产品详情介绍
Honeywell 51401583-100 EPNI输出接口模块
监测温度传感器持续监测模块的工作温度。处理器模块的温度状态指示是否已超过以下环境温度范围的温度阈值
中断工作电压后，控制器可能不会自动重新启动。如果一个处理器模块的模式开关处于停止位置，并且在重新连接工作电压时，此处理器模块意外地第一个启动，则它仍处于停止状态。因此，其他处理器模块也无法启动。如果在中断工作电压后需要自动启动，则所有处理器模块上的模式开关必须设置为运行！开关位置：运行至安全相关操作设置！影响：非冗余操作：如果自动启动被激活，处理器模块将启动用户程序。冗余操作：处理器模块采用与其他处理器模块相同的操作状态。如果温度超过特定阈值或低于该阈值，温度状态将发生变化。表14适用于带运行风扇的正常运行。如果出现异常操作，例如，没有风扇，温度状态可能表明即使在较低的环境温度下也已超过温度阈值。温度状态是处理器模块的状态。登录处理器模块后，模块状态显示在SILworX控制面板中。
操作系统
加载到CPU中的操作系统包含HIMax可编程电子系统（PES）的所有基本功能，例如：处理用户程序，执行硬件和软件的所有测试例行程序周期时间监控（看门狗）与I/O模块的安全通信与其他系统的安全通信，例如：-HIMax-HIMatrix创建和存储事件。有关操作系统功能的说明，请参阅系统手册（HI 801 001 E）。周期处理CPU周期通过以下阶段运行：读取输入数据处理用户程序写入输出数据其他活动，例如重新加载处理连接器板X-CB 001 01连接器板将模块与其他HIMA控制器或PADT连接。模块和连接器板一起构成一个功能单元。连接器板包含处理器模块上以太网交换机的四个端口（Eth1…Eth4）。要启动处理器模块，请将处理器模块插入允许的基板插槽中，参见第4.1.1章。如果基板已经在运行，处理器模块将启动并采用通过其配置和模式开关位置设置的运行状态。如果基板不工作，请连接电源电压。
Monitoring the Temperature
Sensors continuously monitor the operating temperature of the modules. The temperature status of a processor module indicates wether the temperature thresholds have been exceeded with respect to the following environment temperature ranges
The controller might not restart automatically after interrupting the operating voltage If the mode switch of one processor module is in the Stop position and this processor module is accidentally the first to be started when the operating voltage is reconnected, it remains in the STOP state. Consequentially, also the remaining processor modules cannot start. If an Autostart is required after interrupting the operating voltage, the mode switches on all the processor modules must be set to Run! Switch Position: Run To set for safety-related operation! Effect: Non-redundant operation: The processor module starts the user programs if Autostart is activated. Redundant operation: The processor module adopts the same operating state as the other processor modules.If the temperature exceeds a specific threshold or falls below it, the temperature status changes. Table 14 applies to normal operation with operating fans. In case of abnormal operation, e.g., without fans, the temperature status can indicate that the temperature thresholds have been exceeded even at a lower environment temperature. The temperature status is a status of the processor module. After logging in to the processor module, the module status is displayed in the SILworX Control Panel.
Operating System
The operating system loaded into the CPU contains all basic functions of the HIMax programmable electronic system (PES), for example: Processing the user programs, Performing all test routines for hardware and software Cycle time monitoring (watchdog) Safe communication with the I/O modules Safe communication with other systems, such as: - HIMax - HIMatrix Creating and storing events. For a description of the operating system functions, see the System Manual (HI 801 001 E). Cycle Processing A CPU cycle runs through the following phases: Reading the input data Processing the user programs Writing the output data Other activities, e.g., reload processing Connector Board The X-CB 001 01 connector board connects the module with other HIMA controllers or with the PADT. Module and connector board form together a functional unit. The connector board contains the four ports (Eth1...Eth4) of the Ethernet switch on the processor module.To start up the processor module, insert the processor module into a permissible base plate slot, see Chapter 4.1.1. If the base plate is already operating, the processor module starts and adopts the operating state set through its configuration and the mode switch position. If the base plate is not operating, connect the supply voltage.
产品优势
1：国外专业的供货渠道，具有价格优势
2：产品质量保证，让您售后无忧
3：全国快递包邮
4：一对一服务
公司主营范围简介
PLC可编程控制器模块，DCS卡件，ESD系统卡件，振动监测系统卡件，汽轮机控制系统模块，燃气发电机备件等，优势品牌：Allen Bradley、BentlyNevada、ABB、Emerson Ovation、Honeywell DCS、Rockwell ICS Triplex、FOXBORO、Schneider PLC、GE Fanuc、Motorola、HIMA、TRICONEX、Prosoft等各种进口工业零部件、欧美进口模块。
产品广泛应用于冶金、石油天然气、玻璃制造业、铝业、石油化工、煤矿、造纸印刷、纺织印染、机械、电子制造、汽车制造、塑胶机械、电力、水利、水处理/环保、锅炉供暖、能源、输配电等等
