3ADT220090R0003 SDCS-POW-1机器人备件
简介
Fanuc Embedded Systems的-7807/VME-7807RC是全功能的基于奔腾®；M的单板计算机（SBC），采用单插槽、被动冷却、VME Eurocard外形。这些产品采用Intel®855GME芯片组的先进技术。-7807/VME-7807RC提供了桌面系统上常见的功能，例如：•1.0GB DDR SDRAM，使用一个SODIMM和可选512MB内存焊料，最大1.5GB•内置SVGA支持（前面板连接）•数字视频控制器（后I/O）DVI-D，具有双头显示功能•10/100 Mbit以太网控制器（前面板）•双千兆以太网支持（前面板或后I/O）•可选P0带VITA 31.1接口•串行ATA（SATA）支持（后I/O）？串行端口COM1（前面板连接）•Ultra IDE驱动器支持（后输入/输出）•实时时钟/日历•前面板复位开关•微型扬声器•键盘/鼠标端口（前面板）855GME芯片组允许-7807/VME-7807RC提供增强功能，如集成视频和Ultra ATA/100 IDE支持。-7807/VME-7807RC能够执行当今许多桌面操作系统，如Microsoft®的Windows®XP、Windows 2000和各种基于Linux®的操作系统。本手册第2章介绍了-7807/VME-7807RC的标准桌面功能。
提供了对嵌入式应用程序有用的功能
例如：•三个串行端口：COM2、COM3和COM4（后I/O）•四个USB 2.0端口（前面板上两个，后I/O两个）•32KB非易失性RAM•远程以太网引导•辅助IDE上高达2GB的CompactFlash（可选）•软件可选的带复位的看门狗定时器此外，提供一个带前面板接入的PMC扩展站点（PCI-X，66MHz）。能够执行当今许多操作系统，如VxWorks®、Solaris™ 或QNX®。本手册第3章介绍了的嵌入式功能。适用于电信、模拟、仪表、工业控制、过程控制和监控、工厂自动化、自动化测试系统、数据采集系统以及任何需要在单个VME插槽中实现最高性能处理能力的应用。Intel 855GME芯片组15 Intel 855GME芯片组采用了最新的Intel芯片组技术855GME。该芯片组采用高级集线器架构（AHA）。AHA通过将许多高带宽I/O访问与PCI访问分开，缓解了PCI总线上的瓶颈，从而提高了系统性能。此外，855GME芯片组为主板芯片组带来了新的集成水平，并提供了其他功能，如集成LVDS和串行ATA。
Introduction
Fanuc Embedded Systems' - 7807/VME-7807RC is a fully functional Pentium ® - based; M single board computer (SBC) adopts single slot, passive cooling and VME Eurocard shape. These products use Intel ® Advanced technology of 855GME chipset- 7807/VME-7807RC provides common functions on the desktop system, such as: • 1.0GB DDR SDRAM, using a SODIMM and optional 512MB memory solder, maximum 1.5GB • built-in SVGA support (front panel connection) • digital video controller (rear I/O) DVI-D, With dual head display function • 10/100 Mbit Ethernet controller (front panel) • Dual Gigabit Ethernet support (front panel or rear I/O) • Optional P0 with VITA 31.1 interface • Serial ATA (SATA) support (rear I/O)? Serial port COM1 (front panel connection) • Ultra IDE driver support (rear I/O) • Real time clock/calendar • Front panel reset switch • Micro speaker • Keyboard/mouse port (front panel) 855GME chipset allows - 7807/VME-7807RC to provide enhanced features such as integrated video and Ultra ATA/100 IDE support- 7807/VME-7807RC can execute many desktop operating systems today, such as Microsoft ® Windows for ® XP, Windows 2000 and various Linux based ® The operating system of. Chapter 2 of this manual describes the standard desktop functions of the - 7807/VME-7807RC.
Provides functionality useful for embedded applications
For example: • Three serial ports: COM2, COM3 and COM4 (rear I/O) • Four USB 2.0 ports (two on the front panel and two on the rear I/O) • 32KB non-volatile RAM • Remote Ethernet boot • CompactFlash up to 2GB on the secondary IDE (optional) • Software optional watchdog timer with reset In addition, a PMC expansion site with front panel access (PCI-X, 66MHz) is provided. Capable of executing many operating systems today, such as VxWorks ®、 Solaris ™ Or QNX ®。 The embedded functions of are described in Chapter 3 of this manual. It is applicable to telecommunication, simulation, instrument, industrial control, process control and monitoring, factory automation, automatic test system, data acquisition system and any application that needs to achieve the highest performance processing capacity in a single VME slot. Intel 855GME chipset 15 The Intel 855GME chipset uses the latest Intel chipset technology 855GME. The chipset uses Advanced Hub Architecture (AHA). By separating many high bandwidth I/O accesses from PCI accesses, AHA alleviates the bottleneck on the PCI bus and improves the system performance. In addition, the 855GME chipset brings a new level of integration to the motherboard chipset and provides other functions, such as integrated LVDS and serial ATA.
