环境–1区、2区、21区、22区–防火（db）、增强安全（eb），和外壳（tb）保护类型•面板安装设计–面板安装盖安装的两个选项卡–800G-APMC面板安装盖附件可现场安装在面板背面，以达到额外的IP66和IP67等级–组件保持认证覆盖范围•装配式站配置便于选择和安装，包括：–双按钮–按键操作选择开关–锁紧保护装置、锁紧盖–附加卡扣式颜色盖变体•可作为单个组件或标准或定制组装工位提供，以实现最佳灵活性全球危险场所解决方案的来源出版物800G-PP001A-EN-P–2019年5月版权所有©2019 Rockwell Automation，Inc.。保留所有权利。在美国印刷。Allen-Bradley和Rockwell Software是罗克韦尔自动化公司的商标。不属于罗克韦尔自动公司的商标是其各自公司的财产。公告800G系列比较公告800G解决方案公告800G“-EX”解决方案认证cULus、ATEX（过时）ATEX（更新）、IECEx、INMETRO、NEPSI危险区域分类I级2区、I级1区1区、21区环境等级IP66、IP67（选择配置）、4X型IP64、IP66、，IP67（选择配置）与800G-APMC（面板安装盖附件）的兼容性否是否允许现场安装站/空外壳可供销售是否组装站标准、成组、定制标准、成组，自定义目录编号字符串现有（不会更改）
“-EX”后缀（表示ATEX和IECEx）ATEX&IECEx组装站扩展说明操作员代码双瞬时按钮U 2位置键选择开关R 3位置键选择按钮S紧急停止推拉带锁紧防护装置4非照明按钮带锁紧盖5照明按钮带锁定盖6 2位置带锁盖的选择器开关8 3位置选择器开关带锁盖9完整的组装站目录编号目录编号描述800G-144N3-EX红色急停按钮，带2个NC触点和锁紧防护装置，M20塑料电缆压盖800G-144A3-EX红色紧急停按钮，带有1个NO 1 NC触点和锁定防护装置，M20塑料电缆压盖800G-1R1A3-EX 2位置保持键选择开关，带1 NO 1 NC触点，左键拆除，M20塑料电缆密封套800G-1UXA8-EX双按钮，带1 NO1 NC触点；M20金属电缆压盖800G-2FAA5A3-EX启动按钮，带一NO 1 NC接触，M20塑料电缆压盖800G-2F3AA54A3-EX带1 NO 1 NC触点的绿色按钮，带1 NO 1NC触点和锁定盖的红色按钮，M20塑料电缆填料压盖800G-2P4DUXA3-EX红色指示灯，带1 NO1NC触点的双按钮，M20塑性电缆压盖800G-3F3AF4A44A3-EX带有1 NO 1数控触点的绿色按键，红色急停按钮，带1 NO 1NC触点和锁紧防护装置，M20塑料电缆压盖。本表包括组装站的常用目录号，更多标准配置可在我们的配置工具或出版物800-TD011_-EN-P（第52-54页）中找到。
Environment – Zone 1, Zone 2, Zone 21, Zone 22 – Fire (db), Enhanced Security (eb), and Enclosure (tb) protection types • Panel mounting design – two tabs for panel mounting cover installation – 800G-APMC panel mounting cover accessories can be field mounted on the back of the panel to achieve additional IP66 and IP67 ratings – components maintain certified coverage • Fabricated station configuration for easy selection and installation, Includes: – Double button – Key operated selector switch – Locking protector, locking cover – Additional snap on color cover variants • Available as a single component or as a standard or custom assembly station for optimal flexibility Source publication 800G-PP001A-EN-P – May 2019 Global Hazardous Locations Solutions © 2019 Rockwell Automation，Inc.。 All rights reserved. Printed in the United States. Allen Bradley and Rockwell Software are trademarks of Rockwell Automation. Trademarks not belonging to Rockwell Automation are the property of their respective companies. Announcement 800G Series Comparison Announcement 800G Solution Announcement 800G "- EX" Solution Certification cULus, ATEX (outdated) ATEX (updated), IECEx, INMETRO, NEPSI Hazardous Area Classification Class I Zone 2, Class I Zone 1 Zone 1, Zone 21 Environmental Class IP66, IP67 (optional configuration), 4X type IP64, IP66, Whether IP67 (optional configuration) is compatible with 800G-APMC (panel mounting cover accessories), whether field installation station/empty shell is allowed to be sold, whether assembly station standard, grouping, customized standard, grouping, customized directory number string is existing (will not be changed)
"- EX" suffix (representing ATEX and IECEx) ATEX&IECEx assembly station expansion description operator code double instantaneous button U 2 position key selection switch R 3 position key selection button S emergency stop push-pull with locking protection device 4 non illuminated button with locking cover 5 illuminated button with locking cover 6 2 position selector switch with locking cover 8 3 position selector switch with locking cover 9 complete assembly station catalog number catalog number description 800G-144N3-EX red emergency stop button, With 2 NC contacts and locking protection devices, M20 plastic cable gland 800G-144A3-EX red emergency stop button, with 1 NO 1 NC contact and locking protection device, M20 plastic cable gland 800G-1R1A3-EX 2 position holding key selector switch, with 1 NO 1 NC contact, left key removal, M20 plastic cable gland 800G-1UXA8-EX double button, with 1 NO 1 NC contact; M20 metal cable gland 800G-2FAA5A3-EX start button with 1 NO 1 NC contact, M20 plastic cable gland 800G-2F3AA54A3-EX green button with 1 NO 1 NC contact, red button with 1 NO 1 NC contact and locking cover, M20 plastic cable gland 800G-2P4DUXA3-EX red indicator light, double button with 1 NO 1 NC contact, M20 plastic cable gland 800G-3F3AF4A44A3-EX green button with 1 NO 1 NC contact, red emergency stop button, With 1 NO 1NC contact and locking guard, M20 plastic cable gland. This table includes the common catalog numbers of the assembly station. More standard configurations can be found in our configuration tool or publication 800-TD011_- EN-P (pages 52-54).
