SAT RM3141-01-02输入电子模块
对于特殊应用，驱动系统的性能可以：通过附加模块（附加泄放器、TBM、附加电容器、CZ或TCM）进一步扩展。有关这些的更多详细信息，请参阅来自电源模块的文档。
各种伺服驱动模块的具体特性，以及下表总结了供应模块：
伺服驱动特性单元
适用于MAC 71至MAC 160的TDM 1标准伺服驱动模块马达
用于MAC 63到MAC 93的TDM 2废弃专用单元马达
用于MAC 63至MAC的TDM 3标准伺服驱动模块112B电机
适用于MAC 21、MAC 25和MAC 41的TDM 4伺服驱动模块电机（内置于驱动模块中的反馈电子设备代替电机用于低噪声应用的TDM 6伺服驱动模块具有温度监视器、制动器和MAC 63至MAC 93电机的启动联锁TDM 7伺服驱动模块，用于低噪声应用和具有温度监视器、制动器和MAC 21、MAC 25和MAC 41的启动联锁电机（内置于驱动模块中的反馈电子设备代替电机）
KDS 1伺服驱动模块采用冷运行技术
对于MAC 90至MAC 160电机（由于内置外部热交换器：在控制柜）。
电源装置，用于连接大约4个平均机械输出的伺服驱动器功率为4.1kW。
TVM 2标准电源装置，用于连接多达平均约6个伺服驱动器机械输出4.1 kW。
TVD 1电源装置，直接连接到3 x 380-460电压电源，内置电源接触器。
采用冷运行技术的KDV 1电源装置（由于外部散热器，在控制柜），用于一个主驱动器和6个伺服驱动器
平均机械输出为28kW。
KDV 2与KDV 1相同，但不需要串联电阻器
用于通电的电源输入。受控制动，尤其是相关异步主驱动的制动可能的工件和刀具可以自由运行。
KDV 3与KDV 2相同，但也为机器提供能量回收负载质量大，加工周期短。
KDV 4与KDV 3相同，但与380直接电源连接-460伏电源和受控链路电路电压。
For special applications the performance of the drive system can be
further extended by additional modules (additional bleeder, TBM, additional capacitors, CZ or TCM). Further details of these can be obtained
from the documentation covering the power supply modules.
The specific characteristics of the various servo drive modules and
supply modules are summarized in the following table:
Servo drive Characteristics
module
TDM 1 Standard servo drive module for MAC 71 to MAC 160
motors
TDM 2 Obsolescent special unit for MAC 63 to MAC 93
motors
TDM 3 Standard servo drive module for MAC 63 to MAC
112B motors
TDM 4 Servo drive module for MAC 21, MAC 25, MAC 41
motors (feedback electronics built into drive module
instead of motor
TDM 6 Servo drive module for low-noise applications and
with interface for temperature monitor, brake and
starting interlock for MAC 63 to MAC 93 motors
TDM 7 Servo drive module for low-noise applications and
with interface for temperature monitor, brake and
starting interlock for MAC 21, MAC 25, MAC 41
motors (feedback electronics built into drive module
instead of motor)
KDS 1 Servo drive module using cold-running technology
for MAC 90 to MAC 160 motors (due to built-on
external heat exchanger no heat losses occur in the
control cabinet).
Power supply unit for connection of up to approximately
4 servo drives of up to an average mechanical output
of 4.1 kW.
TVM 2 Standard power supply unit for connection of up to
approximately 6 servo drives of up to an average
mechanical output of 4.1 kW.
TVD 1 Power supply unit for direct connection to 3 x 380-460
volt mains, with built-in power contactor.
KDV 1 Power supply unit using cold-running technology
(due to external heatsink, no heat losses occur in the
control cabinet) for one main drive and 6 servo drives
with an average mechanical output of 28 kW.
KDV 2 As KDV 1, but no series resistors required in the
mains input for power-up. Controlled braking, especially of an associated asynchronous main drive is
possible. Workpiece and tool can run free.
KDV 3 As KDV 2, but also has energy recovery for machines
with large load masses and short machining cycles.
KDV 4 As KDV 3, but with direct mains connection to 380-
460 volt supplies, and controlled link circuit voltage.
