NELES AUTOMATION A413305 AOR4C自动化数控模块
Modbus通信是标准的，后端的一个端口（RS485，半双工）提供网络最多连接32个控制器（例如352P、353、354、354N和Procidia型号™ i|pac™) 给操作员
工作站、人机界面（HMI）或DCS，可将控制器集成到全厂系统中。
一种流行的HMI是Procidia i|工作站™ 在PC上运行i|ware™ 操作员界面软件。通信端口
（RS232）在使用时可用于配置和/或调试i|config™, 可选的基于PC的图形配置实用程序。
可选的I/O扩展板可添加到基础Moore 353。它包括直接热电偶、RTD和用于温度和频率变量的直接过程测量的频率输入和附加I/O，
提高精度和控制。可用的扩展板I/O如下所示。当多回路应用、高级控制或批量排序需要更多I/O时，远程I/O可以安装使用流行LonWorks协议的选项板。LonWorks董事会提供：
通过高速数字现场总线连接到大量标准I/O产品：模拟输入和输出以及使用继电器或固态技术的数字输入和输出。尽管Moore 353可以连接到中央操作员工作站并完全从中央操作员工作站操作，例如
i|站，包括控制器面板。此本地操作员界面适用于需要循环的应用程序
启动、故障排除、维护或紧急情况期间的个人注意事项。方便的面板布局和复杂的软件允许快速、轻松地进行流程和配置更改。
控制器可以从操作员面板完全配置，或者如上所述，配置远程使用i|config™, 可选的基于PC的图形配置实用程序。可选的实时时钟/配置板（RTC/CB）可用于将配置从一个控制器快速传输到另一个控制器
当通过网络下载配置不可用时。RTC/CB还提供实时时钟作用
下表列出了网络通信选项。
协议（选择一个）可用，连接选项板需要Modbus标准后端子，NCA和NCB无
本地仪表链路可选后终端、NCA和NCB LIL通信
以太网可选后面板，RJ-45（需要案例选项4）以太网通信
Modbus通信是标准的。可选的本地仪器链路（LIL）网络板可替代
Modbus通信提供更高速度的联网和之间的点对点通信控制器。这提供了与一系列支持网络的产品的连接，包括下面列出的产品。
当前控制器模型以前的控制器模型Procidia i|pac互联网控制系统
Moore 352P单回路数字控制器
352型单回路数字控制器
351型三环数字控制器
摩尔354/354N通用控制器
382型逻辑和顺序控制器
可选的以太网板可替代Modbus和LIL通信。此选项启用Moore 353控制器、Procidia i|pac控制器和许多其他具有以下功能的设备之间的对等通信
以太网（嵌入式Modbus RTU协议）。以太网通信需要以太网板和控制器
固件V2.4或更高版本。
Modbus communication is standard and a port (RS485, half-duplex) at the rear terminals provides for network
connection of up to 32 controllers (e.g. Models 352P, 353, 354, 354N, and Procidia™ i|pac™) to an operator
workstation, Human/Machine Interface (HMI), or DCS, enabling integration of controllers into a plant-wide system.
A popular HMI is the Procidia i|station™ running i|ware PC™ operator interface software. A communication port
(RS232) on the underside of the Display Assembly is available for configuration and/or debugging when using
i|config™, the optional PC-based Graphical Configuration Utility.
An optional I/O Expander Board can be added to the base Moore 353. It includes direct thermocouple, RTD, and
frequency inputs and additional I/O for direct process measurement of temperature and frequency variables,
improving accuracy and control. Available Expander board I/O is listed below. When even more I/O is needed for multiple-loop applications, advanced control, or batch sequencing, a remote I/O
option board that uses the popular LonWorks protocol can be installed. This LonWorks board provides
connectivity via a high-speed digital fieldbus to a large selection of standard I/O products: analog inputs and outputs
and digital inputs and outputs using relay or solid state technology.
Although the Moore 353 can be connected to and operated entirely from a central operator workstation, such as
i|station, a controller faceplate is included. This local operator interface is for applications where loops need
individual attention during startup, troubleshooting, maintenance, or emergency conditions. The convenient
faceplate layout and sophisticated software allow process and configuration changes to be made quickly and easily.
The controller can be completely configured from the operator faceplate or, as mentioned above, configured
remotely using i|config™, the optional PC-based Graphical Configuration Utility. An optional Real Time
Clock/Configuration Board (RTC/CB) is available to quickly transfer a configuration from one controller to another
when downloading a configuration over a network is not available. The RTC/CB also provides a real time clock
function.
Network communication options are listed in the following table.
Protocol (Select One) Available Connection Option Board Needed
Modbus Standard Rear Terminals, NCA and NCB None
Local Instrument Link Optional Rear Terminals, NCA and NCB LIL Communication
Ethernet Optional Rear Panel, RJ-45 (requires case option 4) Ethernet Communications
Modbus communication is standard. An optional Local Instrument Link (LIL) network board is available in place of
the Modbus communication to provide higher speed networking and peer-to-peer communication between
controllers. This provides connectivity with an array of network-enabled products, including those listed below.
Current Controller Models Previous Controller Models
Procidia i|pac Internet Control System
Moore 352P Single-Loop Digital Controller
Model 352 Single-Loop Digital Controller
Model 351 Triple-Loop Digital Controller
Moore 354/354N Universal Controllers
Model 382 Logic and Sequence Controller
An optional Ethernet board is available in place of Modbus and LIL communication. This option enables peer-topeer communication between Moore 353 controllers, Procidia i|pac controllers, and many other devices that feature
Ethernet (embedded Modbus RTU protocol). Ethernet communications requires an Ethernet board and controller
firmware V2.4 or higher.
