3HNA024871-001/03 DCS控制模块
伺服驱动模块连接、MAC电机的插头和接线盒分配以及电缆的线路分配
连接如第5.6章的图所示。
第5.3.1章至第5.2.8章中概述的单独指南。
应遵循。
电源连接和控制开关的合适和推荐取决于所使用的电源模块，在相应的供应模块描述中概述。
从提供的附件上拆下以下部件：–用于L+和L-连接的连接电路母线，-端塞X1，
–模拟接口驱动模块上的插入式端子以及马达反馈连接，–低压总线插头X1连接的扁平带总线电缆。这个
总线电缆X1的黑线应位于底部已接通电源。
用于线路监控的端塞，是附件套件的一部分电源模块应插入最后一个模块化单元（单元位于最远的位置）。
线路横截面的选择尺寸应足以避免：
在最大环境温度和应产生相应的电流。（建议见在DIN VDE 0113或EN 60204第1节中。）
电源连接处所有线路的横截面必须扭曲，并且具有足够的尺寸，即：–附加泄放器模块TBM的管线必须扭曲，横截面至少为6mm2（线路长度最大为2m）。
–连接额外TCM容量的线路必须扭曲，横截面至少为10mm2
（见（1），6 mm2，带TVM）（最大线路长度0.5m）。
–相邻驱动模块通常通过中间连接
电路母线，连接附件的一部分。如果这不应该在
在某些情况下是可能的，则连接必须以扭曲方式布置
尽可能短的线路（最大长度1m）。最小横截面为10mm2
在这种情况下足够了（见（1），6 mm2使用TVM）。
“GLD”型中间回路节流阀应连接至使用10mm2双绞线的电源模块。这些应为尽可能短。
The servo drive module connection, the plug and terminal box assignments of the MAC motors and the line assignments of the cable connections are depicted in the figures of Chapter 5.6. The individual guidelines outlined in Chapters 5.3.1 through 5.3.8. should be followed. The mains connection and the control switch approppriate and recommended for it depend upon the supply module used and are, therefore, outlined in the corresponding supply module description. Remove the following from the accessories as supplied: – link-circuit busbar for L+ and L- connections, – end plug X1, – the plug-in terminals on the drive module for the analogue interfaces and the motor feedback connection, as well as, – the flat belt bus cable for the low-tension bus plug X1 connections. The black lines of bus cable X1 should be at the bottom, once everything has been plugged in. The end plug for line monitoring, which is a part of the accessories kit for the supply module, should be plugged into the last modular unit (the unit located farthest away). Line cross-sections should be selected in a size sufficient to avoid any line overloading in the event that maximum ambient temperature and the corresponding currents should occur. (Recommendations can be found in DIN VDE 0113, or EN 60204, Section 1.) The cross-sections of all lines at power connections must be twisted and have a sufficient size, namely: – Lines to additional bleeder module TBM must be twisted with a crosssection of at least 6mm2 (line length max. 2m). – Lines to the additional TCM capacities must be twisted with a crosssection of at least 10mm2 (see (1), 6 mm2 with TVM) (max. line length of 0.5m). – Adjacent drive modules are usually connected via the intermediate circuit busbar, a part of the connecting accessories. If this should not in some cases be possible, then the connection must be laid out in twisted lines which are as short as possible (max length 1m). A minimum crosssection of 10mm2 suffices in this case (see (1), 6 mm2 with the TVM). – Intermediate circuit throttles of the „GLD“ type should be connected to the supply module using twisted lines of 10mm2. These should be as short as possible.
