本文件中使用的所有品牌名称和产品名称均为其各自持有人的商标或注册商标。版权所有©2018 Prolific Technology Inc.保留所有权利。未经Prolific Technology Inc.Bulletin 931 Signal Conditioners 22 www.ab.com/catalogs Publication 931-TD001B-EN-P RTD Signal Conditioners Passive Converter明确书面许可，不得以任何方式复制或传播本文件的任何部分，PT100/RTD用于两个或三个导体PT100传感器环路馈电输出电流高精度和线性931H-P2A2N-OP规范无源转换器，PT100/RTD接线图标准符合UL 508、CSA C22.2 No.142-M1987、CSA C22.2No.0-10、CSA C22.2.No.14-10、EN 50178:1997、EN 61000-6-1:2007、EN 6100-6-2:2005、EN 61000-16-3:2007、，EN 61000-6-4:2007认证cURus（NRAQ2/8.E113724）、CSA、CE输入额定值传感器PT100/2-/3导体（符合IEC 751）温度输入范围0°C…+200°C输入无源输出额定值电流4…20 mA负载阻抗（电压/电流）-/≤ 600Ω精度典型值为FSR阶跃响应时间的0.2%，最大值为0.5%10 ms输出无源通用规范电源电压9…30V DC电源型输出回路供电工作温度0°C…+50°C存储温度-20°C…+85°C连接型张力夹L x W x H（mm）91 x 6 x 93.2类信号调节器。数量Pkg。数量931H-P2A2N-OP 1端部屏障（必需）931H-EB1 10文件控制编号：931-CT001C-EN-E 1/2 EU合格产品声明：模拟信号调节器制造商名称和地址：美国威斯康星州密尔沃基南二街1201号罗克韦尔自动化公司，邮编53204。授权代表的姓名和地址：罗克韦尔自动化公司Pegasus Park De Kleetlaan 12A 1831 Diegem Belgium本符合性声明由制造商全权负责发布。声明对象：Allen-Bradley 931H、931S和931U系列（参考随附的目录号列表）上述声明对象符合相关欧盟协调立法：2014/35/EU LowAll brand names and product names used in this document are trademarks or registered trademarks of their respective holders. Copyrights Copyright © 2018 Prolific Technology Inc. All rights reserved. No part of this document may be reproduced or transmitted in any form by any means without the express written permission of Prolific Technology Inc.Bulletin 931 Signal Conditioners 22 www.ab.com/catalogs Publication 931-TD001B-EN-P RTD Signal Conditioners Passive Converter, PT100/RTD For two or three conductor PT100 sensors Loop-fed output current High accuracy and linearity 931H-P2A2N-OP Specifications Passive Converter, PT100/RTD Wiring Diagram Standards Compliance UL 508, CSA C22.2 No. 142-M1987, CSA C22.2 No. 0-10, CSA C22.2 No. 14-10, EN 50178:1997, EN 61000-6-1:2007, EN 61000-6-2: 2005, EN 61000-6-3:2007, EN 61000-6-4:2007 Certifications cURus (NRAQ2/8.E113724), CSA, CE Input Ratings Sensor PT100/2-/3-conductor (to IEC 751) Temperature Input Range 0 °C…+200 °C Input Passive Output Ratings Current 4...20 mA Load Impedance (voltage/current) — / ≤ 600 Ω Accuracy typical 0.2%, max. 0.5% of FSR Step Response Time 10 ms Output Passive General Specifications Supply Voltage 9...30V DC Power Type Output Loop Powered Operating Temperature 0 °C…+50 °C Storage Temperature -20 °C…+85 °C Connection Type Tension Clamp L x W x H (mm) 91 x 6 x 93.2 Signal Conditioner Cat. No. Pkg. Quantity 931H-P2A2N-OP 1 End Barrier (required) 931H-EB1 10Document Control Number: 931-CT001C-EN-E 1 / 2 EU Declaration of Conformity Product: Analogue Signal Conditioners Name and address of the manufacturer: Rockwell Automation Inc. 1201 South 2nd Street Milwaukee, WI 53204 U.S.A. Name and address of the authorised representative: Rockwell Automation NV Pegasus Park De Kleetlaan 12A 1831 Diegem Belgium This declaration of conformity is issued under the sole responsibility of the manufacturer. Object of the declaration: Allen-Bradley 931H, 931S and 931U Series (reference the attached list of catalogue numbers) The object of the declaration described above is in conformity with the relevant Union harmonisation legislation: 2014/35/EU Low
