.com/motion或Kinetix选择指南GMC-SG001x。Allen-Bradley和Kinetix是罗克韦尔自动化的注册商标。SERCOS接口是德国斯图加特Interest Group SERCOS interface e.V的商标。电缆可用于MP系列电机和其他Allen-Bradley电机以及带有DIN型连接器的致动器。安装说明MP系列低惯量无刷伺服电机，具有75 mm或更小的框架尺寸，目录号MPL-A1510、MPL-A1520、MPL-A1130、MPL-A210、MPL-A120、MPL-A-220、MPL-B230、MPL-B1510、MPR-B1520、，MPL-B230主题页重要用户信息2目录号说明3关于MP系列低惯量电机4开始之前4安装电机9产品尺寸13电机负载力额定值15连接器数据17拆卸和安装轴键18电机电缆和附件套件19规格20附加资源21 2 MP系列75 mm或较小框架尺寸罗克韦尔自动化出版物MP-IN006D-EN-P-2015年1月重要用户信息阅读本文档以及有关安装的附加资源部分中列出的文档，
The rotor inertia value shown in MPL-B980E 2750 13.0 0.0354 (0.313) 141.0 (1250) 237.0 (2100) 105.0 230.0 * is applicable to non brake encoder motor. The brake and resolver versions have higher inertia. The incremental encoder and parser versions are limited in size. Publication MP-PP001O-EN-P – March 2012 All rights reserved © 2012 Rockwell Automation，Inc. All rights reserved. Printed in the United States and replacing publication MP-P001N-EN-P – December 2008 connector and cable MP series low inertia motors, the new SpeedTEC DIN connector version allows flexible orientation of the connector and can use a single cable series for all MP series motors. The SpeedTEC DIN connector is designed to provide fast quarter turn connections. This provides a simple and secure servo connection. Connectors meet a wide range of specifications and standards: DESINA cable sheathed, colored tray cable rating RoHS and REACH 600V insulation rating motor cable conforming to UL certification NFPA 79 Rockwell Automation provides a comprehensive selection of power, feedback and brake cables for your MP series motors. Accessories include standard and continuous flow cables ranging in length from 1 meter to 90 meters. Continuous flow power and brake cables comply with RoHS and NFPA-79 tray ratings and consist of UL certified bulk cables. Sheath color shall conform to DESINA specification. The motor accessory shaft seal kit is applicable to all frame dimensions of MP series low inertia motors. If installed correctly, the protection class of the seal on the shaft is IP66. Note that the shaft seal is a wearing part that needs to be replaced regularly.
The shaft seal kit is selected for the specific motor. The motor end connector kit is available for most MP series motors. These cables are used when customers choose to make their own cables. The kit uses a metal back shell, a compression sealed cable sheath, and a welded or crimped connector socket according to the kit. Rockwell Automation provides crimping tools for crimping sockets. For more information, please visit our website at www.ab.com/motion or Kinetix Selection Guide GMC-SG001x. Allen Bradley and Kinetix are registered trademarks of Rockwell Automation. SERCOS interface is a trademark of the Interest Group SERCOS interface e.V in Stuttgart, Germany. Cables can be used for MP series motors and other Allen Bradley motors as well as actuators with DIN type connectors. Installation instructions MP series low inertia brushless servo motor, with 75 mm or smaller frame size, catalog number MPL-A1510, MPL-A1520, MPL-A1130, MPL-A210, MPL-A120, MPL-A-220, MPL-B230, MPL-B1510, MPR-B1520, MPL-B230 topic page Important user information 2 Catalog number description 3 About MP series low inertia motor 4 Before starting 4 Installing motor 9 Product size 13 Motor load force rating 15 Connector data 17 Removing and installing shaft key 18 Motor cable and accessories kit 19 Specification 20 Additional resources 21 2 MP series 75 mm or smaller frame size Rockwell automation publication MP-IN006D-EN-P-2015 Important user information Read this document and additional resources related to installation Documents listed in section,
