PM825-1 3BSE010800R1数控系统模块
140MT D型机架的额定值和应用范围（抽头导体保护和E型额定值）•与现有产品线相比，热性能有所改善（热损失更低）•不同的产品变体（MCP、高涌入型、驱动器输出时应用的D9V）由单机架尺寸（D）覆盖。•可锁定旋钮和防篡改护罩是140MT D型框架的标准产品•连接模块和组合SCCR与100-E、100-C和100-K接触器一起测试•140MT和140UT Core i3 140MT C型和D型框架以及140UT 140M C型和D-型框架的反馈能力，和140U公告140M至140MT电机保护断路器和电机电路保护器公告140U至140UT塑壳断路器140M至140 MT目录号转换注释：现有产品和新产品之间的交叉参考表可以是直接*或功能**或工程***替换，具体取决于电压额定值、短路额定值、，应用等级以及现有140M产品的安装或应用方式。更多信息请参考技术数据出版物140-TD005。140M F框架产品及其相关配件仍处于活动状态。140M-C现有140MT-C新产品140U-D6D3-C30 140UT-D7D3-C302-140UT-D7D3-C352-140UT-D-7D3-C402更换类别定义：*直接更换（DR）：无需用户修改或调整即可替代早期产品的产品。直接替换通过模仿早期产品提供向后兼容的形式、配合和功能**功能性替换（FR）：可用于替换早期产品或系列的产品或系列，并在对现有应用程序进行最小更改的情况下模仿旧产品或系列。功能替换意味着存在形式、配合或功能更改，但它是向后兼容的***工程替换（ER）：可用于移植早期产品或系列的产品或系列，需要对现有应用程序进行工程更改。工程更换意味着应用程序的形状、配合或功能发生变化
ratings and application coverage (tap conductor protection and Type E ratings) for 140MT D-frame • Improved thermal performance compared to existing product line (lower heat loss) • Different product variants (MCP, High inrush version, D9V for application at output of Drives) are covered by single frame size (D). • Lockable knob and anti-tamper shield as standard offering for 140MT D-frame • Connecting modules and Combination SCCR tested with 100-E, 100-C and 100-K contactors • Back feeding capability for 140MT and 140UT Core i3 140MT C- and D-frame, and 140UT 140M C- and D-frame, and 140U Bulletin 140M to 140MT Motor Protection Circuit Breaker and Motor Circuit Protectors Bulletin 140U to 140UT Molded Case Circuit Breakers 140M to 140MT Catalog Number Conversion NOTE: Cross reference tables between existing and new product can be Direct* or Functional** or Engineered*** replacement depending on voltage ratings, short circuit ratings, application ratings and how existing 140M products are installed or applied. Please refer to technical data publication 140-TD005 for additional information. 140M F-frame products and their associated accessories remain active. 140M-C Existing 140MT-C New product140U-D6D3-C30 140UT-D7D3-C302 - 140UT-D7D3-C352 - 140UT-D7D3-C402 Definition of replacement categories: *Direct Replacement (DR): a product that can be used in place of an earlier product without any user modifications or adjustments. A direct replacement provides backward compatible form, fit and function by emulating the earlier product. **Functional Replacement (FR): a product or family that can be used to replace an earlier product or family and emulates the old one with minimal changes to an existing application. A functional replacement means that there is a form, fit or function change, but that it is backward compatible. ***Engineered Replacement (ER): a product or family that can be used to migrate an earlier product or family and requires engineering changes to existing applications. An engineered replacement means that there is a form, fit or function change of the application
