MOTOROLA MVME5500 自动化模块备件
最大罗克韦尔自动化出版物1370-TD001C-EN-P-2013年12月5直流回路接触器、接触器凸耳和动态制动器1370直流回路接触器近似安装尺寸和重量额定电流（续安培）电线杆目录号尺寸-mm（in.）重量A B C DE J kg（lbs.）56 2-N.O。，1-第1370-DC56 90.4（3.56）152.4（6.00）113.5（4.47）35.0（1.38）139.7（5.50）12.7（0.5）1.4（3.0）110 2号，1-第1370-DC110 100.1（3.94）173.0（6.81）117.6（4.63）40.1（1.58）160.3（6.31）12.7（1.5）1.8（4.0）180 2号，1-N.C.1370-DC180 155.7（6.13）255.0（10.04）154.7（6.09）69.8（2.75）220.0（8.66）16.3（0.64）5.4（12.0）280 2-未注明。，1-N.C.1370-DC280 177.8（7.00）289.6（11.40）194.6（7.66）80.3（3.16）250.0（9.84）20.0（0.79）10.0（22.0）E B D A C D J 6罗克韦尔自动化出版物1370-TD001C-EN-P-2013年12月直流回路接触器、接触器凸耳和动态制动器1370凸耳套件1370凸片套件提供所需的凸耳，以终止1370直流回路接触器上的电线。正确安装后，接线片将提供一个安全且耐气体的终端。吊耳套件包含（2）DB吊耳和（4）电枢线和负载吊耳。安装接线片时，需要使用经过UL认证的压接工具。有关适当压接工具和方法的信息，请参阅接线片制造商的规范。目录编号说明位置1 23 1370–LG 40 a bc a产品代码类型1370 DC组件b设备代码描述LG接线片套件c接线片额定电流代码最大电机电流40 40 52 56 68 68 92 104 110 120 140 160 180 204 204 228 228 248 268 280 280罗克韦尔自动化出版物1370-TD001C-EN-P-2013年12月7 DC回路接触器，
maximum Rockwell Automation Publication 1370-TD001C-EN-P - December 2013 5 DC Loop Contactors, Contactor Lugs and Dynamic Brakes 1370 DC Loop Contactors Approximate Mounting Dimensions and Weights Current Rating (Cont. Amps) Power Poles Catalog Number Dimensions - mm (in.) Weight A B C DE J kg (lbs.) 56 2 - N.O., 1 - N.C. 1370-DC56 90.4 (3.56) 152.4 (6.00) 113.5 (4.47) 35.0 (1.38) 139.7 (5.50) 12.7 (0.5) 1.4 (3.0) 110 2 - N.O., 1 - N.C. 1370-DC110 100.1 (3.94) 173.0 (6.81) 117.6 (4.63) 40.1 (1.58) 160.3 (6.31) 12.7 (0.5) 1.8 (4.0) 180 2 - N.O., 1 - N.C. 1370-DC180 155.7 (6.13) 255.0 (10.04) 154.7 (6.09) 69.8 (2.75) 220.0 (8.66) 16.3 (0.64) 5.4 (12.0) 280 2 - N.O., 1 - N.C. 1370-DC280 177.8 (7.00) 289.6 (11.40) 194.6 (7.66) 80.3 (3.16) 250.0 (9.84) 20.0 (0.79) 10.0 (22.0) E B D A C D J 6 Rockwell Automation Publication 1370-TD001C-EN-P - December 2013 DC Loop Contactors, Contactor Lugs and Dynamic Brakes 1370 Lug Kits 1370 Lug Kits provide the required lugs to terminate wires on 1370 DC Loop Contactors. When properly installed, the lugs will provide a secure and gas-resistant termination. The Lug Kit contains (2) DB Lugs and (4) Armature Line and Load Lugs. A crimp tool that is UL certified is required to install the lugs. Please see the lug manufacturer’s specifications for information on the appropriate crimp tools and methods. Catalog Number Explanation Position 1 23 1370 – LG 40 a bc a Product Code Type 1370 DC Component b Device Code Description LG Lug Kit c Lug Current Rating Code Max. Motor Amps 40 40 52 52 56 56 68 68 92 92 104 104 110 110 120 120 140 140 160 160 180 180 204 204 228 228 248 248 268 268 280 280 Rockwell Automation Publication 1370-TD001C-EN-P - December 2013 7 DC Loop Contactors,
