330103-00-03-10-02-05震动模块控制器
当配置为跳闸倍增时
双掷（SPDT）触点额定值最小开关电流12Vdc/100mA DC规格（电阻负载）最大开关电流5A最大开关功率70W@24 Vdc 10W@48 Vdc 9W@60 Vdc最大开关电压60Vdc AC规格（电阻负荷）最大开关电压5A最大开关功率150VA最大开关电压30Vac参考危险区域专用用于危险区域应用的继电器规格注意事项章节。触点寿命100000次循环@5 A，250 Vac 200000次循环@1 A，24 Vdc密封环氧绝缘电阻1000 MΩ 最小值@500 Vdc抑制、复位和跳闸倍增输入抑制/跳闸倍增用户可以使用软件将抑制/跳闸倍增输入配置为抑制或跳闸倍增。当配置为跳闸倍增时，将抑制/跳闸倍增触点短路至RTN将增加报警和危险设置点。当配置为禁止时，禁止输入将禁止（旁路或停用）报警和危险状态。将禁止触点短路至禁止RTN将：l将所有可变危险状态设置为逻辑0 l将所有变量报警状态设置为0 l将旁路和禁止状态设置为1逻辑监视器报警禁止开关，和Modbus网关中映射的监视器跳闸倍增开关将分别远程禁用报警和危险状态或激活跳闸倍增。电气激活抑制50 kΩ 或更少（短路）禁用禁用500 kΩ 或更大（打开）重置使用重置输入重置所有锁定报警和锁定继电器。如果驱动状态的条件不再存在，将RESET触点短路至RESET RTN将：l重置所有锁定的报警状态l重置所有锁存的危险状态l重置全部锁存的非正常状态l重置锁存的继电器将非零值写入Modbus寄存器重置Modbus网关中映射的锁存状态将远程重置监视器。电气激活复位50 kΩ 或更少（缩短）停用重置500 kΩ 或更高（开路）传感器电源1900/65A通用设备监测器数据表8/22 173401 Rev.T所有输出都有短路保护。
双线电流模式
电流源3.3 mA±5%开路电压21至24 Vdc三线电压模式电源电压-24.02 Vdc至-23.47 Vdc最大额定电流15 mA短路电流15.1 mA至23.6 mA 4-20 mA输出接口数量四个输出，其中任何一个可配置为从任何通道和任何变量提供数据。比例值4至20 mA值与通道满标度成比例。回路电源电压18至36 Vdc回路电阻600Ω 在工作温度范围内最大精度2%更新率100 mS分辨率10 mA箝位电流2 mA±10%（可配置为不正常和旁路）缓冲输出显示模块显示模块上的单个缓冲输出提供对输入通道1至4的访问。信号没有增益，该输出被缓冲以提供短路和EMI保护。输出阻抗550Ω 最小带宽40 kHz（显示器模块直接连接至显示器）最小8 kHz（75 m（250 ft.）电缆）监视器模块通道1至4的每个输入都有一个专用的缓冲输出。信号没有增益，也没有缩放。每个输出都有缓冲，以提供短路和EMI保护。输出阻抗550Ω 最小带宽40 kHz指示灯监视器模块状态LED指示监视器正常工作。显示模块正常LED指示监视器何时正常工作。警报LED指示警报状态。危险LED指示危险状态。旁路LED指示监视器处于旁路模式。跳闸倍增LED指示监视器处于跳闸倍增模式。通道LED指示通道处于活动状态。带背光的液晶显示器（LCD）尺寸68.6 mm（2.7英寸）宽x 35.6 mm（1.4英寸）高功率要求输入电压范围18至36 Vdc工作电流0.35 A典型值，1.0 A最大工作功率8.5 W典型值，14 W最大值
When configured as Trip Multiply
Double throw (SPDT) contact rating Minimum switching current 12Vdc/100mA DC specification (resistive load) Maximum switching current 5A Maximum switching power 70W@24 Vdc 10W@48 Vdc 9W@60 Vdc maximum switching voltage 60Vdc AC specification (resistance load) maximum switching voltage 5A maximum switching power 150VA maximum switching voltage 30Vac refer to the chapter on relay specifications for hazardous area applications. Contact life 100000 cycles @ 5 A, 250 Vac 200000 cycles @ 1 A, 24 Vdc sealed epoxy insulation resistance 1000 M Ω minimum value @ 500 Vdc inhibit, reset and trip multiplication input inhibit/trip multiplication user can use software to configure inhibit/trip multiplication input as inhibit or trip multiplication. When configured as Trip Multiply, short circuiting the inhibit/trip multiplier contacts to the RTN will increase alarm and danger setpoints. When configured to inhibit, the inhibit input will inhibit (bypass or disable) alarm and danger states. Short circuit the inhibit contact to the inhibit RTN Set: l all variable hazardous states to logic 0 l all variable alarm states to 0 l bypass and inhibit states to 1 logic monitor alarm inhibit switch, and monitor trip multiply switch mapped in Modbus gateway will distinguish between remote disable alarm and hazardous states or activate trip multiply. Electrical activation inhibits 50 k Ω or less (short circuit) disables disabling 500 k Ω or more (open) resets all lockout alarms and lockout relays using the reset input. If the conditions of the drive state no longer exist, short circuiting the RESET contact to the RESET RTN will: l Reset all locked alarm states l Reset all latched dangerous states l Reset all latched abnormal states l Reset latched relays Write non-zero values to the Modbus registers Reset latched states mapped in the Modbus gateway Reset the monitor remotely. Electrical Activation Reset 50 k Ω or less (shortened) Deactivation Reset 500 k Ω or more (open circuit) Sensor Power Supply 1900/65A Universal Unit Monitor Data Sheet 8/22 173401 Rev. T All outputs are short-circuit protected.
Two wire current mode
Current source 3.3 mA ± 5% Open circuit voltage 21 to 24 Vdc Three wire voltage mode Power supply voltage - 24.02 Vdc to -23.47 Vdc Maximum rated current 15 mA Short circuit current 15.1 mA to 23.6 mA 4-20 mA Output interface quantity Four outputs, any of which can be configured to provide data from any channel and any variable. The proportional value 4 to 20 mA is proportional to the full scale of the channel. Loop power voltage 18 to 36 Vdc Loop resistance 600 Ω Maximum accuracy 2% Update rate 100 mS resolution 10 mA Clamping current 2 mA ± 10% (configurable as abnormal and bypass) Buffered output display module Single buffered output on the display module provides access to input channels 1 to 4. The signal has no gain and the output is buffered to provide short circuit and EMI protection. Output impedance 550 Ω Minimum bandwidth 40 kHz (display module directly connected to the display) Minimum 8 kHz (75 m (250 ft.) cable) Each input to channel 1 through 4 of the monitor module has a dedicated buffered output. The signal has no gain or scaling. Each output is buffered to provide short circuit and EMI protection. Output impedance 550 Ω minimum bandwidth 40 kHz indicator monitor module status LED indicates that the monitor is working properly. The display module OK LED indicates when the monitor is working properly. The alarm LED indicates the alarm status. The danger LED indicates the danger status. The bypass LED indicates that the monitor is in bypass mode. Trip Multiply LED indicates that the monitor is in Trip Multiply mode. The channel LED indicates that the channel is active. LCD with backlight Size 68.6 mm (2.7 inches) Width x 35.6 mm (1.4 inches) High power requirements Input voltage range 18 to 36 Vdc Operating current 0.35 A typical, 1.0 A maximum operating power 8.5 W typical, 14 W maximum
