PFCL201CD 5.0KN模块控制器
I主开关装配套件标配外部警示牌有以下语言：64保加利亚语73罗马尼亚语65丹麦语74俄语66芬兰语75瑞典语67荷兰语76塞尔维亚语克罗地亚语68意大利语77西班牙语69希腊语78捷克语70挪威语79土耳其语71波兰语80匈牙利语72葡萄牙语81南非荷兰语要获得订单号，在所需的类型引用中插入语言代码编号。订购示例芬兰语外部警示牌：ZFS66-NZM7 LZM1（-4）、LN1（-4）LZM2（-4），LN2（-4）L2M3（-4）和LN3（-4）L4M4（-4）以及LN4（-4）配件订购NZM…-XRAV…、ZFS…、BPF-…伊顿公司CA012002EN 32与零件号一起使用。价格标准注释条款编号见单独订购的价格包附件订购NZM、-XDZ、NZM…XBR，NZM…-X…绝缘外壳用于拨动杆、带旋转驱动装置的旋转手柄和远程操作器。防护等级IP40 LZM1（-4）、LN1（-4）NZM1-XBR 1 off 260195 LZM2（-4），LN2（-4）NZM2-XBR 260197 LZM3（-4）和LN3（-4）新西兰M3-XBR 284645 LZM4（-4）以及LN4（-4）纽西M4-XBR 284646适用于材料厚度为1.5–5 mm的门和外壳上的长方形切口。NZM4-XBR上可夹有外部警示牌/标识标签，不能与旋转驱动的旋转手柄结合使用。拨动杆锁定装置关闭位置可使用最多3个挂锁（搭扣厚度4–8 mm）LZM1（-4）、LN1（-4）NZM1-XKAV 1个关闭260199 LZM2（-4），LN2（-4）NZM2/3-XKAV 2个关闭LZM3（-4）和LN3（-4）260201锁定。垫片可快速、廉价地调整不同的机架尺寸（带/不带旋转手柄）至相同的前深度LZM1（-4），LN1（-4）NZM1/2-XAB 1套LZM2（-4）、LN2（-4）260203 LZM3（-4）和LN3（-4）NZM3-XAB 1组LZM4（-4）以及LN3（4）260211网格深度17.5 mm，M4螺纹类型包含4个垫片最大部件容量：LZM1:4个固定螺钉，LZM2：每个固定螺钉2个（LZM1）或4个（LZM2），每个断路器包含2个固定螺钉网格深度17.5 mm，M5螺纹一套包含4个垫片LZM3，LZM4：每个固定螺丝1个，每个开关包含4个固定螺钉夹板，使断路器能够卡扣到DIN导轨LZM1（-4），LN1（-4）NZM1-XC35 1个260213 LZM2，LN2 NZM2-XC75 1个260215适用于35 mm顶帽导轨适用于75 mm顶帽滑轨不适用于带远程操作员的断路器。伊顿公司CA012002EN 33伊顿公司CA012 002EN 34机械联锁订购NZM…XMV（R）（L），NZM-XBZ…旋转手柄LZM1（-4），LN1（-4）NZM1-XMV 1 off 281581 LZM2（-4）的机械联锁
ncluded as standard in main switch assembly kit External warning plates are available in the following languages: 64 Bulgarian 73 Romanian 65 Danish 74 Russian 66 Finnish 75 Swedish 67 Dutch 76 Serbo-Croatian 68 Italian 77 Spanish 69 Greek 78 Czech 70 Norwegian 79 Turkish 71 Polish 80 Hungarian 72 Portuguese 81 Afrikaans To obtain the order number, insert the language code number into the type reference required. Ordering example External warning plate in Finnish: ZFS66-NZM7 LZM1(-4), LN1(-4) LZM2(-4), LN2(-4) LZM3(-4), LN3(-4) LZM4(-4), LN4(-4) Accessories Ordering NZM...-XRAV..., ZFS..., BPF-... EATON CORPORATION CA012002EN 32 For use with Part no. Price Std. Notes Article no. when see price pack ordered separately list Accessories Ordering NZM...-XDZ, NZM...-XBR, NZM...-X... Insulating surrounds For toggle lever, rotary handle with rotary drive and remote operator. Degree of protection IP40 LZM1(-4), LN1(-4) NZM1-XBR 1 off 260195 LZM2(-4), LN2(-4) NZM2-XBR 260197 LZM3(-4), LN3(-4) NZM3-XBR 284645 LZM4(-4), LN4(-4) NZM4-XBR 284646 For oblong cut-out on doors and enclosures with material thicknesses of 1.5 – 5 mm. External warning plate/designation label can be clipped on NZM4-XBR cannot be combined with rotary handle with rotary drive. Toggle lever locking device Off position lockable using up to 3 padlocks (hasp thickness 4 – 8 mm) LZM1(-4), LN1(-4) NZM1-XKAV 1 off 260199 LZM2(-4), LN2(-4) NZM2/3-XKAV 1 off LZM3(-4), LN3(-4) 260201 Cannot be combined with insulating surround. Spacers Enables fast and low-priced adjustment of differing frame sizes with/ without rotary handle to the same front depth LZM1(-4), LN1(-4) NZM1/2-XAB 1 set LZM2(-4), LN2(-4) 260203 LZM3(-4), LN3(-4) NZM3-XAB 1 set LZM4(-4), LN3(-4) 260211 Grid depth 17.5 mm, M4 thread Type contains 4 off spacer Maximum component capacity: LZM1: 4 units per fixing screw, LZM2: 2 units per fixing screw 2 (LZM1) or 4 (LZM2) fixing screws contained per circuit-breaker Grid depth 17.5 mm, M5 thread One set contains 4 spacers LZM3, LZM4: 1 off per fixing screw 4 fixing screws per switch included Clip plate Enables snap-fit of the circuit-breaker to a DIN rail LZM1(-4), LN1(-4) NZM1-XC35 1 off 260213 LZM2, LN2 NZM2-XC75 1 off 260215 For top-hat rail 35 mm For top-hat rail 75 mm Not suitable for circuit-breakers with remote operator. EATON CORPORATION CA012002EN 33 EATON CORPORATION CA012002EN 34 Mechanical interlock Ordering NZM...XMV(R)(L), NZM-XBZ... Mechanical interlocking of (door coupling) rotary handles LZM1(-4), LN1(-4) NZM1-XMV 1 off 281581 LZM2(-4)
