ABB 086444-003备件模块
封闭安装期间
它是一个保护前部的盖子，也可以防止钥匙被篡改。在封闭安装期间，如果未安装但带有前保护罩，则设置器的面板安装空间为105 mm或更大。15-2.接触保护元件接触保护元件连接到设置器的继电器输出端子，以抑制噪声。始终通过触点保护元件和缓冲继电器在继电器输出（如ON-OFF脉冲型、ON-OFF伺服型和报警输出）中进行加载和布线。下面所示的接触保护元件也可用于我们公司，请使用您需要的型号。型号规格开合电流应用CX-CR1 0.01μF+120Ω小于0.2A对于轻负载CX-CR2 0.5μF+47Ω0.2A或更大对于重负载在使用时，泄漏电流根据负载电源而流动，如下所示，因此要小心。电源电压：200V电源电压：100V型号
参数列表
参数未链接到程序模式]模式号设置项默认值（出厂时）客户设置值设置范围SV 0000.0 SV范围执行SV和时间0时间000:00 000:00至999:59 SV校正000.00至199.99至200.00运行操作键锁定UNLOCK UNLOCK、lock程序驱动系统MASTER key MASTER key、MASTER EXT SLAVE EXT、，MASTER COM MASTER FREE模式选择系统KEY KEY、EXT、COM、FREE Time显示系统PASS STEP PASS STER、PASS PATERN REMAIN STEP REMAIN PATERN1启动电源时操作CONTINUE CONTINU、RESET SV范围0000.0至2000.0-1999.9至3000.0模式清除END EACH（01至30），所有模式复制END PTN:（01到30）→ （01至30），重置0000.0 SV范围2期间为YES
During closed installation
It is a cover that protects the front and also prevents the key from being tampered with. During closed installation, if the front protective cover is not installed, the panel installation space of the setter is 105 mm or more. 15-2. Contact protection element The contact protection element is connected to the relay output terminal of the setter to suppress noise. Always load and wire relay outputs (such as ON-OFF pulse type, ON-OFF servo type and alarm output) through contact protection elements and buffer relays. The contact protection elements shown below can also be used in our company. Please use the model you need. Model Specification Switching current application CX-CR1 0.01 μ F+120 Ω less than 0.2A for light load CX-CR2 0.5 μ F+47 Ω 0.2A or greater When using heavy load, the leakage current flows according to the load power supply, as shown below, so be careful. Power supply voltage: 200V Power supply voltage: 100V model
Parameter list
Parameter not linked to program mode] Mode number setting item default value (ex factory) Customer setting value setting range SV 0000.0 SV Range execution SV and time 0 Time 000:00 000:00 to 999:59 SV correction 000.00 to 199.99 to 200.00 Running operation keys lock UNLOCK UNLOCK, lock Program driver system MASTER key MASTER key, MASTER EXT SLAVE EXT, MASTER COM MASTER FREE Mode selection system KEY KEY, EXT, COM FREE Time Display System PASS STEP PASS STER, PASS PATERN REMAIN STEP REMAIN PATERN1 Operate CONTINUE CONTINU, RESET SV range 0000.0 to 2000.0-1999.9 to 3000.0 mode Clear END EACH (01 to 30), all modes copy END PTN: (01 to 30) → (01 to 30), RESET 0000.0 SV Range 2 is YES
