产品内容介绍
EMERSON 01984-2347-0021主驱动器控制卡
本章的前几页提供了独立于模块的内容
关于设置节点编号、机械安装和ACS 600连接。模块特定说明（例如I/O和电源连接）。
设置模块节点编号
每个模块必须有一个单独的节点号。节点数字是通过调整位于顶盖下的DIP开关来设置的模块外壳（见左下图）。每个的开关设置模块如下所示。对于允许的NDIO和NAIO节点数字，请参阅驱动器的固件手册。机械安装根据驱动器的不同，模块可以安装在内部或驱动器外壳或机柜外部。请参阅的硬件手册模块放置选项的驱动器。
外部安装
驱动器
选择模块的位置。请注意以下事项：
•布线说明（本章后面针对每个模块给出类型）。此外，光纤电缆的长度选项包中包含的选项可能会限制模块和驱动器。
•遵守模块的自由空间要求（最小10 mm与驱动器（参见驱动器文档）。
•必须考虑环境条件（参见附录B）。
模块的防护等级为IP 20。
•模块接地通过一个接地夹（见下图3-2）。安装导轨要安装的模块必须接地至无声接地。如果轨道没有安装在正确接地的底座上必须使用接地导体。导线必须同样短横截面积必须至少为6 mm2。
注：不得使用实心铜导线（绞合线仅允许）。安装说明：
1.关闭模块外壳中的所有危险电压将安装在中。
2.紧固导轨并确保如上所述正确接地。
3.将模块推到导轨上。模块可以通过以下方式释放用螺丝刀拉动锁定弹簧（见图3-2）。
注意电池的缓慢放电电压电容器组和从外部连接的电压驱动器输入和输出的控制电路。请勿触摸印刷电路板。集成的电路对静电放电极为敏感。
The first few pages of this chapter
provide module-independent instructions on setting the node number, mechanical installation and ACS 600 connection. Module-specific instructions (e.g. on I/O and power connections) are given later in the chapter. Setting the Module Node Number Each module must be given an individual node number. The node number is set by adjusting the DIP switches located under the top lid of the module casing (see picture below left). The switch settings for each module are shown below. For allowable NDIO and NAIO node numbers, see the Firmware Manual of the drive.Mounting instructions: 1. Switch off all dangerous voltages in the enclosure that the module is to be mounted in. 2. Fasten the rail and ensure proper earthing as described above. 3. Push the module onto the rail. The module can be released by pulling the locking spring with a screwdriver (see Figure 3-2).Pay attention to the slowly discharging voltage of the capacitor bank and the voltages that are connected from external control circuits to the inputs and outputs of the drive.Do not touch the printed circuit boards. The integrated circuits are extremely sensitive to electrostatic discharge.
Mechanical Installation
Depending on the drive, the module(s) can be installed either inside or outside the drive housing or cabinet. See the Hardware Manual of the drive for module placement options. Mounting Outside the Drive Choose the location for the module. Note the following: • The cabling instructions (given later in this chapter for each module type) must be followed. Also, the length of the fibre optic cables included in the option package may restrict the distance between the module and the drive. • Observe the free space requirements for the module (min. 10 mm from adjoining equipment or wall) and the drive (see the drive documentation). • The ambient conditions must be taken into account (see Appendix B). The degree of protection of the module is IP 20. • Module earth is connected to the mounting rail by means of an earthing clip (see Figure 3-2 below). The mounting rail onto which the module is to be mounted must be earthed to a noiseless earth. If the rail is not mounted on a properly earthed base, a separate earthing conductor must be used. The conductor must be as short as possible and the cross-sectional area must be 6 mm2 at least. Note: No solid copper conductor may be used (stranded wire allowed only).
