CM572-DP工控DCS系统备件
面板切口和安装方法
１．常规安装方法① 将此产品插入面板切口。② 安装上下连接的安装支架，用螺丝刀拧紧螺钉并将其固定。拧紧螺钉时，扭矩为“0.6–0.8 Nm”。③ 对于IP54面板密封规格，请确认产品和面板之间的垫片正确。小心，因为如果垫片漂移或有间隙，安装不正确，防水功能不起作用。面板切割单位：mm 2.封闭式仪表① 将此产品插入面板切口。② 安装上下连接的安装支架，用螺丝刀拧紧螺钉并将其固定。拧紧螺钉时，扭矩为“0.6-0.8 Nm”。③ 在封闭式仪表时，即使在IP54面板密封规格的产品中，由于产品和面板之间的垫片功能丧失，防水功能也不起作用。单位：mm N：已安装仪表的数量封闭仪表的面板切口 面板安装支架控制器 安装条件预防措施为了避免事故，请务必阅读并理解这些内容。1.环境① 在一个房间里。② 远离阳光直射。③ 远离高温。④ 远离振动和冲击。⑤ 远离液体（水等）。⑥ 远离冷凝。⑦ 根据EN标准，在“过电压类别II，污染等级2”下。
2.大气
① 远离强噪声、静电、电场、磁场等。② 环境温度在-10至50°C（如果是封闭式仪表，则低于40°C），环境湿度在10-90%RH范围内。③ 温度变化较小。④ 远离腐蚀性气体、爆炸性气体、引燃气体和可燃气体。⑤ 远离盐、铁和导电材料（碳、铁等）。⑥ 远离蒸汽、油和化学品等。⑦ 远离灰尘等。⑧ 远离产生高温的环境。⑨ 远离储存温度的地方。⑩ 产品上部上方的大量空间。⑪ 远离风。3.安装位置① 安装高度低于海平面2000米② 安装位置约为1.5m（约为人的眼睛水平位置）。③ 安装方向纵向倾斜度小于±10°横向倾斜度大于±10°。4.其他① 不要用有机溶剂（如酒精）擦拭固定器。② 为避免设置器出现故障，请勿在其附近使用手机。③ 可能会对设置在设置器附近的电视机和收音机造成障碍。-9-4-3.接线4-3-1.端子号和功能根据产品规格，也有未提供端子螺钉的地方。1.电源端子① 通用电源规格端子号⑨ ⑩ Ⓝ ⑪ Ⓛ ② 24V电源规格24V DC端子号 （50/60Hz）选项端子1区2区3区接地端子和电源端子 模拟数字输出（50/60 Hz） 24VAC 24VDC＋－10－1.
Panel cut and installation method
1. Conventional installation method ① Insert the product into the panel notch. ② Install the upper and lower mounting brackets, tighten the screws with a screwdriver and fix them. When tightening the screws, the torque is "0.6 – 0.8 Nm". ③ For IP54 panel sealing specification, please confirm that the gasket between the product and the panel is correct. Be careful, because if the gasket drifts or has clearance and is installed incorrectly, the waterproof function will not work. Panel cutting unit: mm 2. Enclosed instrument ① Insert the product into the panel notch. ② Install the upper and lower mounting brackets, tighten the screws with a screwdriver and fix them. When tightening the screws, the torque is "0.6-0.8 Nm". ③ In the case of enclosed instrument, even in the products with IP54 panel sealing specification, due to the loss of gasket function between the product and the panel, the waterproof function does not work. Unit: mm N: number of installed instruments Panel cutouts Panel mounting brackets Panel mounting conditions Preventive measures To avoid accidents, please be sure to read and understand these contents. 1. Environment ① In a room. ② Keep away from direct sunlight. ③ Keep away from high temperatures. ④ Keep away from vibration and shock. ⑤ Keep away from liquids (water, etc.). ⑥ Keep away from condensation. ⑦ According to EN standard, under "overvoltage category II, pollution class 2".
2. Atmosphere
① Keep away from strong noise, static electricity, electric field, magnetic field, etc. ② The ambient temperature is - 10 to 50 ° C (lower than 40 ° C if it is a closed instrument), and the ambient humidity is within the range of 10-90% RH. ③ The temperature change is small. ④ Keep away from corrosive gas, explosive gas, ignition gas and combustible gas. ⑤ Keep away from salt, iron and conductive materials (carbon, iron, etc.). ⑥ Keep away from steam, oil, chemicals, etc. ⑦ Keep away from dust, etc. ⑧ Keep away from high temperature environment. ⑨ Keep away from storage temperature. ⑩ A large amount of space above the upper part of the product. ⑪ Stay away from the wind. 3. Installation position ① The installation height is 2000m lower than the sea level ② The installation position is about 1.5m (about the eye level). ③ The longitudinal inclination in the installation direction is less than ± 10 °, and the transverse inclination is more than ± 10 °. 4. Others ① Do not wipe the fixator with organic solvent (such as alcohol). ② To avoid failure of the setter, do not use the phone near it. ③ The TV and radio set near the setter may be obstructed- 9-4-3. Wiring 4-3-1. The terminal number and function are based on the product specification, and there are some places where terminal screws are not provided. 1. Power supply terminal ① General power supply specification terminal number ⑨ Ω ⑩ ⓃⓁ ② 24V power supply specification 24V DC terminal number (50/60Hz) Option terminal 1 Zone 2 Zone 3 Ground terminal and power supply terminal analog digital output (50/60Hz) 24VAC 24VDC ＋－ 10 － 1
