产品详情介绍
88TV01H-E数字量输出模块
描述3300 XL 8 mm接近传感器系统包括：
一个3300 XL 8 mm探针，
一根3300 XL延长电缆1，和
一个3300 XL前置器*传感器2。
系统提供的输出电压与探头尖端与观察到的导电表面和罐之间的距离测量静态（位置）和动态（振动）值。系统的主要应用是流体膜上的振动和位置测量轴承机，以及Keyphasor*基准和速度测量3。
3300 XL 8 mm系统提供了我们涡流中最先进的性能电流接近传感器系统。标准3300 XL 8 mm 5米该系统还完全符合美国石油学会（API）670机械配置、线性范围、精度和温度稳定性。所有3300 XL 8 mm接近传感器系统提供
这种性能水平和支持探针的完全互换性，延长电缆和前置器传感器，无需匹配或台架校准单个部件。
每个3300 XL 8 mm传感器系统组件向后兼容可与其他非XL 3300系列5 mm和8 mm传感器互换
系统组件5.此兼容性包括3300 5 mm探针，用于8 mm探针对于可用安装来说太大的应用空格6,7。
前置器传感器
3300 XL Proximitor Sensor集成了多项改进以前的设计。它的物理包装允许您在高密度DINrail安装中使用它。您也可以将传感器安装在传统的面板安装中配置，其中它与旧款共享相同的4孔安装“占用空间”
前置器传感器设计。任一选项的安装底座都提供电气隔离，无需单独的隔离器板。3300型XL前置器传感器对射频干扰高度免疫，允许安装在玻璃纤维外壳中，不会受到附近无线电的不利影响频率信号。3300 XL前置器传感器改进的RFI/EMI抗扰度满足欧洲CE标志认证，无需特殊屏蔽导管或金属外壳，从而降低安装成本和复杂性。
3300 XL的SpringLoc端子板不需要特殊的安装工具和通过消除螺丝类型，促进更快、更坚固的现场接线连接可以松开的夹紧机构。
Description
The 3300 XL 8 mm Proximity Transducer System consists of:
One 3300 XL 8 mm probe,
One 3300 XL extension cable1, and
One 3300 XL Proximitor* Sensor2.
The system provides an output voltage that is directly proportional to the
distance between the probe tip and the observed conductive surface and can
measure both static (position) and dynamic (vibration) values. The system’s
primary applications are vibration and position measurements on fluid-film
bearing machines, as well as Keyphasor* reference and speed measurements3.
The 3300 XL 8 mm system delivers the most advanced performance in our eddy
current proximity transducer systems. The standard 3300 XL 8 mm 5-metre
system also fully complies with the American Petroleum Institute’s (API) 670
Standard (4th Edition) for mechanical configuration, linear range, accuracy, and
temperature stability. All 3300 XL 8 mm proximity transducer systems provide
this level of performance and support complete interchangeability of probes,
extension cables, and Proximitor sensors, eliminating the need to match or
bench calibrate individual components.
Each 3300 XL 8 mm Transducer System component is backward-compatible and
interchangeable4 with other non-XL 3300 series 5 mm and 8 mm transducer
system components5. This compatibility includes the 3300 5 mm probe, for
applications in which an 8 mm probe is too large for the available mounting
space6,7.
Proximitor Sensor
The 3300 XL Proximitor Sensor incorporates numerous improvements over
previous designs. Its physical packaging allows you to use it in high-density DINrail installations. You can also mount the sensor in a traditional panel mount
configuration, where it shares an identical 4-hole mounting “footprint” with older
Proximitor Sensor designs. The mounting base for either option provides
electrical isolation and eliminates the need for separate isolator plates. The 3300
XL Proximitor Sensor is highly immune to radio frequency interference, allowing
you to install it in fiberglass housings without adverse effects from nearby radio
frequency signals. The 3300 XL Proximitor Sensor’s improved RFI/EMI immunity
satisfies European CE mark approvals without requiring special shielded conduit
or metallic housings, resulting in lower installation costs and complexity.
The 3300 XL’s SpringLoc terminal strips require no special installation tools and
facilitate faster, more robust field wiring connections by eliminating screw-type
clamping mechanisms that can loosen.
