产品内容介绍
SCHENCK AG 018078.07 B6 AVIV700模拟控制卡
•可配置为传输的主从或对等层次结构
与控制器或其他PowerFlex 750系列驱动器之间的数据通过使用另一个20-750-ENETR选项模块或PowerFlex 755驱动器中的嵌入式EtherNet/IP适配器。
•支持“EtherNet/IP网络上的集成运动”操作（Tap仅适用于PowerFlex 755驱动器，固件版本2.003或后来有关设置“EtherNet/IP网络上的Integrated Motion”的详细信息
操作，请参阅EtherNet/IP网络用户上的Integrated Motion手册，出版物MOTION-UM003。
•用户定义的故障操作，以确定选项模块及其
连接的主机驱动器响应以下内容：
–I/O消息通信中断（Comm Flt Action）
–控制器处于空闲模式（空闲飞行动作）
–对等设备通信中断（对等Flt操作）
–通过PCCC、CIP对驱动器控制进行明确的消息传递中断
注册对象或CIP程序集对象（消息Flt操作）
•通过参数的名称或编号访问参数。
•使用Web浏览器查看的网页，显示有关选件模块、其主驱动器以及连接到驱动器的DPI设备。根据所选的操作模式（适配器或抽头），选项模块提供了一组具有不同信息的独特网页。
•配置电子邮件（仅适用于适配器模式）发送至所需地址当选定的驱动器故障发生和/或被清除时，和/或当选项模块执行通信或空闲故障操作。
•访问上的任何PowerFlex驱动器及其连接的外围设备选项模块所连接的网络。
选项模块操作模式选项模块可以在适配器模式（默认）或抽头模式下操作。这个操作模式跳线J4（第19页图1中的项目3）用于选择操作模式。如果缺少跳线，则选项模块在适配器模式。
适配器模式（默认）在适配器模式下
选项模块作为EtherNet/IP网络运行通信模块。凭借EtherNet/IP嵌入式交换机技术和ENET1和ENET2网络端口，选项模块使驱动器能够在线性或设备级环（DLR）网络拓扑中使用。使用星号时网络拓扑，可以使用ENET1或ENET2网络端口。在里面适配器模式，“EtherNet/IP网络上的集成运动”功能不受支持。
轻触模式（仅适用于PowerFlex 755驱动器）在Tap模式下，选项模块的工作方式类似于网关，功能类似至1783-ETAP模块。通过将提供的以太网电缆连接到选项模块的ENET3网络端口和嵌入式EtherNet/IP
PowerFlex 755驱动器上的适配器端口，选项模块启用
PowerFlex 755驱动器将其I/O连接扩展到线性或设备级环（DLR）网络拓扑。这还支持“EtherNet上的集成运动”/用于的PowerFlex 755驱动器支持IP网络的功能这些拓扑。
• Master-Slave or Peer-to-Peer hierarchy
that can be configured to transmit data to and from a controller or another PowerFlex 750-Series drive on the network by using another 20-750-ENETR option module or the embedded EtherNet/IP adapter in a PowerFlex 755 drive. • Supports ‘Integrated Motion on the EtherNet/IP network’ operation (Tap mode only) for only the PowerFlex 755 drive, firmware revision 2.003 or later. For details to set up ‘Integrated Motion on the EtherNet/IP network’ operation, see Integrated Motion on the EtherNet/IP Network User Manual, publication MOTION-UM003. • User-defined fault actions to determine how the option module and its connected host drive respond to the following: – I/O messaging communication disruptions (Comm Flt Action) – Controllers in Idle mode (Idle Flt Action) – Peer device communication disruptions (Peer Flt Action) – Explicit messaging disruptions for drive control via PCCC, the CIP Register Object or the CIP Assembly object (Msg Flt Action) • Accessing parameters by their name or their number. • Web pages, viewed by using a web browser, that show information about the option module, its host drive, and DPI devices connected to the drive. Depending on its selected operating mode (Adapter or Tap), the option module provides a unique set of web pages with different information. • Configured e-mail messaging (Adapter mode only) to desired addresses when selected drive faults occur and/or are cleared, and/or when the option module takes a communication or idle fault action. • Access to any PowerFlex drive and its connected peripherals on the network to which the option module is connected.
Option Module Operating Modes
The option module can be operated in Adapter mode (default) or Tap mode. The Operating Mode Jumper J4 (item 3 in Figure 1 on page 19) is used to select the operating mode. If the jumper is missing, the option module operates in the Adapter mode. Adapter Mode (default) In the Adapter mode, the option module operates as an EtherNet/IP network communication module. With its EtherNet/IP embedded switch technology and ENET1 and ENET2 network ports, the option module enables the drive to be used in a linear or device-level ring (DLR) network topology. When using a star network topology, either the ENET1 or ENET2 network port may be used. In Adapter mode, the ‘Integrated Motion on the EtherNet/IP network’ functionality is not supported. Tap Mode (only with PowerFlex 755 drives) In the Tap mode, the option module operates like a gateway and functions similar to the 1783-ETAP module. By connecting the supplied Ethernet cable between the option module’s ENET3 network port and the embedded EtherNet/IP adapter port on the PowerFlex 755 drive, the option module enables the PowerFlex 755 drive to extend its I/O connection to a linear or device-level ring (DLR) network topology. This also enables ‘Integrated Motion on the EtherNet/ IP network’ functionality supported by the PowerFlex 755 drive to be used with these topologies.
