高级信息驱动窗口2 10-29您也可以单击Pin文件（*.x01）或Symbol文件（*.xml）对话框中的浏览按钮，而不是写入文件的路径和名称。将显示一个类似于打开对话框的对话框：•从“查找”中，浏览到符号表文件所在的驱动器和文件夹•单击要打开的符号表文件•单击“打开注释”！也可以在“文件名”中输入符号表文件的名称，包括或不包括文件夹路径。笔记通过在“文件名”中输入通配符构造，然后单击“打开”，可以限制显示的文件名。文件的路径和名称现在显示在Pin文件（*.x01）对话框中。高级信息10-30 DriveWindow 2如果找到文件，应用程序常量和PC元素结构将显示为浏览树窗格中Pins子分支下的子分支。文件名显示为浏览项目集中Pin文件（*.x01）项的值。如果无法打开文件，则会收到一条错误消息，通知您写入pin文件项失败。当浏览到子分支的叶子时，端号和常量值将显示在浏览的项目集中。您可以通过向浏览的项目集中的pin文件（名称）写入空字符串来关闭符号表文件。关闭文件后，也可以通过在浏览树窗格中双击Pins子分支来折叠该分支。10.1.2系统软件符号要打开系统软件符号表，请在浏览树窗格中浏览驱动器内存子分支下的Ram子分支。对于ACS880系列驱动器（本机DriveDA OPC服务器驱动器），系统软件符号不可用。现在，您可以将符号表文件的路径和名称写入浏览项目中的内存映射文件（*.CLD）。请注意，如果文件位于DriveWindow起始文件夹（通常是安装文件夹）中，则可以省略路径。您也可以单击内存映射文件（*.CLD）对话框中的浏览按钮，而不是写入文件的路径和名称。高级信息驱动窗口2 10-31显示类似于打开对话框的对话框：•从“查找”中，浏览到符号表文件所在的驱动器和文件夹•单击要打开的符号表文件•单击“打开注释”！也可以在“文件名”中输入符号表文件的名称，包括或不包括文件夹路径。笔记通过在“文件名”中输入通配符构造，然后单击“打开”，可以限制显示的文件名。文件的路径和名称现在显示在内存映射文件（*.CLD）对话框中。如果找到文件，则X、Y和P内存的系统软件符号将显示在浏览树窗格中Ram子分支的相应子分支下的子分支中。文件名显示为浏览项目集中内存映射文件（*.CLD）项目的值。
Advanced Information DriveWindow 2 10-29 Instead of writing the path and name of the file, you can also click the browse button in the Pin file (*.x01) or Symbol file (*.xml) dialog box. A dialog box similar to an open dialog box is displayed: • From Look in, browse into the drive and folder, in which the symbol table file resides • Click the symbol table file you want to open • Click Open Note! You can also enter the name of the symbol table file into File name, with or without a folder path. Note! You can limit the filenames displayed by entering a wildcard construct into File name and then clicking Open. Path and name of the file are now shown in the Pin file (*.x01) dialog box. Advanced Information 10-30 DriveWindow 2 If the file is found, the application constant and PC element structures will appear as sub-branches under the Pins sub-branch in the browse tree pane. The name of the file is shown as value of the Pin file (*.x01) item in the browsed item set. If the file could not be opened, you get an error message informing you that writing to pin file item failed. The pins and constant values are shown in the browsed item set, when you browse to the leaves of the sub-branches. You can close the symbol table file by writing an empty string to the pin file (name) in the browsed item set. After closing the file, also collapse the Pins sub-branch by double-clicking it in the browse tree pane. 10.1.2 System Software Symbols To open a system software symbol table, browse in the browse tree pane the Ram sub-branch under the Memory sub-branch of the drive. In case of ACS880 family of drives (native DriveDA OPC server drives) system software symbols are not available. You can now write to the Memory map file (*.CLD) in the browsed item set the path and the name of the symbol table file. Note that if the file is in the DriveWindow start-in folder (usually the installation folder), you can omit the path. Instead of writing the path and name of the file, you can also click the browse button in the Memory map file (*.CLD) dialog box. Advanced Information DriveWindow 2 10-31 A the dialog box similar to an open dialog box is displayed: • From Look in, browse into the drive and folder, in which the symbol table file resides • Click the symbol table file you want to open • Click Open Note! You can also enter the name of the symbol table file into File name, with or without a folder path. Note! You can limit the filenames displayed by entering a wildcard construct into File name and then clicking Open. Path and name of the file are now shown in the Memory map file (*.CLD) dialog box. If the file is found, system software symbols for X-, Y-, and P-memory will appear in sub-branches under the corresponding sub-branches of the Ram sub-branch in the browse tree pane. The name of the file is shown as value of the Memory map file (*.CLD) item in the browsed item set.
