PFTL301E 0.1KN工控模块系统备件
端子位置，第4节给出了额定值。注：如果两根电线连接到一个端子，则需要双套管。1 2 6 4 5 1 3 440F护垫™ Mat Manager用户手册第5节-安装设计18罗克韦尔自动化出版物95302194/EO:0240第8期）Allen-Bradley Guardmaster系统可用作唯一的保护措施，或与其他措施或装置（如安全光幕、工作系统）结合使用。图15显示了440F-C28011的示例连接图。电路条件如下：电源开启；传感器垫上不存在，常开安全输出打开，负载断电。控制单元配置为监控手动复位。按下并释放复位按钮，为负载通电。踩在任何垫子上都会导致安全输出打开并切断负载的电源。离开垫子后，必须按下并释放重置按钮，以重新给负载通电。图15图16显示了440F-C28012的示例连接图。电路条件如下：电源开启；传感器垫上不存在，常开安全输出打开，负载断电。注意：安全触点上的新端子连接。控制单元配置为监控手动复位。按下并释放复位按钮，为负载通电。踩在任何垫子上都会导致安全输出打开并切断负载的电源。离开垫子后，必须按下并释放重置按钮，以重新给负载通电。注：罗克韦尔自动化出版物95302194/EO:0240发布号：8 19 440F MatGuard安全输出上的新终端连接™ Mat Manager用户手册第5节-安装设计图16图17显示了440F-C28013的示例连接图。电路条件如下：电源开启；传感器垫上不存在，常开安全输出打开，负载断电。控制单元配置为监控手动复位。按下并释放复位按钮，为负载通电。踩在任何垫子上都会导致安全输出打开并切断负载的电源。离开垫子后，必须按下并释放重置按钮，以重新给负载通电。440F护垫™ Mat Manager用户手册第5节-安装设计20罗克韦尔自动化出版物95302194/EO:0240发行号：8）图17图18显示了440F-C28021和440F-C2802 3的示例连接图。电路条件如下：电源开启，传感器垫上不存在，常开安全输出断开，负载断电。控制单元配置为自动/手动复位。
The terminal positions are given in section 6.2 and ratings are given in section 4. Note: Duplex sleeves required if two wires are connected to one terminal. 1 2 6 4 5 1 3 440F MatGuard™ Mat Manager User Manual Section 5 - Installation Design 18 Rockwell Automation Publication 95302194/EO:0240 Issue No: 8) The Allen-Bradley Guardmaster system may be used as the sole protective measure or in combination with other measures or devices (e.g. safety light curtain, system of work). Figure 15 shows an example connection diagram for the 440F-C28011. The circuit conditions are as follows: supply power is ON; no presence on the sensor mats, the normally open safety outputs are open and the loads are de-energized. The Control Unit is configured for Monitored Manual reset. Press and release the reset button to energize the loads. Stepping on any of the mats will cause the safety outputs to open and remove power to the loads. After stepping off the mat, the reset button must be pressed and released to re-energize the loads. Figure 15 Figure 16 shows an example connection diagram for the 440F-C28012. The circuit conditions are as follows: supply power is ON; no presence on the sensor mats, the normally open safety outputs are open and the loads are de-energized. Note: new terminal connection on the safety contacts. The control unit is configured for monitored manual reset. Press and release the reset button to energize the loads. Stepping on any of the mats will cause the safety outputs to open and remove power to the loads. After stepping off the mat, the reset button must be pressed and released to re-energize the loads. Note: New terminal connection on the safety outputs Rockwell Automation Publication 95302194/EO:0240 Issue No: 8 19 440F MatGuard™ Mat Manager User Manual Section 5 - Installation Design Figure 16 Figure 17 shows an example connection diagram for the 440F-C28013. The circuit conditions are as follows: supply power is ON; no presence on the sensor mats, the normally open safety outputs are open and the loads are de-energized. The control unit is configured for monitored manual reset. Press and release the reset button to energize the loads. Stepping on any of the mats will cause the safety outputs to open and remove power to the loads. After stepping off the mat, the reset button must be pressed and released to re-energize the loads. 440F MatGuard™ Mat Manager User Manual Section 5 - Installation Design 20 Rockwell Automation Publication 95302194/EO:0240 Issue No: 8) Figure 17 Figure 18 shows an example connection diagram for the 440F-C28021 and the 440F-C28023. The circuit conditions are as follows: supply power is ON, no presence on the sensor mats, the normally open safety outputs are open and the loads are deenergized. The control unit is configured for automatic/manual reset.
