330930-065-01-00模块备件
零件号说明
100076 330500 Velomitor Sensor and Velomittor XA Sensor User Guide 02173006散装电缆；2芯18 AWG绞合屏蔽电缆，无连接器或接线片。指定英尺数。46000-01磁性底座，用于临时安装Velomitor传感器。与1/4-28 UNF安装螺纹适配器一起使用。46122-01快速接头，用于Velomitor传感器的半永久安装。与1/2-20 UNF安装螺纹适配器一起使用。89409-01单个1/2-20 UNF安装适配器。89410-01单个M8 x 1安装适配器。89411-01单个1/4-28 UNF安装适配器。89412-01单个1/4-20 UNC安装适配器。89413-01单个1/4-18 NPT安装适配器。仅备件。对于新安装，请订购330525测速仪。04300015单个5/8-18 UNF安装适配器。161191单个1/2-13 UNC安装适配器。Velomitor Sensor随附适配器。单个适配器可用作备件。101212-01 Velomitor传感器连接器套件。用于外壳和改装。123135-01 Velomitor传感器电源模块。
压电速度传感器
330500 Velomitor压电速度传感器数据表8/11 141632版次N图和图1.2针，MIL-C-5015插座2.15/16英寸六角形3.12.7（0.500）直径，0.8（0.030）深沉头孔4.25.3（0.995）直径5.3/8-24 UNF-2B，最小螺纹深度6.4（0.250），最大钻孔深度14.0（0.550）图1：Velomitor-Piezo速度传感器尺寸图9/11 141631版次。N 330500 Velomitor压电速度传感器数据表图2：典型振幅响应图3：典型相位响应10/11 141632修订版N 330500 Velomitor压力传感器数据表版权所有2019 Baker Hughes，一家GE公司，LLC（“BHGE”）保留所有权利。Bently Nevada、Orbit Logo和Velomitor是BHGE在美国和其他国家的注册商标。所有产品和公司名称均为其各自持有人的商标。商标的使用并不意味着与各自持有人有任何关联或背书。本产品可能受一项或多项专利保护，参见Bently。com/legal获取当前状态。本文件中包含的信息如有更改，恕不另行通知。
Part Number Description
100076 330500 Velomitor Sensor and Velomitor XA Sensor User Guide 02173006 bulk cable; 2-core 18 AWG stranded shielded cable without connector or lug. Specify the number of feet. 46,000-01 magnetic base for temporary installation of Velomitor sensors. Use with 1/4-28 UNF mounting thread adapter. 46122-01 quick connector for semi permanent installation of Velomitor sensor. Use with 1/2-20 UNF mounting thread adapter. 89409-01 Single 1/2-20 UNF Mounting Adapter. 89410-01 Single M8 x 1 mounting adapter. 89411-01 Single 1/4-28 UNF Mounting Adapter. 89412-01 Single 1/4-20 UNC Mounting Adapter. 89413-01 Single 1/4-18 NPT Mounting Adapter. Spare parts only. For a new installation, order the 330525 Tachometer. 04300015 Single 5/8-18 UNF mounting adapter. 161191 Single 1/2-13 UNC Mounting Adapter. The Velomitor Sensor comes with an adapter. A single adapter can be used as a spare part. 101212-01 Velomitor Sensor Connector Kit. For housing and retrofitting. 123135-01 Velomitor Sensor Power Module.
Piezoelectric speed sensor
330,500 Velomitor Piezoelectric Speed Sensor Data Sheet 8/11 141,632 Rev. N Figure and Figure 1.2 Pin, MIL-C-5015 Socket 2.15/16 inch hexagon 3.12.7 (0.500) diameter, 0.8 (0.030) deep countersunk hole 4.25.3 (0.995) diameter 5.3/8-24 UNF-2B, minimum thread depth 6.4 (0.250), maximum drilling depth 14.0 (0.550) Figure 1: Velomitor Piezo Speed Sensor Dimension Figure 9/11 141,631 Rev. N 330500 Velomitor Piezoelectric Velocity Sensor Data Sheet Figure 2: Typical Amplitude Response Figure 3: Typical Phase Response 10/11 141632 Revision N 330500 Velomitor Pressure Sensor Data Sheet Copyright 2019 Baker Hughes, a GE company, LLC ("BHGE") All rights reserved. Bently Nevada, Orbit Logo and Velomitor are registered trademarks of BHGE in the United States and other countries. All product and company names are trademarks of their respective holders. The use of trademarks does not imply any association or endorsement with their respective holders. This product may be protected by one or more patents, see Bently. Com/legal to get the current status. The information contained in this document is subject to change without notice.
