CUTLER HAMMER CPS120480DSK控制器系统扩展
通信规范可连接单元：ESB总线节点单元（ANB10), 光纤ESB总线节点单元（ANB11), 以及光纤ESB总线中继器模块（ANT10U）的单元可连接单元数：可以连接到ESB总线的ESB总线节点单元数和光纤ESB节点单元数取决于所选数据库。可连接单元*1:ESB总线节点单元（ANB10）中不包括用于ESB总线中继器模块（ANT10U）的单元), 光纤ESB总线节点单元（ANB11) *2： 将ESB总线节点单元和光纤ESB总线单元连接到FCU（AFV30/AFV40型), 将ESB总线耦合器模块（EC401或EC402）安装在插槽7和8中。EC401最多可以连接九个节点单元（ANB10或ANB11). EC402最多可以连接九个节点单元（ANB10或ANB11) 分别位于上部和下部。节点单元总数的总和（ANB10 或ANB11) 每个FCU不应超过指定的数量*3： 对于AFV40，单个机柜中最多可以安装11个ESB总线节点单元、光纤ESB总线单元和光纤ESB母线中继器模块单元. 传输路径规格网络拓扑：总线拓扑传输路径冗余：可用传输速度：128兆位/秒传输电缆：专用电缆（YCB301），光缆（*1）传输距离：最大10米（*2），50公里（使用ANT411光纤ESB总线中继器模块时）（*3）*1：光缆规格连接器类型：LC（符合IEC 61754-20）建议电缆：石英单模光纤（JIS C6835 SSMA-9.3/125 IEC 60793-2-50B1.1）芯数：2*2：EC401最大10米，上下两侧最大10米，对于EC402.*3：使用光纤ESB总线中继器模块距离最多可延长50公里。有链式和星形连接配置。
传输路径规格
网络拓扑：总线拓扑传输路径冗余：可用传输速度：10兆位/秒传输电缆：同轴电缆（YCB141、YCB311）。使用YCB147/YCB149总线适配器单元将YCB141电缆连接到YCB311电缆。连接YCB311电缆时，应为每段（*1）使用一个接地装置（YCB117）。传输距离：YCB141:混合YCB141和YCB311时最大185米：YCB41+（185/500）的长度x YCB31l的长度≤ 185总线适配器单元数量：每段最多4个（*1）通用以太网中继器：总传输距离受中继器数量限制。L≤ 4-0.5×n L：总传输距离（km）n：通用以太网中继器的数量（最多4个中继器）*1：如果在ER总线上使用中继器，由中继器隔离的ER总线的每个部分称为一个段。 法规遵从性有关以下标准的详细信息，请参阅“系统概述”（GS 33K01A10-50E）和每个产品的GS。 光ESB总线中继器模块电源模块单元、光ESB母线中继器组件安装在一个单元中。有关更多详细信息，请参阅“光纤总线中继器模块单元（用于AFV30/AFV40型)” （第33K50F50-50E节）。I/O模块I/O模块包括模拟I/O模块、数字I/O模块和通信模块。模拟I/O模块有几种类型，包括隔离通道型、隔离型和非隔离型。此外，为了更换CENTUM V，还提供了CENTUM-XL和µXL兼容模块，以便将信号调节器的系统电缆连接到这些兼容模块。对于I/O模块，可以指定环保支持（温度环境支持、G3支持）选项。I/O模块为防爆产品。详见《防爆》（TI 33Q01J30-01E）
Communication Specifications
Connectable Units: ESB Bus Node Unit (ANB10), Optical ESB Bus Node Unit (ANB11), and Unit for Optical ESB Bus Repeater Module (ANT10U) Number of Connectable Units: The number of ESB bus node units and optical ESB bus node units that can be connected to the ESB bus varies depending on the selected database. Units for Optical ESB Bus Repeater Module (ANT10U) are not included in the number of connectable units *1: ESB Bus Node Unit (ANB10), Optical ESB Bus Node Unit (ANB11) *2: To connect the ESB bus node unit and optical ESB bus node unit to the FCU (AFV30/AFV40), install the ESB Bus Coupler Module (EC401 or EC402) in slots 7 and 8. EC401 can be connected a maximum of nine Node Units (ANB10or ANB11). EC402 can be connected a maximum of nine Node Units (ANB10or ANB11) on the upper and lower sides, respectively. The sum of the total number of Node Units (ANB10 or ANB11) per FCU should not exceed the specified number. *3: The maximum number of ESB bus node units, optical ESB bus node units, and units for optical ESB bus repeater module that can be installed in a single cabinet is 11 for AFV40. Transmission Path Specifications Network Topology: Bus topology Transmission Path Redundancy: Available Transmission Speed: 128 megabits per second Transmission Cable: Dedicated cable (YCB301), an optical fiber cable (*1) Transmission Distance: Max. 10 m (*2), 50 km (when using the ANT411 Optical ESB Bus Repeater Module) (*3) *1: Optical Fiber Cable Specifications Connector Type: LC (compliant with IEC 61754-20) Recommended Cable: Quartz single-mode fiber (JIS C6835 SSMA -9.3/125 IEC 60793-2-50B1.1) Number of Cores: 2 *2: Max. 10 m for EC401 and max. 10 m on the upper and lower sides, respectively, for EC402. *3: The distance can be extended to a maximum of 50 km using the optical ESB bus repeater module. Chain and star connection configurations are available.
Transmission Path Specifications
Network Topology: Bus topology Transmission Path Redundancy: Available Transmission Speed: 10 megabits per second Transmission Cable: Coaxial cable (YCB141, YCB311). Use YCB147/YCB149 Bus Adapter Unit to connect a YCB141 cable to a YCB311 cable. One grounding unit (YCB117) per segment (*1) should be used when connecting YCB311 cable. Transmission Distance: YCB141: Max.185 m When mixing YCB141 and YCB311: Length of YCB141 + (185/500) x Length of YCB311 ≤ 185 Number of Bus Adapter Units: Max. 4 per segment (*1) General-purpose Ethernet Repeater: The total transmission distance is limited by the number of repeaters. L ≤ 4 - 0.5 × n L: total transmission distance (km) n: the number of the general-purpose Ethernet repeater (Max. 4 repeaters) *1: If repeaters are used on ER bus, each part of the ER bus segregated by a repeater is referred to as a segment. Regulatory Compliance For the detailed information of following standards, see “System Overview” (GS 33K01A10-50E) and GS on each product. Unit for Optical ESB Bus Repeater Module Power Supply Modules, Optical ESB Bus Repeater Module are installed in a Unit. For more details, refer to “Unit for Optical Bus Repeater Module (for AFV30/AFV40)” (GS 33K50F50-50E).I/O Modules The I/O Modules include Analog I/O Modules, Digital I/O Modules and Communication Modules. There are several types of Analog I/O Modules, including the isolated channel type, isolated type and non-isolated type. In addition, to enable replacements from CENTUM V, CENTUM-XL and µXL compatible modules are provided so that the system cable from the Signal Conditioner can be connected to these compatible modules. For the I/O Modules, the environment-proof support (temperature environment support, G3 support) options can be specified. The I/O Module is Explosion Protection product. For details, refer to “Explosion Protection” (TI 33Q01J30-01E)
