3AFE61320946P0001模块卡件控制器
本手册中使用的安全符号停止
该符号通知操作员不应执行某项操作或程序。操作可能导致人员受伤或死亡，或可能导致部分或全部系统损坏或毁坏。警告：此标志表示危险。它要求注意程序、实践或条件，如果不正确执行或遵守，可能导致人员受伤或死亡。警告：此标志表示危险。它要求注意操作程序、实践或条件，如果不正确执行或遵守，可能导致系统的部分或全部损坏或破坏。注意：提请注意需要重点强调的程序、实践或条件。
安装和设置
内容开箱程序简介本章介绍了硬件跳线设置、连接器说明、安装、系统设置和操作。所有物品应仔细开箱，并彻底检查装运期间可能发生的损坏。应检查电路板是否有损坏的部件、损坏的印刷电路板、热损坏和其他可见污染。因运输损坏而产生的所有索赔应向承运人提交，并向GE Fanuc嵌入式系统客户服务中心发送完整报告，同时请求提供有关损坏物品处置的建议。警告：GE Fanuc嵌入式系统产品上组装的某些组件可能对静电放电敏感，并且可能会在承受高能静电场的电路板上发生损坏。当电路板放置在工作台上进行配置等时，建议在电路板下方插入导电材料，以提供导电分流器。未使用的电路板应存放在装运时的相同保护箱中。
The safety symbol used in this manual stops
This symbol informs the operator that an operation or procedure should not be performed. Operation may result in personal injury or death, or damage or destruction of part or all of the system. Warning: This sign indicates danger. It requires attention to procedures, practices or conditions that, if not properly implemented or followed, may result in personal injury or death. Warning: This sign indicates danger. It requires attention to operating procedures, practices or conditions. If they are not correctly implemented or followed, they may cause partial or total damage or destruction of the system. Note: Draw attention to the procedures, practices or conditions that need to be highlighted.
Installation and setup
Content Introduction to the unpacking procedure This chapter describes the hardware jumper settings, connector instructions, installation, system settings, and operation. All items shall be carefully unpacked and thoroughly inspected for possible damage during shipment. The circuit board should be checked for damaged components, damaged printed circuit boards, thermal damage and other visible contamination. All claims arising from transportation damage shall be submitted to the carrier, and a complete report shall be sent to the GE Fanuc Embedded System Customer Service Center, requesting advice on the disposal of damaged items. Warning: Some components assembled on GE Fanuc embedded system products may be sensitive to electrostatic discharge and may be damaged on the circuit board that is exposed to a high electrostatic field. When the circuit board is placed on the workbench for configuration, it is recommended to insert conductive materials under the circuit board to provide conductive shunt. Unused circuit boards shall be stored in the same protective box at the time of shipment.
