（实际上是其通信库）或其他应用程序当前正在使用该通信库。将显示一个对话框，其中包含所选当前配置找到的DDCS/UDP设备列表。请注意，测试不会检查设备的DDCS网络中是否有驱动器。因此，虽然找到了DDCS/UDP设备，但当DriveWindow连接到DriveOPC时，可能找不到驱动器。如果测试未找到任何DDCS/UDP设备，将显示消息框而不是对话框。OPC服务器驱动窗口2 7-21 7.1.5保存更改要保存对DDCS/UDP配置所做的任何更改，请单击DDCS/UDP“配置”对话框中的“确定”按钮。7.1.6编辑配置通常，您很少编辑默认配置。要编辑配置，请首先将其选择为“当前配置”，然后从“编辑”或上下文菜单中选择“属性”。或OPC服务器7-22 DriveWindow 2显示配置设置对话框。通常使用默认值，即默认配置中定义的值。重要的例外是启用了DDCS/UDP通信，因为它通常在默认情况下被禁用。并非所有设置都显示在对话框中。用于搜索邻近或intranet设备的DDCS/UDP设备的设置、FixedIPs/remote subnets中列出的每个固定IP和远程子网的设置显示在单独的对话框中。OPC服务器驱动窗口2 7-23 7.1.7设备附近或Intranet设备的设置要编辑搜索DDCS/UDP设备附近或Intranet设备的设置，请单击配置设置对话框通信组中的“附近设备或Intranet设备”按钮。将显示配置的“搜索附近的设备”或“搜索Intranet设备设置”对话框。对话框的区别仅在于标题。OPC服务器7-24 DriveWindow 2 7.1.8固定IP或远程子网的设置要编辑固定IP和远程子网设置，请在配置设置对话框的固定IP/远程子网列表中单击该设置，然后从编辑菜单中选择属性命令，或右键单击固定IPs/Remote Subnets列表中的它，然后从显示的上下文菜单中选择Properties命令。或显示配置的固定IP/远程子网设置对话框。OPC服务器驱动窗口2 7-25 7.1.9添加和删除固定IP或远程子网可在配置设置对话框的编辑菜单和上下文菜单中找到用于添加或删除固定IP和远程子网的命令，如果右键单击对话框中的固定IP/远程子网列表，将显示该菜单。或注意，您也可以通过点击Del键删除所选的固定IP或远程子网。还请注意，如果固定IP/远程子网列表中没有条目或没有选择条目，则菜单中除“新建”以外的所有其他命令都将灰显。7.1.10通过查找设备添加和删除固定IP请注意，只有当（默认）UDP端口61332空闲且未被防火墙阻止时，查找操作才有效。在DDCS/UDP配置中对端口设置所做的任何更改都不会用于查找DDCS/UDP设备。要查找DDCS/UDP设备附近或intranet设备的IP地址，请单击“配置设置”对话框“查找”组中的“附近设备”或“intranet设备”按钮。将显示OPC服务器7-26 DriveWindow 2“找到的设备”对话框。在左侧，您可以看到未包含在所选当前配置中的DDCS/UDP设备列表。在右侧，您可以看到所选当前配置中包含的DDCS/UDP设备列表。
(actually its communication library) or some other application is currently using the communication library. A dialog box containing a list of DDCS/UDP devices found by the selected Current configuration is displayed. Note that the test does not check that there are drives in the DDCS network of the device. So it is possible that although there are DDCS/UDP devices found, no drive is found when DriveWindow is connected to DriveOPC. If the test does not find any DDCS/UDP devices, instead of a dialog box a message box is shown. OPC Server DriveWindow 2 7-21 7.1.5 Saving Changes To save any changes made into the DDCS/UDP configurations, click the OK button in the DDCS/UDP Configuration dialog box. 7.1.6 Editing a Configuration Typically, you seldom edit the Default configuration. To edit a configuration, first select it as the Current configuration and then select Properties from the Edit or context menu. or OPC Server 7-22 DriveWindow 2 The configuration Settings dialog box is displayed. Typically default values, i.e., values defined in the Default configuration, are used. The important exception is that DDCS/UDP Communication is enabled because it is usually disabled by default. Not all of the settings are shown in the dialog box. Settings for searching DDCS/UDP devices near or intranet devices, settings for each fixed IP and remote subnets listed in FixedIPs / Remote Subnets are presented in separate dialog boxes. OPC Server DriveWindow 2 7-23 7.1.7 Settings for Devices Near or Intranet Devices To edit settings for searching DDCS/UDP devices near or intranet devices, click the Near Devices or Intranet Devices button in the Communication group of the dialog box for Settings of a configuration. The Search Devices Near or Search Intranet Devices Settings dialog box for the configuration is displayed. The dialog boxes differ only by the title. OPC Server 7-24 DriveWindow 2 7.1.8 Settings for Fixed IPs or Remote Subnets To edit settings for a Fixed IP or a Remote Subnet, either select it by clicking it in the Fixed IPs / Remote Subnets list in the dialog box for Settings of a configuration and then select the Properties command from the Edit menu, or right click it in the Fixed IPs / Remote Subnets list and select Properties command from the context menu displayed. or The Fixed IP / Remote Subnet Settings dialog box for the configuration is displayed. OPC Server DriveWindow 2 7-25 7.1.9 Adding and Deleting Fixed IPs or Remote Subnets Commands for adding and deleting a Fixed IP or a Remote Subnet can be found in the Edit menu of the dialog box for Settings of a configuration and in the context menu, which is displayed if you right click the Fixed IPs / Remote Subnets listing in the dialog box. or Note that you can delete the selected Fixed IP or Remote Subnet also by hitting the Del key. Note also that if there is no entry in the Fixed IPs / Remote Subnets list or no entry is selected, all other commands than New are grayed in the menu. 7.1.10 Adding and Deleting Fixed IPs by Finding Devices Note that the Find operation works only if the (default) UDP port 61332 is free and not blocked by the firewall. Any changes for the port settings made in the DDCS/UDP configurations are not used in finding the DDCS/UDP devices. To find IP addresses of DDCS/UDP devices near or intranet devices, click the Near Devices or Intranet Devices button in the Find group of the dialog box for Settings of a configuration. OPC Server 7-26 DriveWindow 2 The Devices Found dialog box is displayed. On the left side you have a list of DDCS/UDP devices found that are not included in the selected Current configuration. On the right side you have a list of DDCS/UDP devices found that are included in the selected Current configuration.
