NELES AUTOMATION A413295 AIR8C自动化控制模块
本用户手册包含以下各项的配置、安装和服务信息：摩尔353 过程自动化控制器。它分为十五个部分。
•第1节，导言，包含了关于本组织的一般信息手册、控制器、产品支持和典型装运的内容。
•第2节，配置概述，包含功能块列表可用于配置控制器和以下步骤：配置功能块可用性取决于控制器模型和MPU控制器板固件版本。
•第3节“功能块”包含每个功能的详细说明块
•第4节，工厂配置选项，提供了FCO中使用的功能块的图形表示以及对默认功能块参数所做更改的列表。
•第5节“LonWorks通信”概述了LonWorks®通信。
•第6节“网络通信”概述了Modbus、LIL和以太网通信数据。
•第7节，数据映射，包含Modbus、本地仪表链路（LIL）和以太网。
•第8节“安装”包含详细说明机械和电气安装的图纸和步骤。与电有关的
确定了与控制器的连接，并包括了许多接线图。
•第9节“本地面板操作”描述并说明了显示组件的操作员控制和显示。描述了在线操作、配置和自动调谐的使用。
控制器和系统测试，有测试控制器和安装的程序。
•第11节“维护”列出了维护控制器的工具和测试设备。它还具有预防性维护和维修程序，包括错误代码。包括以下组件更换步骤：
详细的跳线选择标准和跳线设置步骤。
•第12节“校准”提供了模拟输入和输出电路校准的分步程序。
•第13节“电路描述”提供了控制器电路的框图级描述。
•第14节，型号名称和规格，显示了控制器型号；附件清单；
机械、电气和环境规范；以及当前机构批准的列表。
•第15节，缩写和首字母缩略词，是新用户的方便参考，解释了许多
本手册中出现的缩写和首字母缩略词。
重要的保存此用户手册。它应该可用于那些安装、配置、维护和维护的人员，
操作和维护控制器。产品描述
Moore 353为控制系统设计者提供了实现以下功能的终极灵活性和能力：
连续溶液和分批溶液。控制器的分解图如图1-1所示。
在摩尔353的核心是一个强大的MPU控制器板，使用最新的微处理器
技术它包括板载I/O和可重用功能块，能够解决大量
控制实现包括单回路、级联和双回路。中列出了可用的MPU板I/O下表。
This User’s Manual contains configuration, installation and service information for
the Moore 353 Process Automation Controller. It is divided into fifteen sections.
• Section 1, Introduction, has general information about the organization of this
manual, the controller, product support, and the contents of a typical shipment.
• Section 2, Configuration Overview, contains a list of the functions blocks
available for use in configuring the controller and a procedure for
configuration. Function block availability depends on controller model and
MPU Controller board firmware version.
• Section 3, Function Blocks, contains a detailed description of each function
block.
• Section 4, Factory Configured Options, provides a graphical presentation of the function blocks used in FCOs
and a listing of changes made to default function block parameters.
• Section 5, LonWorks Communications, provides an overview of LonWorks® communication.
• Section 6, Network Communications, furnishes overviews of Modbus, LIL, and Ethernet communication data.
• Section 7, Data Mapping, contains network data details for Modbus, Local Instrument Link (LIL), and
Ethernet.
• Section 8, Installation, contains drawings and steps detailing mechanical and electrical installation. Electrical
connections to the controller are identified and numerous wiring diagrams are included.
• Section 9, Local Faceplate Operation, describes and illustrates the Display Assembly’s operator controls and
displays. Use of these for on-line operation, for configurations and for autotuning is described.
• Section 10, Controller and System Test, has procedures for testing the controller and the installation.
• Section 11, Maintenance, lists the tools and test equipment to service a controller. It also has preventive
maintenance and servicing procedures, including error codes. Assembly replacement steps are included as are
detailed jumper selection criteria and jumper setting steps.
• Section 12, Calibration, provides step-by-step procedures for calibration of analog input and output circuits.
• Section 13, Circuit Description, furnishes a block diagram level description of the controller’s circuits.
• Section 14, Model Designation and Specifications, shows controller model numbers; a list of accessories;
mechanical, electrical, and environmental specifications; and a list of current agency approvals.
• Section 15, Abbreviations and Acronyms, is a convenient reference for new users that explains many
abbreviations and acronyms appearing in this manual.
IMPORTANT
Save this User’s Manual. It should be available to those installing, configuring,
operating, and servicing the controller. PRODUCT DESCRIPTION
The Moore 353 offers the control system designer the ultimate in flexibility and capability for the implementation of
continuous solutions and batch solutions. An exploded view of the controller appears in Figure 1-1.
At the heart of the Moore 353 is a powerful MPU Controller board that uses the latest in microprocessor
technology. It includes on-board I/O and reusable function blocks, and it is capable of solving a vast array of
control implementations including single loop, cascade, and dual loop. Available MPU board I/O is listed in the
table below.
