此示例应用程序用于安装在ControlLogix机架插槽1中的模块。梯形图逻辑使用插槽编号标识模块。如果您正在安装模块位于不同的插槽中，您必须更新梯形图逻辑，以便标签和变量是正确的，不会与机架中的其他模块冲突。更改插槽号
1在控制器组织列表中，选择模块，然后单击右侧鼠标按钮打开快捷菜单。单击自动配置按钮。RSLinx将尝试配置与所选驱动程序一起工作的串行端口。
5当您看到消息“自动配置成功”时，单击“确定”按钮关闭对话框。
注意：如果自动配置程序失败，请确认电缆连接正确在处理器和计算机上的串行端口之间，然后重试。如果你还在无法自动配置端口，请参阅RSLinx文档以了解进一步的疑难解答
步骤。将示例程序下载到处理器注意：ControlLogix处理器前面的键开关必须位于REM或PROG中位置
1如果您尚未与处理器联机，请打开通信菜单，然后选择下载。RSLogix 5000将建立与处理器的通信。您不必通过处理器的串行端口，
如下所示。您可以通过任何可用的网络连接
2通信建立后，RSLogix 5000将打开确认对话框。单击下载按钮将示例程序传输到加工机
RSLogix 5000将编译程序并将其传输到处理器。这过程可能需要几分钟。
下载完成后，RSLogix 5000将打开另一个确认对话框。如果钥匙开关处于REM位置，单击OK（确定）以
将处理器从程序模式切换到运行模式。将电脑连接到模块安全安装模块后，将您的电脑连接到使用RJ45-DB-9串行适配器电缆和零线配置/调试端口
调制解调器电缆。
1如图所示连接两根电缆。
2.将RJ45电缆连接器插入的配置/调试端口单元
3.将另一端连接到电脑的串行端口。
This sample application is for a module installed in Slot 1 in a ControlLogix rack.
The ladder logic uses the slot number to identify the module. If you are installing
the module in a different slot, you must update the ladder logic so that program
tags and variables are correct, and do not conflict with other modules in the rack.
Changing the slot number
1 In the Controller Organization list, select the module and then click the right
mouse button to open a shortcut menu. Click the AUTO-CONFIGURE button. RSLinx will attempt to configure your
serial port to work with the selected driver.
5 When you see the message Auto Configuration Successful, click the OK
button to dismiss the dialog box.
Note: If the auto-configuration procedure fails, verify that the cables are connected correctly
between the processor and the serial port on your computer, and then try again. If you are still
unable to auto-configure the port, refer to your RSLinx documentation for further troubleshooting
steps. Downloading the Sample Program to the Processor
Note: The key switch on the front of the ControlLogix processor must be in the REM or PROG
position.
1 If you are not already online with the processor, open the Communications
menu, and then choose DOWNLOAD. RSLogix 5000 will establish
communication with the processor. You do not have to download through the
processor's serial port, as shown here. You may download through any
available network connection.
2 When communication is established, RSLogix 5000 will open a confirmation
dialog box. Click the DOWNLOAD button to transfer the sample program to the
processor.
RSLogix 5000 will compile the program and transfer it to the processor. This
process may take a few minutes.
4 When the download is complete, RSLogix 5000 will open another
confirmation dialog box. If the key switch is in the REM position, click OK to
switch the processor from PROGRAM mode to RUN mode. Connecting Your PC to the Module
With the module securely mounted, connect your PC to the
Configuration/Debug port using an RJ45-DB-9 Serial Adapter Cable and a Null
Modem Cable.
1 Attach both cables as shown.
2 Insert the RJ45 cable connector into the Configuration/Debug port of the
module.
3 Attach the other end to the serial port on your PC.
