本特利1900/65A-00-01-01-00-00风机振动监测器
q输入：
总共8个（4个振动和4个温度）q输出：6个离散（单独可编程继电器），4个比例（4-20 mA）q报警：每个测量变量可单独配置警报和危险级别（每个通道最多8个）；不可以按通道单独配置q灵活、经济高效的系统q连续在线保护q优于变送器的性能/便利性q可选显示模块（可安装在监视器上或最远75米处）q设计用于在现有机器上进行经济高效的安装，或由原始设备制造商将其纳入新机器包q缓冲输出能力，便于与便携式仪器连接新产品特点[2005年第25卷第1期]轨道4 5特别强调高度可配置和灵活的设计，可轻松适应各个应用，并为每个输入传感器提供多个测量参数。例如，单个地震传感器输入可以返回多达四个不同的测量参数，包括带通滤波、积分、RMS或峰值检测、偏置电压和加速度包络。
测量变量
结合起来，振动和温度输入可以被处理为用户选择的20个不同的测量变量，每个变量都有自己的警报，在非常小的封装中提供高测量密度。报警逻辑也是高度可配置的–用户可以在各种参数和通道之间以几乎无限的组合加入复杂的投票逻辑。可选显示模块提供了新的安装自由度。将显示器安装在布线成本最低的地方（例如机器附近），并将显示器安装到人员最方便接近的地方（如遮蔽处或控制室）——最远75米。或者，当只需要一个“盲”监控系统时，完全取消显示。现在，有一个系统提供了功能和可负担性的平衡，您需要该系统来监控工厂设备资产的基本和平衡。
Q Input:
Total 8 (4 vibrations and 4 temperatures) q outputs: 6 discrete (individually programmable relays), 4 proportional (4-20 mA) q alarms: alarm and danger levels can be individually configured for each measured variable (up to 8 per channel); It is not allowed to configure q flexible and cost-effective system by channel, q continuous online protection, q better performance/convenience than transmitter, q optional display module (can be installed on the monitor or at the farthest 75m), q designed for cost-effective installation on existing machines, or incorporated into the q buffered output capacity of new machine package by the original equipment manufacturer, Easy connection with portable instruments New product features [2005 Volume 25, Issue 1] The track 4 5 emphasizes highly configurable and flexible design, which can easily adapt to various applications and provide multiple measurement parameters for each input sensor. For example, a single seismic sensor input can return up to four different measurement parameters, including band-pass filtering, integration, RMS or peak detection, bias voltage, and acceleration envelope.
Measuring variables
Combined, vibration and temperature inputs can be processed into 20 different measurement variables selected by the user, each of which has its own alarm, providing high measurement density in a very small package. The alarm logic is also highly configurable – users can add complex voting logic between various parameters and channels in almost unlimited combinations. The optional display module provides new degrees of freedom for installation. Install the display in the place with the lowest wiring cost (such as near the machine), and install the display in the place that is most convenient for people to access (such as shelter or control room) - the maximum distance is 75 meters. Or, when only one "blind" monitoring system is required, the display is completely canceled. Now, there is a system that provides a balance between functionality and affordability. You need this system to monitor the basic and balance of plant equipment assets.
