CI854A模块卡件
高完整性I/O模块模块
只能连接到AC 800M控制器PM865。通过TB840（非TB820）直接连接到模块总线和光学模块总线。文章编号：AI880A高完整性模拟输入。单个或冗余HART。4..20 mA，8通道电流输入。HART通信。SIL3认证。需要根据安全手册进行配置。3BSE039293R1 DI880高完整性数字输入。单个或冗余24 V直流，16通道24 V直流输入。SIL3认证。需要根据安全手册进行配置。3BSE028586R1 DO880高完整性数字输出。单个或冗余24 V直流，16通道0.5 A输出。SIL3认证。需要根据安全手册进行配置。高完整性800xA系统需要3BSE028602R1 SS823投票设备。每个电源单元一个，也在冗余配置中。3BSE038226R1 58 S800 I/O | System 800xA产品目录模块终端装置模块终端装置产品编号TU805K01终端装置，用于DI801和DO801的两线或三线连接，包括10个终端装置TU805。50 V.3BSE013230R1 TU811V1紧凑型模块终端装置，MTU，250 V.1 x 8信号端子，额定绝缘。250 V 3BSE013231R1 TU812V1紧凑型模块终端装置，MTU，50 V，带25针D-sub连接器，额定绝缘。50 V D-sub（母）连接器未封闭。3BSE013232R1 TU813紧凑型模块终端装置，MTU，250 V，2 x 8信号端子，额定绝缘。250 V可拆卸（可插拔）连接器。3BSE036714R1 TU814V1紧凑型模块终端装置，MTU，50 V，2 x 8信号端子，额定绝缘。50 V可拆卸（可插拔）连接器。3BSE013233R1 TU818紧凑型模块终端装置，MTU，50V 2x16信号端子，额定绝缘。50V注：在价格手册发布时，此项目需要订购TSA。订购前，请在TSA数据库中检查TSA的当前需求。
紧凑型模块终端装置
3BSE069209R1 TU819紧凑型模块终端装置，MTU，50V。带2x25针D-sub连接器，额定绝缘。50V，D-sub（母）连接器未随附注：在价格手册发布时，此项目需要订购TSA。订购前，请在TSA数据库中检查TSA的当前需求。3BSE068891R1 TU830V1扩展模块终端装置，MTU，50 V，2 x 16信号端子，额定绝缘。50 V.3BSE013234R1 TU831V1扩展模块终端装置，MTU，250 V.2 x 8信号端子，额定绝缘。250 V.3BSE013235R1 TU833扩展模块终端装置，MTU，50 V.2 x 16信号端子，额定绝缘。50 V弹簧笼端子。3BSE038726R1 TU834扩展模块终端装置，MTU 50 V，与AI880/AI880A一起使用。额定绝缘。不包括50 V分流棒。3BSE040364R1 TU835V1扩展模块终端装置，MTU，50 V，8个带保险丝的电源插座，8个信号端子，额定绝缘。50 V.3BSE013236R1 TU836V1扩展模块终端装置，MTU，250 V.2 x 4保险丝信号，2 x 4返回端子，2 x 2 L 2 x 2 N端子，额定绝缘。250 V.3BSE013237R1 TU837V1扩展模块终端装置，MTU，250 V.8 x 1保险丝绝缘。信号，8 x 1 L端子，2 x 6 N端子，额定绝缘。250 V.3BSE013238R1 TU838扩展模块终端装置，MTU，50 V.2 x 4保险丝传感器电源插座，16个信号端子，2 x 4个回路端子，2×2 L+，2 x 2 L-端子，额定绝缘。50 V模块水平安装。3BSE008572R1 TU839扩展模块终端装置，250 V，2 x 8信号端子。2 x 4保险丝传感器电源。额定绝缘。250伏。3BSE046966R1系统800xA产品目录| S800 I/O 59模块终端单元模块终端单元产品编号TU842模块终端单元，MTU，用于冗余应用，50 V。用于AO845、DI840、DO840。水平安装DIN导轨。额定绝缘。50 V.3BSE020850R1 TU843模块终端装置，MTU，用于冗余应用，50 V.用于AO845、DI840、DO840。垂直安装的DIN导轨。额定绝缘。50 V.3BSE021443R1 TU844模块终端装置，MTU，用于冗余应用，50 V.与AI845、AI880和DP840一起使用。水平安装DIN导轨。额定绝缘。不包括50 V分流棒。3BSE021445R1 TU845模块终端装置，MTU，用于冗余应用，50 V。与AI845、AI880A和DP840一起使用。垂直安装的DIN导轨。额定绝缘。不包括50 V分流棒。3BSE021447R1 TU850扩展模块终端装置，MTU，50 V，2 x 8信号端子和2 x 8可断开限流传感器/变送器出口电源端子。额定绝缘。50 V 3BSE050930R1 TU851扩展模块终端装置，MTU，250V 2x16信号端子，额定绝缘。250伏。注：在价格手册发布时，此项目需要订购TSA。订购前，请在TSA数据库中检查TSA的当前需求。3个068782r1
High integrity I/O module
Only connect to the AC 800M controller PM865. It is directly connected to the module bus and optical module bus through TB840 (not TB820). Article No.: AI880A High Integrity Analog Input. Single or redundant HART. 4.. 20 mA, 8-channel current input. HART communication. SIL3 certification. It needs to be configured according to the safety manual. 3BSE039293R1 DI880 high integrity digital input. Single or redundant 24 VDC, 16 channel 24 VDC input. SIL3 certification. It needs to be configured according to the safety manual. 3BSE028586R1 DO880 high integrity digital output. Single or redundant 24 V DC, 16 channel 0.5 A output. SIL3 certification. It needs to be configured according to the safety manual. The high integrity 800xA system requires 3BSE028602R1 SS823 voting equipment. One for each power supply unit, also in redundant configuration. 3BSE038,226R1 58 S800 I/O | System 800xA product catalog module terminal device module terminal device product number TU805K01 terminal device, used for two or three wire connection of DI801 and DO801, including 10 terminal devices TU805. 50 V.3BSE013230R1 TU811V1 compact module terminal unit, MTU, 250 V.1 x 8 signal terminals, rated insulation. 250 V 3BSE013231R1 TU812V1 compact module termination unit, MTU, 50 V, with 25 pin D-sub connector, rated insulation. The 50 V D-sub (female) connector is not closed. 3BSE013232R1 TU813 compact module terminal unit, MTU, 250 V, 2 x 8 signal terminals, rated insulation. 250 V detachable (pluggable) connector. 3BSE036714R1 TU814V1 compact module terminal unit, MTU, 50 V, 2 x 8 signal terminals, rated insulation. 50 V detachable (pluggable) connector. 3BSE013233R1 TU818 compact module terminal unit, MTU, 50V 2x16 signal terminal, rated insulation. 50V Note: TSA needs to be ordered for this project when the price manual is released. Before ordering, please check the TSA's current requirements in the TSA database.
Compact module terminal unit
3BSE069209R1 TU819 compact module terminal unit, MTU, 50V. With 2x25 pin D-sub connector, rated insulation. 50V, D-sub (female) connector is not attached with the note: TSA needs to be ordered for this project when the price manual is released. Before ordering, please check the TSA's current requirements in the TSA database. 3BSE068891R1 TU830V1 expansion module terminal unit, MTU, 50 V, 2 x 16 signal terminals, rated insulation. 50 V.3BSE013,234R1 TU831V1 expansion module terminal unit, MTU, 250 V.2 x 8 signal terminals, rated insulation. 250 V.3BSE013235R1 TU833 expansion module terminal unit, MTU, 50 V.2 x 16 signal terminals, rated insulation. 50 V spring cage terminals. 3BSE038726R1 TU834 expansion module terminal unit, MTU 50 V, used with AI880/AI880A. Rated insulation. The 50 V splitter bar is not included. 3BSE040364R1 TU835V1 expansion module terminal unit, MTU, 50 V, 8 fused power sockets, 8 signal terminals, rated insulation. 50 V.3BSE013236R1 TU836V1 expansion module terminal unit, MTU, 250 V.2 x 4 fuse signal, 2 x 4 return terminals, 2 x 2 L 2 x 2 N terminals, rated insulation. 250 V.3BSE013237R1 TU837V1 expansion module terminal unit, MTU, 250 V.8 x 1 fuse insulated. Signal, 8 x 1 L terminal, 2 x 6 N terminal, rated insulation. 250 V.3BSE013238R1 TU838 expansion module terminal unit, MTU, 50 V.2 x 4 fuse sensor power socket, 16 signal terminals, 2 x 4 return terminals, 2 × 2 L+, 2 x 2 L-terminal, rated insulation. The 50 V module is installed horizontally. 3BSE008572R1 TU839 expansion module terminal unit, 250 V, 2 x 8 signal terminals. 2 x 4 fuse sensor supply. Rated insulation. 250 Volts. 3BSE046966R1 system 800xA product catalog | S800 I/O 59 module terminal unit module terminal unit product number TU842 module terminal unit, MTU, for redundant applications, 50 V. Used for AO845, DI840, DO840. Mount the DIN rail horizontally. Rated insulation. 50 V.3BSE020850R1 TU843 module terminal unit, MTU, for redundancy applications, 50 V. for AO845, DI840, DO840. Vertically mounted DIN rail. Rated insulation. 50 V.3BSE021443R1 TU844 module terminal unit, MTU, for redundant applications, 50 V. for use with AI845, AI880 and DP840. Mount the DIN rail horizontally. Rated insulation. The 50 V splitter bar is not included. 3BSE021445R1 TU845 module terminal unit, MTU, for redundant applications, 50 V. Used with AI845, AI880A, and DP840. Vertically mounted DIN rail. Rated insulation. The 50 V splitter bar is not included. 3BSE021447R1 TU850 expansion module terminal unit, MTU, 50 V, 2 x 8 signal terminals and 2 x 8 current limiting sensor/transmitter outlet power terminals can be disconnected. Rated insulation. 50 V 3BSE050930R1 TU851 expansion module terminal unit, MTU, 250V 2x16 signal terminal, rated insulation. 250 Volts. Note: TSA needs to be ordered for this project when the price manual is issued. Before ordering, please check the TSA's current requirements in the TSA database. Three 068,782r1
