MVME259D机器人备件
商标是其各自公司的财产。还可提供全系列兼容附件，包括：•馈线接线板和紧凑型母线•常开和常闭前部和侧面安装的辅助触点•并联跳闸和欠压跳闸辅助触点•门耦合手柄•IP65外壳（UL/CSA类型12）有关附件和规格的更多详细信息，请参阅ab.com上的技术数据*所示马力/kW额定值仅供参考。MPCB/MPSD的最终选择取决于实际电机满载电流。安装说明原始说明VersaView 6300 DC连接器组件和更换安装夹目录号6300V-DCCONN、6300V-DCCONN2、6300V-DCCON3、，6300V-MTGCLIP16本出版物中的说明适用于以下项目：•直流电源VersaView®6300 PC和VersaView 6300监视器的连接器组件•VersaView 630P面板PC和Versa View 6300M监视器的更换安装夹安装所需工具以下工具用于安装6300V-DCCONN、6300V-DCCONN2、，或6300V-DCCONN3直流连接器组件：•带公制平刃螺丝刀头的可调扭矩螺丝刀•剥线器、切割器、，和压接工具•剪切钳•安全眼镜以下工具用于安装替换的6300V-MTGCLIP16安装夹：•1.5 mm六角扳手（两个随安装夹一起提供）•带1.5 mm六方扳手头的可调扭矩驱动器•安全眼镜安装直流连接器组件连接器组件通过减少直流电源线移动要组装和连接连接器组件，请执行以下步骤。
1.断开计算机的电源。2.从计算机机箱上卸下直流接线板。3.打开电脑附带的电源连接器组装套件（第3页图2中的A）。4.将电缆扎带穿过相应连接器半部的插槽（第3页图2中的B）。5.剥开每根直流电源线的末端，使其达到第2页图1所示的长度。6.将每个剥开的末端插入直流接线板，如图1所述。主题页安装所需工具1安装直流连接器组件1安装更换安装夹3重要的直流电源线必须为绞合铜，尺寸符合第2页图1。2罗克韦尔自动化出版物6300V-IN003A-EN-P-2021 1月VersaView 6300直流连接器组件和更换安装夹安装说明7。拧紧接线板顶部的螺钉，将直流电源线固定到图1.8中的扭矩值。将连接器半体连同连接的系带滑动到直流接线板的端部（第3页图2中的C）。9.拧紧电缆扎带，使其紧贴端子电线。10.使用切割钳切割电缆扎带的多余部分（第3页图2中的D）。11.安装随套件提供的白色标签（第3页图2中的E）。12.对齐并安装另一半连接器夹具，以完成组装（第3页图2中的F）。13.将直流接线板与连接器组件重新连接到计算机机箱。将直流接线板法兰螺钉拧紧至图1.14中的值。打开主电源开关或断路器。图1-直流接线板连接规范白色标签可用于标识或其他信息。正确安装后，半卡箍的两个凸舌将锁定到位。项目描述属性6300V-DCCONN 6200V-DCCONN2 6300V-DCCONN3 1 DC+（24V DC标称）推荐电源线尺寸1.5 mm2（16 AWG）2.5 mm2（14 AWG）4 mm2（12 AWG）2 DC-（0V DC）
Trademarks are the property of their respective companies. A full range of compatible accessories are also available, including: • Feeder terminal blocks and compact buses • Normally open and normally closed front and side mounted auxiliary contacts • Shunt trip and undervoltage trip auxiliary contacts • Door coupling handle • IP65 enclosure (UL/CSA type 12) For more details on accessories and specifications, see ab The horsepower/kW rating shown in the technical data * on. com is for reference only. The final selection of MPCB/MPSD depends on the actual motor full load current. Installation Instructions Original Instructions VersaView 6300 DC Connector Assembly and Replacement Mounting Clip Catalog Numbers 6300V-DCCONN, 6300V-DCCONN2, 6300V-DCCON3, 6300V-MTGCLIP16 The instructions in this publication apply to the following items: • DC Power VersaView ® Connector assemblies for 6300 PC and VersaView 6300 monitors • Replacement mounting clips for VersaView 630P panel PC and Versa View 6300M monitors Required tools for installation The following tools are used to install 6300V-DCCONN, 6300V-DCCONN2, or 6300V-DCCONN3 DC connector assemblies: • Adjustable torque screwdriver with metric flat blade screwdriver head • Wire stripper, cutter, And crimping tools • Shear pliers • Safety glasses The following tools are used to install the replacement 6300V-MTGCLIP16 mounting clip: • 1.5 mm hex wrench (two are supplied with the mounting clip) • Adjustable torque driver with 1.5 mm hex wrench head • Safety glasses installation DC connector assembly Connector assembly To assemble and connect the connector assembly by reducing DC power cord movement, please perform the following steps.
1. Disconnect the power of the computer. 2. Remove the DC patch panel from the computer chassis. 3. Open the power connector assembly kit (A in Figure 2 on page 3) that came with your PC. 4. Thread the cable tie through the slot in the corresponding connector half (B in Figure 2 on page 3). 5. Strip the end of each DC power cord to the length shown in Figure 1 on page 2. 6. Insert each stripped end into the DC terminal block as shown in Figure 1. Tools required for installation on the topic page 1. Installation of DC connector assembly 1. Installation and replacement of mounting clip 3. Important DC power cables must be stranded copper, and the size should conform to Figure 1 on page 2. 2 Rockwell Automation Publication 6300V-IN003A-EN-P-2021 January VersaView 6300 DC Connector Assembly and Replacement Mounting Clip Installation Instructions 7. Tighten the screws on the top of the terminal block to secure the DC power cord to the torque value in Figure 1.8. Slide the connector half together with the attached tie wrap onto the end of the DC terminal block (C in Figure 2 on page 3). 9. Tighten the cable tie to make it close to the terminal wire. 10. Use cutting pliers to cut the excess part of the cable tie (D in Figure 2 on page 3). 11. Install the white label supplied with the kit (E in Figure 2 on page 3). 12. Align and install the other half of the connector clamp to complete the assembly (F in Figure 2 on page 3). 13. Reconnect the DC patch panel and connector assembly to the computer chassis. Tighten the DC terminal block flange screws to the values in Figure 1.14. Turn on the main power switch or circuit breaker. Figure 1 - DC terminal block connection specifications White labels can be used for identification or other information. When properly installed, the two tabs of the half clamp will lock in place. Item Description Attribute 6300V-DCCONN 6200V-DCCONN2 6300V-DCCONN3 1 DC+(24V DC nominal) Recommended power cord size 1.5 mm2 (16 AWG) 2.5 mm2 (14 AWG) 4 mm2 (12 AWG) 2 DC - (0V DC)
