TRICONEX 8111机架
系统要求MVI56-101M模块至少需要以下硬件和软件：组件：罗克韦尔自动化控制™ 处理器，具有兼容电源为MVI56-101M模块提供机架中的一个空闲插槽。模块需要800 mA的可用功率。
罗克韦尔自动化RSLogix 5000编程软件版本2.51或较高的罗克韦尔自动化RSLinx通信软件
奔腾®
II最小450 MHz。奔腾III 733 MHz（或更高）
支持的操作系统：
o带有Service Pack 1或2的Microsoft Windows XP Professional
o带有Service Pack 1、2或3的Microsoft Windows 2000 Professional
o Microsoft Windows Server 2003
最小128 MB内存，建议256 MB内存
100 MB的可用硬盘空间（或更多，取决于应用程序要求）
256色VGA图形适配器，最小分辨率为800 x 600（真彩色1024×768推荐）
ProSoft配置生成器、超级终端或其他终端仿真器
程序注意：您可以将模块安装在本地或远程机架中。对于远程机架安装，模块
需要与处理器进行以太网/IP或ControlNet通信。安装ProSoft Configuration Builder软件
您必须安装ProSoft Configuration Builder（PCB）软件才能进行配置模块。您始终可以获得最新版本的ProSoft配置ProSoft技术网站的建设者。
从ProSoft网站安装ProSoft Configuration Builder
1.打开web浏览器并导航
2.单击此处下载链接下载最新版本的ProSoft配置生成器。
3在提示时选择保存或保存文件。
4将文件保存到Windows桌面，以便在您已完成下载。
5下载完成后，找到并打开文件，然后按照屏幕上安装程序的说明。
System Requirements
The MVI56-101M module requires the following minimum hardware and software
components:
Rockwell Automation ControlLogix™ processor, with compatible power
supply and one free slot in the rack, for the MVI56-101M module. The module
requires 800 mA of available power.
Rockwell Automation RSLogix 5000 programming software version 2.51 or
higher
Rockwell Automation RSLinx communication software
Pentium®
II 450 MHz minimum. Pentium III 733 MHz (or better)
recommended
Supported operating systems:
o Microsoft Windows XP Professional with Service Pack 1 or 2
o Microsoft Windows 2000 Professional with Service Pack 1, 2, or 3
o Microsoft Windows Server 2003
128 Mbytes of RAM minimum, 256 Mbytes of RAM recommended
100 Mbytes of free hard disk space (or more based on application
requirements)
256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color
1024 × 768 recommended)
ProSoft Configuration Builder, HyperTerminal or other terminal emulator
program.
Note: You can install the module in a local or remote rack. For remote rack installation, the module
requires EtherNet/IP or ControlNet communication with the processor. Installing ProSoft Configuration Builder Software
You must install the ProSoft Configuration Builder (PCB) software to configure
the module. You can always get the newest version of ProSoft Configuration
Builder from the ProSoft Technology website.
Installing ProSoft Configuration Builder from the ProSoft website
1 Open your web browser and navigate to http://www.prosofttechnology.com/pcb
2 Click the DOWNLOAD HERE link to download the latest version of ProSoft
Configuration Builder.
3 Choose SAVE or SAVE FILE when prompted.
4 Save the file to your Windows Desktop, so that you can find it easily when
you have finished downloading.
5 When the download is complete, locate and open the file, and then follow the
instructions on your screen to install the program.
