330105-02-12-05-02-00前置传感器
注意事项
如果模块OK（正常）状态变为not OK（不正常），则机架接口输入/输出模块上的系统OK继电器将被驱动为not OK（异常）。Configuration Fault（配置故障）表示机架接口模块配置是否无效。通道状态正常这表示是否在通道或模块内检测到故障。如果通道OK状态变为not OK，则机架接口输入/输出模块上的系统OK继电器将被驱动为not OK。下表显示了可找到状态的位置。状态通信网关模块机架配置软件操作员显示软件模块OK X X模块配置故障X通道OK X X 3500/20操作和维护2一般信息5 2.3 LED说明机架接口模块前面板上的LED指示模块的运行状态，如下图所示。有关所有可用的LED条件，请参阅第6.2节。1） OK（正常）：表示机架接口模块和I/O模块工作正常。2） TX/RX：以发送消息的速率闪烁。3） TM：指示机架是否处于跳闸倍增模式。4） Config OK（配置正常）：表示机架中的任何模块未配置或存在配置错误，或机架接口模块的存储配置与机架3配置信息3500/20操作和维护6 3配置信息的物理配置不匹配本节描述了如何使用机架配置配置机架接口模块软件它还描述了与此模块相关的任何配置注意事项。
有关如何操作
软件的详细信息，请参阅3500监测系统机架配置和实用程序指南和机架配置软件。3.1软件配置选项本节显示了与机架接口模块相关的机架配置软件的配置屏幕，并讨论了配置注意事项。它将显示软件屏幕的副本，并解释可用的选项。3.1.1机架接口模块配置注意事项机架接口模块选项屏幕上指定的后端口I/O选项和电源选项必须与系统的物理组件匹配。如果发现配置不匹配，机架将不接受下载的配置3.1.2机架接口模块配置本节描述了机架接口模块组态屏幕上的可用选项。
matters needing attention
If the module OK status changes to not OK, the system OK relay on the Rack Interface I/O Module will be driven to not OK. Configuration Fault indicates whether the Configuration of the Rack Interface Module is invalid. Channel status OK This indicates whether a fault has been detected in the channel or module. If the channel OK status changes to not OK, the system OK relay on the Rack Interface I/O Module will be driven to not OK. The following table shows where the status can be found. Status Communication Gateway Module Rack Configuration Software The operator displays the software module OK X X Module Configuration Fault X Channel OK X X 3500/20 Operation and Maintenance 2 General Information 5 2.3 LED that indicate the operating status of the module on the front panel of the Rack Interface Module, as shown in the following figure. Refer to Section 6.2 for all available LED conditions. 1) OK: Indicates that the Rack Interface Module and I/O Module are working properly. 2) TX/RX: Flashes at the rate at which messages are sent. 3) TM: Indicates whether the rack is in Trip Multiply mode. 4) Config OK: indicates that any module in the rack is not configured or has a configuration error, or the storage configuration of the Rack Interface Module does not match the physical configuration of the 3500/20 operation and maintenance 6 3 configuration information. This section describes how to use the Rack Configuration to configure the Rack Interface Module software. It also describes any configuration considerations related to this module.
About how to
For software details, refer to the 3500 Monitoring System Rack Configuration and Utilities Guide and Rack Configuration Software. 3.1 Software Configuration Options This section displays the configuration screen for the Rack Configuration Software associated with the Rack Interface Module and discusses configuration considerations. It displays a copy of the software screen and explains the available options. 3.1.1 Rack Interface Module Configuration Considerations The rear port I/O options and power options specified on the Rack Interface Module Options screen must match the physical components of the system. If a configuration mismatch is found, the rack will not accept the downloaded configuration3.1.2 Rack Interface Module ConfigurationThis section describes the options available on the Rack Interface Module Configuration screen.
