Artisan Technology Group-优质仪器。保证|来源| artisantg GE Fanuc信息中心美洲其他资源：有关更多信息，请访问美国亚利桑那州亨茨维尔1（800）322-3616 GE Fanuc嵌入式系统网站：1（256）880-0444 Camarillo，CA 1（805）987-9300 gefanucembedded Greenville，SC 1（864）627-8800 Richardson，TX 1（972）671-1972 Europe，中东和非洲：英国爱丁堡44（131）561-3520法国巴黎33（1）4324-6007©2007 GE Fanuc Automation，股份有限公司。保留所有权利。所有其他品牌或名称均为其各自持有人的财产。Artisan Technology Group-优质仪器。保证|来源| Artisan Technical Group是优质二手设备的独立供应商金标准解决方案，通过我们卓越的服务和支持延长关键工业、商业和军事系统的寿命。我们购买设备计划升级您当前的设备？剩余设备是否占用货架空间？我们会给它一个新家。了解更多！请访问我们的artiantg，了解有关报价、驱动程序、技术规范、手册和文档的更多信息。Artisan Scientific Corporation dba Artisan Technology Group不是本文所列任何制造商的附属公司、代表或授权经销商。我们来这里是为了让你的生活更轻松。今天我们能为您提供什么帮助？（217）352-9330 Isales@artisantgI artisant 12090 South Memorial Parkway，Huntsville，Alabama 35803-3308 1可提供1.1 GHz，1.6 GHz或1.8 GHz奔腾®；M处理器高达2兆字节的高级二级缓存高达1.5兆字节DDR SDRAM高达1兆字节的辅助IDE可引导CompactFlash（请参阅订购选项）内部SVGA和DVI控制器通过P2后I/O 400 MHz系统总线通过Intel®855GME芯片组以太网控制器通过前面板千兆以太网支持10BaseT和100BaseTX控制器支持10BaseT、100BaseTX和1000BaseT接口，可选Vita 31.1支持四个异步16550兼容串行端口四个通用串行总线（USB）2.0版连接，两个在前面板上，两个后I/O PMC扩展站点（PCI-X，66 MHz）32 KB非易失性SRAM操作系统支持Windows®XP、Windows 2000、VxWorks®、QNX®、，LynxOS®和Linux®功能特性微处理器：-7807基于奔腾M处理器系列。
增强型
1.1 GHz和1.6 GHz奔腾M处理器具有1 Mbyte的二级缓存，而1.8 GHz奔奔M处理器具有2 Mbyte二级缓存。奔腾M处理器系列提供的热特性非常适合在各种温度下运行的嵌入式系统。DRAM内存：-7807支持DDR SDRAM，可选ECC支持，最大内存容量为1.5 GB。SDRAM是双端口到VMEbus的。BIOS：系统和视频BIOS提供在可重新编程的闪存中。以太网控制器：-7807使用Intel 82551ER以太网控制器为10/100 Mbyte LAN提供连接。前面板上提供了一个标准RJ45连接器，带有网络状态指示器。第二个以太网接口是双千兆以太网（Intel 82546EB），其中一个连接到前面板，另一个通过P2连接器连接到背板。两个千兆以太网订购选项8月4日，2004 800-007807-000 B A B C D E F-7807–A=处理器1=保留2=1.1 GHz奔腾M 3=1.6 GHz奔奔腾M 4=1.8 GHz奔驰M B=系统DDR SDRAM 0=保留1=512 Mbyte 2=1 Gbyte 3=1.5 Gbyte C=CompactFlash 0=无CompactFlash1=128 Mbyte 2=256 Mbyte3=512 MB byte 4=1 Gbbyte D=连接器P0 0=未安装P0 1=P0（支持千兆以太网和VITA 31.1）E=ECC支持0=无ECC 1=有ECC F=特殊销售订单0=VME标准1=1101.10前面板VME总线后过渡实用板VMIACC-0586和VMIACC-0.590 VMIACC-586和VMIACC-0590安装在VME总线背板的后过渡区域。VMIACC-0586和VMIACC-0.590单独销售。
