3HAC040658-001通用电气卡件
LAN适配器可以配置
为允许访问两个独立的物理网络。每个LAN适配器都能够运行10BaseT和100BaseTX。千兆适配器能够运行1000BaseT。为了优化每个基于PCI的子系统的性能，用户必须在随设备提供的分发光盘上安装驱动程序软件。以下部分提供了在Microsoft Windows 2000 Professional和XP Professional下安装驱动程序的详细说明。D Artisan Technology Group-Quality Instrumentation.Guaranted | SOURCE | artisantg 96 D-7807/RC产品手册Microsoft Windows 2000专业软件驱动程序安装注意：在安装设备驱动程序之前，Windows 2000应更新到Service Pack 4或更高版本。参观http://support.microsoft并搜索最新的Service Pack信息。视频驱动程序安装1.如果尚未安装，请插入Windows驱动程序CD-ROM。2.单击“开始”、“浏览”。在“查找”下拉选择菜单中，选择CD-ROM驱动器。双击“视频”文件夹。双击“win2k_xp141”。单击。3.在“Intel（R）Extreme Chipset Graphics Driver Software”（英特尔（R）至尊芯片集图形驱动程序软件）窗口中，单击。4.在“Intel（R）Ultreme Graphics 2”窗口中，点击。5.单击“”以同意软件许可协议。6.确保选中“，我想立即重新启动计算机”，然后单击“完成”。计算机将重新启动。可以根据需要更改视频分辨率设置。
模拟视频
注：如果只使用模拟视频，请确保在驱动程序中选择“监视器”作为默认视频设备。6300ESB（Hance Rapids）ICH芯片组软件安装1.如果尚未安装，请插入Windows驱动程序CD-ROM。2.单击“开始”、“浏览”。在“查找”下拉选择菜单中，选择CD-ROM驱动器。双击“Hance Rapids”文件夹。双击“Applications”文件夹。双击“ininst_enu”。单击。3.在“英特尔芯片集软件安装实用程序”窗口中，单击。单击“”以同意软件许可协议。单击。在以下每个“硬件安装”窗口中，单击“无论如何继续”。4.确保选中“，我想立即重新启动计算机”，然后单击“完成”。计算机将重新启动。Artisan Technology Group-Quality Instrumentation。保证|来源| artisantg 97 Microsoft Windows 2000 Professional软件驱动程序安装D USB 2.0 EHCI主机控制器根据操作系统和最新service pack的安装方式，USB 2.0控制器驱动程序可能正在运行，也可能未运行。参观http://support.microsoft和在Windows 2000 SP1中搜索USB 2.0支持的可用性，以获取有关此主题的详细信息。要确定USB 2.0控制器的驱动程序是否正在运行，请右键单击“我的电脑”，然后选择“管理”。在“计算机管理”窗口的左侧窗格中，单击“设备管理器”。在右侧窗格中，单击“通用串行总线控制器”旁边的“+”以展开该组。如果组中列出了“标准增强型PCI到USB主机控制器”，则USB 2.0 EHCI主机控制器驱动程序已在运行，设备无需进一步配置。如果在“计算机管理”窗口右窗格的“其他设备”部分下有一个标记为“通用串行总线（USB）控制器”的设备，则该驱动程序尚未安装。要安装驱动程序，右键单击“通用串行总线（USB）控制器”并从下拉菜单中选择“属性”。选择“驱动程序”选项卡，然后选择“更新驱动程序”。当向导启动时，选择并“搜索合适的驱动程序”和“再次下一步”。硬件更新向导将找到相应的驱动程序并自动开始安装。根据需要单击，然后单击“完成”和“关闭”以关闭驱动程序属性对话框。设备管理器将设备重新定位到右侧窗格中的“通用串行总线控制器”部分。以太网适配器驱动程序安装1.如果尚未安装，请插入Windows驱动程序CD-ROM。2.右键单击“我的电脑”，然后选择“管理”。在“计算机管理”窗口的左侧窗格中，单击“设备管理器”。3.Intel（R）PRO/1000 MT双端口服务器适配器。在“计算机管理”窗口右侧窗格的“其他设备”部分下，为每个以太网控制器执行此步骤。右键单击“以太网控制器”并从下拉菜单中选择“属性”。选择“驱动程序”选项卡并选择“更新驱动程序”。
LAN adapter can be configured
To allow access to two independent physical networks. Each LAN adapter can run 10BaseT and 100BaseTX. Gigabit adapters can run 1000BaseT. In order to optimize the performance of each PCI based subsystem, users must install driver software on the distribution CD provided with the device. The following sections provide detailed instructions for installing drivers under Microsoft Windows 2000 Professional and XP Professional. D Artisan Technology Group-Quality Instrumentation. Guaranted | SOURCE | artisantg 96 D-7807/RC Product Manual Microsoft Windows 2000 Professional Software Driver Installation Note: Before installing the device driver, Windows 2000 should be updated to Service Pack 4 or later. visit http://support.microsoft And search for the latest service pack information. Video driver installation 1. If it is not already installed, please insert the Windows driver CD-ROM. 2. Click Start and Browse. From the Find drop-down selection menu, select the CD-ROM drive. Double click the Videos folder. Double click "win2k_xp141". single click. 3. In the Intel (R) Extreme Chipset Graphics Driver Software window, click. 4. In the "Intel (R) Extreme Graphics 2" window, click. 5. Click "" to agree to the software license agreement. "6. Make sure" ", I want to restart my computer now" "is checked, and then click" "Finish" ".". The computer will restart. You can change the video resolution settings as needed.
Analog video
Note: If only analog video is used, make sure Monitor is selected as the default video device in the driver. 6300ESB (Hance Rapids) ICH chipset software installation 1. If not, please insert the Windows driver CD-ROM. 2. Click Start and Browse. From the Find drop-down selection menu, select the CD-ROM drive. Double click the Hance Rapids folder. Double click the Applications folder. Double click "ninst_enu". single click. 3. In the Intel Chipset Software Installation Utility window, click. Click to agree to the software license agreement. single click. In each of the following Hardware Installation windows, click Continue Anyway. 4. Make sure ", I want to restart my computer now" is checked, and then click "Finish". The computer will restart. Artisan Technology Group-Quality Instrumentation。 Guarantee | Source | Artisantg 97 Microsoft Windows 2000 Professional Software Driver Installation D USB 2.0 EHCI Host Controller According to the operating system and the latest service pack installation method, the USB 2.0 controller driver may or may not be running. visit http://support.microsoft And search Windows 2000 SP1 for the availability of USB 2.0 support for more information on this topic. To determine if the USB 2.0 controller driver is running, right-click My Computer and select Manage. In the left pane of the Computer Management window, click Device Manager. In the right pane, click the "+" next to Universal Serial Bus Controllers to expand the group. If the Standard Enhanced PCI to USB Host Controller is listed in the group, the USB 2.0 EHCI Host Controller driver is already running, and the device does not require further configuration. If there is a device labeled Universal Serial Bus (USB) Controller under the Other Devices section in the right pane of the Computer Management window, the driver has not been installed. To install the driver, right-click Universal Serial Bus (USB) Controller and select Properties from the drop-down menu. Select the Drivers tab, and then select Update Driver. When the wizard starts, select and "Search for appropriate drivers" and "Next again". The Hardware Update Wizard will find the appropriate driver and automatically start the installation. Click as needed, and then click Finish and Close to close the driver properties dialog box. The Device Manager relocates the device to the Universal Serial Bus Controller section in the right pane. Ethernet adapter driver installation 1. If not already installed, insert the Windows driver CD-ROM. 2. Right click My Computer and select Manage. In the left pane of the Computer Management window, click Device Manager. 3. Intel (R) PRO/1000 MT dual port server adapter. Perform this step for each Ethernet controller under the Other Devices section in the right pane of the Computer Management window. Right click Ethernet Controller and select Properties from the drop-down menu. Select the Drivers tab and select Update Driver.
