330780-50-00工控模块前置控制器
监视器
订购信息有关国家和产品特定批准的详细列表，请参阅Bently.com上的批准快速参考指南（108M1756）。Velomitor压电速度传感器330500-AA-BB A：安装螺纹适配器选项00无适配器01 1/2-20 UNF 02 M8 x 1 03 1/4-28 UNF 04 1/4-20 UNC 05不适用于330500。注意：对于1/4-18 NPT安装，订单330525.06 5/8–18 UNF 07 3/8–16 UNC 08 1/2–13 UNC B：机构批准选项00不需要01 CSA/US/C 02 ATEX（欧洲）04多重批准（CSA、ATEX）互连电缆标准电缆长度英尺米（近似值）6 ft 1.8 m 8 ft 2.4 m 10 ft 3.0 m 12 ft 3.6 m 15 ft 4.5 m 17 ft 5.0 m 20 ft 6.0 m英尺米（大致值）25 ft 7.6 m 30 ft 9.0 m 33 ft 10.0 m 50 ft15.2 m 99 ft 30.0 m定制电缆零件号您可以以1.0 ft（305 mm）的增量订购定制电缆长度，但需额外付费。有些电缆有最小和最大长度。在这些零件号中使用“NN”指定要订购的电缆的长度（英尺）。零件号描述9571-NN双芯绞合屏蔽22 AWG电缆，一端带有两个插座防潮阴接头，另一端带有接线片。与监视器一起使用。不适用于21128速度传感器外壳。最小长度：2.0英尺（0.6米）最大长度：99英尺（30米）84661-NN双芯绞合屏蔽22 AWG铠装电缆，一端带有双插座防潮阴接头，另一端带有接线片。与监视器一起使用。不适用于21128速度传感器外壳。最小长度：3.0英尺（0.9米）最大长度：96英尺（29米）89477-NN双导线18 AWG绞合屏蔽电缆，一端带有直角双插座插头，另一端带有接线片。与监视器和21128速度传感器外壳一起使用。最小长度：2.0英尺（0.6米）最大长度：99英尺（30米）125065-NN双导线18 AWG绞合屏蔽电缆，一端带有两个插座插头和氟硅橡胶护套，另一端带有接线片。与监视器一起使用。不适用于21128速度传感器外壳。6/11 330500 Velomitor压电速度传感器数据表141632修订版。P零件号说明最小长度：2.0 ft（0.6 m）最大长度：99 ft（30 m）速度传感器外壳组件21128-AA-BB A：
安装螺纹选项
01无螺纹02 3/4-14 NPT 03 1/2-14 NPT04 1/2-12 BSP B：电缆出口配件选项01 1/2-14 NST插头02 1/2-14 NFT防爆03 1/2-14NPT防爆带电缆压盖使用21128外壳时，电缆零件号89477-AA是将Velomitor传感器连接至监视器所必需的。速度传感器外壳–CENELEC批准的107770-AA-BB该版本是330500 Velomitor传感器和工厂预装的21128外壳的组合。它也适用于CENELEC 1区IIC组危险区域应用。A： 安装螺纹选项01无螺纹02 3/4-14 NPT 03 1/2-14 NPT04 1/2-14 BSP B：电缆出口配件选项01 1/2-14 NBT插头02 1/2-14防爆03 1/2-14NPT防爆，带电缆压盖密封7/11 330500 Velomitor压电速度传感器数据表141632修订版。P附件零件号描述100076 330500 Velomitor传感器和Velomittor XA传感器用户指南02173006散装电缆；2芯18 AWG绞合屏蔽电缆，无连接器或接线片。指定英尺数。46000-01磁性底座，用于临时安装Velomitor传感器。与1/4-28 UNF安装螺纹适配器一起使用。46122-01快速接头，用于Velomitor传感器的半永久安装。与1/2-20 UNF安装螺纹适配器一起使用。89409-01单个1/2-20 UNF安装适配器。89410-01单个M8 x 1安装适配器。89411-01单个1/4-28 UNF安装适配器。89412-01单个1/4-20 UNC安装适配器。89413-01单个1/4-18 NPT安装适配器。仅备件。对于新安装，请订购330525测速仪。04300015单个5/8-18 UNF安装适配器。161191单个1/2-13 UNC安装适配器。Velomitor Sensor随附适配器。单个适配器可用作备件。101212-01 Velomitor传感器连接器套件。用于外壳和改装。123135-01 Velomitor传感器电源模块。8/11 330500 Velomitor压电速度传感器数据表141632 Rev.P图表和图1.2针，MIL-C-5015插座2.15/16英寸六角形3.12.7（0.500）直径，0.8（0.030）深沉头孔4.25.3（0.995）直径5.3/8-24 UNF-2B，6.4（0.250）最小螺纹深度，14.0（0.550）最大钻孔深度图1：Velomitor压电速度传感器尺寸图330500 Velomitor-Piezo速度传感器数据表141632 Rev.P 9/11图2：典型振幅响应图3：典型相位响应330500 Velotor-Piez速度传感器数据图141632版本.P 10/11版权所有2020贝克休斯公司。保留所有权利。Bently Nevada、Orbit Logo和Velomitor是Baker H公司Bently内华达的注册商标
monitor
Ordering Information For a detailed list of country and product specific approvals, see Bently Approval Quick Reference Guide (108M1756) on. com. Velomitor Piezoelectric Speed Sensor 330500-AA-BB A: Mounting Threaded Adapter Option 00 No Adapter 01 1/2-20 UNF 02 M8 x 1 03 1/4-28 UNF 04 1/4-20 UNC 05 Not available for 330500. NOTE: For 1/4-18 NPT installations, Order 330525.06 5/8 – 18 UNF 07 3/8 – 16 UNC 08 1/2 – 13 UNC B: Agency Approval Option 00 does not require 01 CSA/US/C 02 ATEX (Europe) 04 Multiple Approvals (CSA, ATEX) Interconnect Cable Standard Cable Length ft m (approximate) 6 ft 1.8 m 8 ft 2.4 m 10 ft 3.0 m 12 ft 3.6 m 15 ft 4.5 m 17 ft 5.0 m 20 ft 6.0 m ft m ft m (approximate) 25 ft 7.6 m 30 ft 9.0 m 33 ft 10.0 m 50 ft 15.2 m 99 ft 30.0 m Custom Cable Part NumberYou can order custom cable lengths in 1.0 ft (305 mm) increments at an additional cost. Some cables have minimum and maximum lengths. Use "NN" in these part numbers to specify the length (in feet) of the cable to order. Part Number Description 9571-NN 2-core twisted shielded 22 AWG cable with two female receptacles at one end and a lug at the other end. Used with the monitor. Not applicable to 21128 speed sensor housing. Minimum length: 2.0 feet (0.6 meters) Maximum length: 99 feet (30 meters) 84661-NN dual core twisted shielded 22 AWG armored cable with dual socket moisture-proof female connector at one end and lug at the other end. Used with the monitor. Not applicable to 21128 speed sensor housing. Minimum length: 3.0 feet (0.9 meters) Maximum length: 96 feet (29 meters) 89477-NN double conductor 18 AWG twisted shielded cable with right angle double socket plug at one end and lug at the other end. Used with monitor and 21128 speed sensor housing. Minimum length: 2.0 feet (0.6 meters) Maximum length: 99 feet (30 meters) 125065-NN double conductor 18 AWG twisted shielded cable with two socket plugs and fluorosilicone sheath at one end and lug at the other end. Used with the monitor. Not applicable to 21128 speed sensor housing. 6/11 330500 Velomitor Piezoelectric Speed Sensor Data Sheet 141632 Rev. P Part Number Description Minimum Length: 2.0 ft (0.6 m) Maximum Length: 99 ft (30 m) Speed Sensor Housing Assembly 21128-AA-BB A:
Mounting Thread Options
01 Unthreaded 02 3/4-14 NPT 03 1/2-14 NPT04 1/2-12 BSP B: Cable outlet fitting option 01 1/2-14 NST plug 02 1/2-14 NFT explosion-proof 03 1/2-14 NPT explosion-proof belt cable gland When 21128 enclosure is used, the cable part number 89477-AA is necessary to connect the Velomitor sensor to the monitor. Speed Sensor Housing – CENELEC approved 107770-AA-BB This version is a combination of the 330500 Velomitor Sensor and the factory pre installed 21128 housing. It is also suitable for CENELEC Zone 1 Group IIC hazardous area applications. A: Mounting thread option 01 Unthreaded 02 3/4-14 NPT 03 1/2-14 NPT04 1/2-14 BSP B: Cable outlet fitting option 01 1/2-14 NBT plug 02 1/2-14 explosion-proof 03 1/2-14 NPT explosion-proof, with cable gland seal 7/11 330500 Velomitor piezoelectric speed sensor data sheet 141632 Rev. P Accessory Part Number Description 100076 330500 Velomitor Sensor and Velomitor XA Sensor User Guide 02173006 Bulk Cable; 2-core 18 AWG stranded shielded cable without connector or lug. Specify the number of feet. 46,000-01 magnetic base for temporary installation of Velomitor sensors. Use with 1/4-28 UNF mounting thread adapter. 46122-01 quick connector for semi permanent installation of Velomitor sensor. Use with 1/2-20 UNF mounting thread adapter. 89409-01 Single 1/2-20 UNF Mounting Adapter. 89410-01 Single M8 x 1 mounting adapter. 89411-01 Single 1/4-28 UNF Mounting Adapter. 89412-01 Single 1/4-20 UNC Mounting Adapter. 89413-01 Single 1/4-18 NPT Mounting Adapter. Spare parts only. For a new installation, order the 330525 Tachometer. 04300015 Single 5/8-18 UNF mounting adapter. 161191 Single 1/2-13 UNC Mounting Adapter. The Velomitor Sensor comes with an adapter. A single adapter can be used as a spare part. 101212-01 Velomitor Sensor Connector Kit. For housing and retrofitting. 123135-01 Velomitor Sensor Power Module. 8/11 330500 Velomitor Piezoelectric Velocity Sensor Data Sheet 141632 Rev. P Chart and Figure 1.2 Pin, MIL-C-5015 Socket 2.15/16 inch hex 3.12.7 (0.500) diameter, 0.8 (0.030) deep counterbore 4.25.3 (0.995) diameter 5.3/8-24 UNF-2B, 6.4 (0.250) minimum thread depth, 14.0 (0.550) Maximum Drilling Depth Figure 1: Velomitor Piezo Velocity Sensor Dimensional Drawing 330500 Velomitor Piezo Velocity Sensor Data Sheet 141632 Rev. P 9/11 Figure 2: Typical Amplitude Response Figure 3: Typical Phase Response 330500 Velomitor Piez Velocity Sensor Data Sheet 141632 Version P 10/11 Copyright 2020 Baker Hughes. All rights reserved. Bently Nevada, Orbit Logo and Velomitor are registered trademarks of Baker H Company Bently Nevada
