57310001-KY
安装位置任何装配说明排零间距标准
请注意，显示的数据是根据我们的在线目录生成的。 我们的通用下载使用条款有效VARIOFACE模块，带刀式断开端子板，用于：-S800 I/O输入模块，模块宽度：126.5 mm产品具有八个带刀片断开的正极接线板（TU810/P）八个带刀断开的负极接线板（TU810）一个带每个通道刀片断开（TU830）的正极和负极接线板关键商业数据包装第一单元每件重量（不包括包装）331.6 GRM定制关税编号85369010原产国德国技术数据尺寸宽度126.5 mm高度90 mm深度61 mm环境条件环境温度（操作）-20°C…50°C环境温度（存储/运输）-20°F…70°C一般标称电压UN 50 V AC/DC每个支路的最大载流容量2 A电压的最大总电流第2/4页接口模块-FLKM-D25 SUB/KDS3-MT/TU810/P-2304539技术数据一般状态显示无测试电压800 V（50 Hz，1分钟）
测试电压触点/触点0.8 kV AC安装位置任何装配说明排零间距标准/法规DIN EN 50178 IEC 62103污染度2浪涌电压II类额定浪涌电压1.4 kV连接数据1连接名称现场水平连接方法螺纹连接带断开刀导体横截面最小为0.2 mm²导体横截面实心最大为4 mm²导线横截面绞合最小为0.2 m²导体截面绞合最大为2.5 mm²最小为24导体横截面AWG/kcmil最大为12剥离长度8 mm螺纹M3连接数据2连接名称控制系统级别连接方法D-SUB插座条位置数量25支持的控制器控制器ABB S800 I/O-合适的I/O卡DI810 DI811 DI830 DI831 DI840 DO814 AI810 AI820
Zero spacing standard for any assembly instructions at the installation position
Please note that the data displayed is generated from our online catalog. Our general download terms of use are valid VARIOFACE modules with knife type disconnecting terminal blocks for: - S800 I/O input modules, Module width: 126.5 mm The product has eight positive terminal blocks (TU810/P) with blade disconnections, eight negative terminal blocks (TU810) with blade disconnections, one positive and negative terminal blocks with blade disconnections (TU830) for each channel. Key business data package. Weight of each unit (excluding package) 331.6 GRM custom tariff No. 85369010 Country of Origin Germany Technical data Size width 126.5 mm Height 90 mm Depth 61 mm Environmental conditions Ambient temperature (operation) - 20 ° C... 50 ° C Ambient temperature (storage/transportation) - 20 ° F... 70 ° C General nominal voltage UN 50 V AC/DC Maximum current carrying capacity of each branch 2A Maximum total current of voltage Page 2 of 4 Interface module FLKM-D25 SUB/KDS3-MT/TU810/P-2304539 General status of technical data shows no test voltage 800 V (50 Hz, 1 minute)
Test voltage contact/contact 0.8 kV AC Installation position Any assembly instructions Zero spacing standard/regulation DIN EN 50178 IEC 62103 Pollution degree 2 Surge voltage Class II Rated surge voltage 1.4 kV Connection data 1 Connection name Field horizontal connection method Screw connection with disconnecting knife Conductor cross-section minimum 0.2 mm ² Conductor cross-section solid max. 4 mm ² Conductor cross-section stranding 0.2 m minimum ² Conductor section stranding up to 2.5 mm ² Minimum 24 conductor cross-section AWG/kcmil Maximum 12 Stripping length 8 mm Thread M3 Connection data 2 Connection name Control system level Connection method D-SUB Number of socket bar positions 25 Supported controller controller ABB S800 I/O - Suitable I/O card DI810 DI811 DI830 DI831 DI840 DO814 AI810 AI820
