WOODWARD 9907-126工控模块系统备件
这些面板安装设备
提供带有电阻触摸屏和CompactFlash固态驱动器的12英寸显示器。通过将工业硬化显示器和计算机结合在一台机器中，这些面板安装的计算机在一个机箱和目录号中提供了完整的解决方案。因为没有外部显示电缆或单独的组件安装要求，所以简化了系统集成。12自动化出版物6181X-UM001C-EN-P-2015年7月第1章功能操作系统提供以下Microsoft许可的操作系统：•Windows 7 Professional（32位）、Service Pack 1•Windows XP Professional、，带有Windows XP Professional操作系统的Service Pack 3计算机•除Service Pack 3外，未对出厂映像应用任何操作系统更新。•Microsoft Windows的I386源目录位于计算机的系统驱动器上，而不是根目录C:\I386，以便于删除和添加Windows组件。这些计算机具有固态驱动器，因此不包含恢复分区。如果需要额外的驱动器空间
请执行以下步骤：
a.将I386目录复制到外部介质。b、 从C:\I386中删除I386目录以获得400 MB的空间。这些固态硬盘经过定制以适应其独特的属性，如下所示：•无分页文件•默认情况下禁用系统还原要获取出厂系统映像的副本，请联系当地技术支持中心或访问自动化产品兼容性和下载中心（PCDC），网址：http://www.rockwellautomation.com/support/pcdc.page.计算机选项本表总结了用于危险场所的集成显示工业计算机的可用选项。计算机功能的比较总结见第57页附录A“技术规格”。No.型号系列显示器尺寸（英寸）触摸屏功能第1章在打开计算机之前，检查装运纸箱是否损坏。如果发现损坏，请立即联系发货人并请求协助。否则，继续打开包装。
These panel mounted devices
A 12 inch display with resistive touch screen and CompactFlash solid-state drive is available. By combining the industrial hardened display and computer in one machine, these panel mounted computers provide a complete solution in one chassis and catalog number. System integration is simplified because there are no external display cables or separate component installation requirements. 12 Automation publication 6181X-UM001C-EN-P-2015 July Chapter 1 Functional Operating System The following Microsoft licensed operating systems are available: • Windows 7 Professional (32-bit), Service Pack 1 • Windows XP Professional, Service Pack 3 computers with Windows XP Professional operating system • No operating system updates are applied to the factory image except for Service Pack 3. • The I386 source directory of Microsoft Windows is located on the system drive of the computer, not the root directory C: I386, to facilitate the removal and addition of Windows components. These computers have solid state drives and therefore do not include recovery partitions. If additional drive space is required
Please perform the following steps:
a. Copy the I386 directory to external media. b. Remove the I386 directory from C: I386 to obtain 400 MB of space. These SSDs are customized to suit their unique attributes, as follows: • No paging files • System Restore is disabled by default To obtain a copy of the factory image, contact your local technical support center or visit the Automated Product Compatibility and Download Center (PCDC) at: http://www.rockwellautomation.com/support/pcdc.page. Computer optionsThis table summarizes the available options for an integrated display industrial computer for use in hazardous locations. The comparison of computer functions is summarized in Appendix A "Technical Specifications" on page 57. No. Model Series Display Dimensions (Inches) Touch Screen FunctionChapter 1 Before turning on the computer, check the shipping carton for damage. If damage is found, please contact the shipper immediately and ask for assistance. Otherwise, continue to open the package.
