产品内容介绍
CTI 2500-C300高速顺序控制
系统配置B2.2.1组件FA-M3 Value版本（F3SC21-1N）由以下组件组成F3BU04-0N基本模块-带电源和内存的F3SP05-0P序列CPU模块-F3WD64-3N I/O模块有关F3BU04-0N和F3WD64-3N模块及其他组件的详细规格，请参阅其各自的相关章节。带电源和存储器的F3SPS05-0P顺序CPU模块包含与F3PU10-0N电源模块等效的电源。本节介绍此内置电源块的规格。序列CPU块的详细信息在“序列CPU–功能（用于F3SP21、F3SP25、F3SPS35）”（IM 34M06P12-02E）中进行了解释。安装F3SP08-0P或F3SP008-SP序列CPU模块的单元主单元A的概念称为主单元。因此，F3SC22-xx或F3SC23-xx本身就是主单元。子单元子单元用于增加I/O端口的数量。FA-M3系统的Value II最多可以添加七个子单元，以处理最多2048个I/O点。使用光纤FA总线模块增加I/O点的数量您可以在主单元和子单元中安装光纤FA母线或FA总线类型2模块，并用光缆连接它们。这使得远程I/O点的分布式布置、I/O点数量的增加以及通过高速、抗噪声通信控制I/O模块成为可能。光纤FA总线或FA总线类型2模块可以安装在插槽3或插槽4中。TIP■ 使用FA总线类型2模块增加I/O点数的示例与光纤FA总线型号2模块一样，可以使用FA母线类型2模块来增加I/O点数。FA总线类型2模块使用屏蔽双绞线连接子单元。
基本配置
FA-M3值II（F3SC22-xx，F3SC23-xx）由以下部件组成。参见图C1.1了解具有各自模块配置的可用模型F3BU04-0N基本模块-F3SP08-0P序列CPU模块，带电源（带M3.5螺钉）和内存-F3SPS08-SP序列CPU模件，带电源和内存（带M4螺钉）-F3WD32-3F I/O模块-F3GD64-3F I/O模件-F3WD64-3P I/O模块-F3WD64-4P I/O模块-F3XD16-3F输入模块-F3YD14-5A输出模块如果FA-M3值II出现故障，只能通过更换故障模块来修复。将F3SP08 xP序列CPU模块安装在F3BU04-0N基本模块的最左侧插槽中，并将其他I/O模块安装在插槽2（或插槽2和3）中。其余插槽3和4（或仅插槽4）是为FA-M3系列可用的各种I/O模块保留的。插槽编号由三位数字组成，其中第三位数字是单元编号。单元编号0分配给主机。将F3SP08-0P顺序CPU安装在F3SC22-xx的插槽1中，并将F3SPS08-SP顺序CPU模块安装到F3SC23-xx插槽1中。在插槽2（或插槽2和3）中安装其他指定的组件模块。您可以在其余插槽中安装FA-M3 I/O模块。您不能在剩余的插槽中安装CPU模块。有关I/O模块（包括子单元）安装的限制，请参阅第A1.2节“模块安装限制”，因为它们等同于该节中讨论的F3SP21-0N模块的限制。
System Configuration B2.2.1 Components
The FA-M3 Value version (F3SC21-1N) consists of the following components. - F3BU04-0N base module - F3SP05-0P sequence CPU module with a power supply and memory - F3WD64-3N I/O module For details on the specifications of the F3BU04-0N and F3WD64-3N modules and other components, see their respective relevant sections.The F3SP05-0P sequence CPU module with a power supply and memory contains a power supply equivalent to the F3PU10-0N power supply module. This section explains the specifications of this built-in power supply block. Details on the sequence CPU block are explained in the "Sequence CPU – Functions (for F3SP21, F3SP25, F3SP35)" (IM 34M06P12-02E).Concept of Unit Main Unit A unit in which the F3SP08-0P or F3SP08-SP sequence CPU module is installed is referred to as a main unit. Consequently, the F3SC22-xx or F3SC23- xx itself serves as the main unit. Subunit Subunits are used to increase the number of I/O ports. A maximum of seven subunits can be added to the Value II of the FA-M3 system to deal with up to 2048 I/O points. Increasing the Number of I/O Points Using Fiber-optic FA-bus Modules You can install fiber-optic FA-bus or FA-bus type 2 modules in both main and subunits and connect them with fiber-optic cables. This enables the distributed arrangement of remote I/O points, increase in the number of I/O points, and control of I/O modules via high-speed, noise-immune communication. The fiber-optic FA-bus or FA-bus type 2 module may be installed in either slot 3 or slot 4. TIP ■ Example of increasing the number of I/O points using FA-bus type 2 modules As with fiber-optic FA-bus type 2 modules, the number of I/O points can be increased using FA-bus type 2 modules. FA-bus type 2 modules use shielded twisted-pair cables for the connection between subunits.
Basic Configuration
The FA-M3 Value II (F3SC22-xx, F3SC23- xx) consists of the following components. See Figure C1.1 for the available models with their respective module configurations. - F3BU04-0N base module - F3SP08-0P sequence CPU module with power supply (with M3.5 screws) and memory - F3SP08-SP sequence CPU module with power supply (with M4 screws) and memory - F3WD32-3F I/O module - F3WD64-3F I/O module - F3WD64-3P I/O module - F3WD64-4P I/O module - F3XD16-3F input module - F3YD14-5A output module Should the FA-M3 Value II fail, it can be fixed by replacing the failed module only. Install the F3SP08-xP sequence CPU module in the leftmost slot of the F3BU04-0N base module and the other I/O modules in slot 2 (or slots 2 and 3). The remaining slots 3 and 4 (or only slot 4) are reserved for a variety of I/O modules available for use with the FA-M3 series. A slot number consists of three digits of which the third digit is the unit number. The unit number 0 is allocated to the main unit.Install the F3SP08-0P sequence CPU in slot 1 for the F3SC22-xx, and install the F3SP08-SP sequence CPU module in slot 1 for the F3SC23- xx. Install the other specified component modules in slot 2 (or slots 2 and 3). You may install FA-M3 I/O modules in the remaining slots. You may not install a CPU module in the remaining slots. For restrictions on the installation of I/O modules, including subunits, refer to Section A1.2, “Restrictions on Module Installation,” as they are equivalent to the restrictions specified for the F3SP21-0N module discussed in that section.
公司主营产品图展示
产品优势
1：国外专业的供货渠道，具有价格优势
2：产品质量保证，让您售后无忧
3：全国快递包邮
4：一对一服务
公司主营范围简介
PLC可编程控制器模块，DCS卡件，ESD系统卡件，振动监测系统卡件，汽轮机控制系统模块，燃气发电机备件等，优势品牌：Allen Bradley、BentlyNevada、ABB、Emerson Ovation、Honeywell DCS、Rockwell ICS Triplex、FOXBORO、Schneider PLC、GE Fanuc、Motorola、HIMA、TRICONEX、Prosoft等各种进口工业零部件、欧美进口模块。
产品广泛应用于冶金、石油天然气、玻璃制造业、铝业、石油化工、煤矿、造纸印刷、纺织印染、机械、电子制造、汽车制造、塑胶机械、电力、水利、水处理/环保、锅炉供暖、能源、输配电等等
