Harmonic Drive CHM-58A-A-E16384-B-SP控制减速机
（1） 输出负载线和输入线应分开并扭曲，以提高噪声灵敏度。（2） 传感线应为绞合线或屏蔽线，并与输出线分开。（3） 使用尽可能粗和短的所有线路，以降低阻抗。电线应扭曲或使用屏蔽线，以提高噪音敏感性。（4） 将电容器连接到负载端子可以消除噪音。（5） 此电源的FG端子为功能接地。为安全起见，将保护接地端子连接到安装组件接地端子。（6） 端子件的建议扭矩：（7）建议接线建议电路保护器：AC250V30A建议噪声滤波器：RSEN-2030（TDK-LAMBDA）（8）输出端子的M4螺钉可能损坏端子的内螺纹。这主要是由M4螺钉的无螺纹部分引起的。因此，请选择垫圈、弹簧垫圈等，以避免无螺纹螺钉部分穿透输出端子内部。输入端子（M4螺钉）：1.27 N∙m输出端子（M8螺栓和螺母）：10.8N・米
预期寿命电源的寿命取决于使用和安装风扇的内置铝电解电容器的寿命。可靠性数据中描述了每个寿命。铝电解电容器的寿命取决于安装电源的方法、负载电流和环境温度。请参阅“电解电容器寿命”。风扇的寿命取决于风扇进气或排气温度。请参阅“风扇预期寿命。请不要使用超过预期寿命的产品。存在意外输出停机的风险，并且可能无法满足规格要求。请联系我们进行维护或更换超过预期寿命要求的产品。
外部保险丝额定值
选择输入线的外部保险丝时，请参考以下保险丝额定值。当线路接通时，浪涌电流流动。使用慢熔断保险丝或时间接线片保险丝。不要使用快速熔断保险丝。保险丝额定值由线路接通时的冲击电流值规定。在实际负载条件下，不要根据输入电流（rms.）值选择保险丝。HWS1500:30A 10.故障排除在确定装置存在故障之前，进行以下检查。（1） 检查额定输入电压是否适用。（2） 检查输入和输出接线是否正确。（3） 检查I/O端子连接是否按规定的拧紧力矩正确拧紧。（4） 检查导线材料是否不太薄。（5） 检查输出电压控制（V.ADJ）是否正确调整。OVP可能被触发，输出被切断。（6）检查“+S”和“-S”端子接线是否正确。如果处于打开状态，输出的稳定性和准确性会恶化。（7） 如果使用远程ON/OFF控制功能，检查远程ON/OFF控制接头是否未打开。如果处于打开状态，则输出被切断。（8）检查内置风扇是否未停止。风扇是否因不规则或灰尘等原因而停止。如果风扇停止，PF信号打开。此外，如果风扇停止输出，保护电路会截获输出。风扇是寿命有限的部件。（9） 该电源在前面板和后面板上有通风孔。检查是否有任何不规则或灰尘等。（10）电源主体是否异常发热？让设备充分冷却后，请再次打开输入。输出被过热保护功能关闭。（11） 检查输出电流和输出功率是否超过规格。（12） 检查输入电压波形是否为正弦。如果此电源设备连接到UPS，输入电压波形可能不是正弦波形。电源设备发出声音噪音。（13） 在动态负载操作期间，可以听到可听的噪音。
Wiring Method
(1) The output load line and input line shall be separated and twisted to improve noise sensitivity. (2) The sensing lines shall be twisted or shield wire and separated from the output lines. (3) Use all lines as thick and short as possible to make lower impedance. Wires are to be twisted or use shield wire to improve noise sensitivity. (4) Attaching a capacitor to the load terminals can eliminate noise. (5) FG terminal of this power supply is functional earthing. For safety purposes, connect protective earthing terminal to the mounting set ground terminal. (6) Recommended torque for the terminal piece: (7) Recommended wiring Recommended circuit protector : AC250V30A Recommended noise filter : RSEN-2030 (TDK-LAMBDA) (8) M4 screw for output terminal might damage the terminal’s inner thread. This is mainly cause by the M4 screw’s unthread section. Therefore, please select a washer, spring washer, etc. to avoid unthread screw section from penetrating into output terminal inner section. Input terminal (M4 screw) : 1.27 N･m Output terminal (M8 Bolt & Nut) : 10.8N・m
The life expectancy The life of the power supply depends on the life of the built-in aluminum electrolytic capacitor being used and mounted fan. Each life is described in reliability data. The life of the aluminum electrolytic capacitor varies depending on the method of mounting the power supply, the load current, and the ambient temperature. Please refer to “Electrolytic Capacitor Lifetime”. The life of the fan depends on the fan intake or exhaust temperature. Please refer to “Fan Life Expectancy. Please do not use the product which passed over the life expectancy. There is a risk of unexpected output shutdown and specifications may not be satisfied. Please contact us for maintenance or exchange the product which passed over the life expectancy.
External Fuse Rating
Refer to the following fuse rating when selecting the external fuses for input line. Surge current flows when line turns on. Use slow-blow fuse or time-lug fuse. Do not use fast-blow fuse. Fuse rating is specified by in-rush current value at line turn-on. Do not select the fuse according to input current (rms.) values under the actual load condition. HWS1500：30A 10. Troubleshooting Before concluding that the unit is at fault, make the following checks. (1) Check if the rated input voltage is apply. (2) Check if the wiring of input and output is correct. (3) Check if the I/O terminal connection is properly tighten by a regulated tightening torque. (4) Check if the wire material is not too thin. (5) Check if the output voltage control (V.ADJ) is properly adjusted. OVP might be triggered and output is cut off. (6) Check if the wiring of “+S” and “-S” terminal is correct. If in open condition, the stability and the accuracy of the output deteriorate. (7) If use function of the remote ON/OFF control, check if the remote ON/OFF control connector is not opened. If in open condition, output is cut off. (8) Check if the built-in fan is not stopped. Is fan stopped by something irregulars or dust, etc. If fan stops, the PF signal is turn on. Moreover, the output is intercepted with the protection circuit if fan stops. Fans are the limited life parts. (9) This power supply has ventilating holes on the front and back panels. Check if there is any irregulars or dust, etc. (10) Is the main body of the power supply abnormally hot? Please turn on the input again after allowing the unit to cool down sufficiently. The output shut down by over temperature protection function. (11) Check if the output current and output power is not applied over specification. (12) Check if the input voltage wave is sinusoidal. If this power supply unit is connected to a UPS, input voltage wave might not be sinusoidal. An audible noise is emitted from the power supply unit. (13) Audible noise can be heard during Dynamic-Load operation.
产品优势
1：国外专业的供货渠道，具有价格优势
2：产品质量保证，让您售后无忧
3：全国快递包邮
4：一对一服务
公司主营范围简介
PLC可编程控制器模块，DCS卡件，ESD系统卡件，振动监测系统卡件，汽轮机控制系统模块，燃气发电机备件等，优势品牌：Allen Bradley、BentlyNevada、ABB、Emerson Ovation、Honeywell DCS、Rockwell ICS Triplex、FOXBORO、Schneider PLC、GE Fanuc、Motorola、HIMA、TRICONEX、Prosoft等各种进口工业零部件、欧美进口模块。
产品广泛应用于冶金、石油天然气、玻璃制造业、铝业、石油化工、煤矿、造纸印刷、纺织印染、机械、电子制造、汽车制造、塑胶机械、电力、水利、水处理/环保、锅炉供暖、能源、输配电等等
