IC695CPU315-CD工控模块机器人备件
最低光束z2H+1 z2H+1 z 3H–区域3最高光束3n/4 3n/4 z4L–区域4最低光束z3H+1 z3H+1 z 4H–区域4最高光束n n光束计数模式0=第一光束电缆侧注意：通过正确接地或分流以及使用静电控制包装和材料搬运产品，帮助保护控制器免受ESD的影响。通过接地、电离和使用导电和耗散静电控制材料来耗散和中和。重要信息：只有使用悬挂检测的应用程序才需要设置载体区域。对于其他应用程序，按“设定”按钮跳过此步骤。8罗克韦尔自动化出版物45MLA-IN002C-EN-P-2020年8月45MLA控制器安装说明4.超高超高输出（Out 2）是一个离散的开关输出，在任何光束中断时默认激活。（默认光束oh=光束1）要设定超高级别，请将允许的最高对象放置在灯光阵列的范围内，然后短按“设定”按钮。状态指示器D14现在应该保持亮起，这表明现在已经设置了允许的最高物体光束。下一个不间断光束被设置为“哦”光束。在该设定过程结束时，如果任何以“oh”或更高开头的光束被中断，则超高输出（Out 2）被激活。5.配置区域如果此时不希望配置特定区域，请按住“设定”按钮，直到状态指示器D14熄灭（约5秒），这表示设定过程结束。如果您希望配置感应区域（对应于输出3…6），请短按“设定”按钮进入区域设置并遵循以下步骤
Lowest beam z2H+1 z2H+1 z3H – Zone 3 Highest beam 3n/4 3n/4 z4L – Zone 4 Lowest beam z3H+1 z3H+1 z4H – Zone 4 Highest beam n n Beam counting mode 0 = first beam cable side ATTENTION: Help protect the controller from ESD with proper grounding or shunting and the use of static control packaging and materials handling products. Dissipate and neutralize by grounding, ionization, and the use of conductive and dissipative static control materials. IMPORTANT Setting the carrier zone is only required for applications that use over-hang detection. For other applications, press the Teach button to skip this step. 8 Rockwell Automation Publication 45MLA-IN002C-EN-P - August 2020 45MLA Controller Installation Instructions 4. Over-height The over-height output (Out 2) is a discrete on-off output that is activated by default when any beam is interrupted. (Default Beam oh = Beam 1) To teach the over-height level, place the highest allowed object in the range of the light array and then briefly press the Teach button. Status indicator D14 should now remain on, which indicates that the highest allowed object beam has now been set. The next uninterrupted beam is set as the “oh” beam. At the conclusion of this teach process, if any beam starting with “oh” and higher is interrupted, the over-height output (Out 2) is activated. 5. Configure zones If you do not wish to configure specific zones at this point, press and hold the Teach button until status indicator D14 turns off (approximately 5 seconds), which signals the end of the teach process. If you wish to configure sensing zones (corresponding to Outputs 3…6), press the Teach button briefly to enter the zone setup and follow these
