IBA SM128V工业控制模块
配置示例
重要提示：以下章节仅供示例，旨在帮助用户使用西门子工业以太网设置和配置模块与处理器的通信协议在发出控制操作（写入命令）之前，请确保处理器位于接收这些命令的安全状态。
请确保沟通和控制可以在不对装置和设备造成损坏或伤害的情况下进行操作致人员。
示例1
此示例演示了从ControlLogix传输数据的配置处理器到S7-300处理器。
数据从RSLogix控制器标签传输溶剂同位素效应。通过SIE写入数据[0]。
将数据[4]写入数据块1中的地址0到8西门子处理器，使用INT数据类型。
1将适当的数据复制或移动到控制器标签SIE中。
通过写入数据[0]溶剂同位素效应。RSLogix 5000中的WriteData[4]此示例演示了从S7-300处理器到ControlLogix的数据传输加工机数据从地址0传输至16（MD 0至MD 16）
RSLogix控制器标签SIE。通过SIE读取数据[0]。ReadData[9]，使用REAL数据类型和地址类型标志。
1在Simatic Manager中，键入标志地址MD 0至MD 16。
更改显示格式，方法是右键单击“显示格式”列中的条目并选择从下拉列表中选择FLOATING-POINT。
静态ARP表
静态ARP表定义了模块在以下情况下将使用的静态IP地址列表需要ARP（地址解析协议）。
模块最多可接受40个静态IP/MAC地址数据集。
使用静态ARP表通过指定IP来减少网络流量地址及其关联的MAC（硬件）地址模块将定期与通信。
要点：如果字段中的设备发生更改，则必须更新此表以包含新的MAC地址并下载到模块。
如果MAC未更改，则与将提供模块。
IP地址点符号此表包含当ARP为必修的。
该模块将接受多达40个静态IP/MAC地址数据集。
要点：如果字段中的设备发生更改，则必须更新此表以包含新的MAC地址并下载到模块。
如果MAC未更改，则与模块将发生。
硬件MAC地址十六进制值此表包含模块在ARP时将使用的静态MAC地址列表是必需的。该模块将接受多达40个静态IP/MAC地址数据集。
要点：如果字段中的设备发生更改，则必须更新此表以包含新的MAC地址并下载到模块。如果MAC未更改，则与模块将发生。
Configuration Examples
Important: The following sections are for example purposes only, and are intended to assist a user in setting up and configuring module communications with a processor using Siemens Industrial Ethernet protocol. Before issuing control operations (write commands), please make sure that the processor is in a safe state to receive these commands. PLEASE ENSURE THAT COMMUNICATION AND CONTROL OPERATIONS CAN BE CARRIED OUT WITHOUT DAMAGE TO PLANT AND EQUIPMENT, OR INJURY TO PERSONNEL. Example 1 This example demonstrates configuration for data transfer from a ControlLogix processor to an S7-300 processor. The data is transferred from RSLogix controller tags SIE.WriteData[0] through SIE.WriteData[4] to Data Block 1 addresses 0 through 8 in the Siemens processor, using the INT data type. 1 Copy or move the appropriate data into controller tags SIE.WriteData[0] through SIE.WriteData[4] in RSLogix 5000 This example demonstrates data transfer from an S7-300 processor to a ControlLogix processor. The data is transferred from addresses 0 through 16 (MD 0 through MD 16) to RSLogix controller tags SIE.ReadData[0] through SIE.ReadData[9], using the REAL data type and Address Type Flag. 1 In Simatic Manager, type in Flag addresses MD 0 through MD 16. Change the display format by right-clicking an entry in the Display format column and selecting FLOATING-POINT from the dropdown list.
Static ARP Table
The Static ARP Table defines a list of static IP addresses that the module will use when an ARP (Address Resolution Protocol) is required. The module will accept up to 40 static IP/MAC address data sets. Use the Static ARP table to reduce the amount of network traffic by specifying IP addresses and their associated MAC (hardware) addresses that the MVI56E-SIE module will be communicating with regularly. Important: If the device in the field is changed, this table must be updated to contain the new MAC address for the device and downloaded to the module. If the MAC is not changed, no communications with the module will be provided. IP Address Dotted notation This table contains a list of static IP addresses that the module will use when an ARP is required. The module will accept up to 40 static IP/MAC address data sets. Important: If the device in the field is changed, this table must be updated to contain the new MAC address for the device and downloaded to the module. If the MAC is not changed, no communications with the module will occur. Hardware MAC Address Hex value This table contains a list of static MAC addresses that the module will use when an ARP is required. The module will accept up to 40 static IP/MAC address data sets. Important: If the device in the field is changed, this table must be updated to contain the new MAC address for the device and downloaded to the module. If the MAC is not changed, no communications with the module will occur.
