未校准将显示未校准的消息
对于从未使用过的新通道卡：校准。
应校准通道卡，并检查其操作。
78校准过期将显示校准过期信息
当预先配置的校准间隔已过期。
这是一条警告信息，表明传感器：
应进行校准。一旦校准
已完成。消息将清除
如果需要，可以禁用此功能使用工程接口软件配置程序。
77零信号过低
显示零信号过低信息
校准期间，当传感器为零时信号低于预先配置的电平，并且无法实现零校准。
对于催化传感器，这通常是：表明两者之间存在很大的不平衡传感器的两个检测元件。
应检查传感器的安装情况导线松动或更换传感器。
对于mA传感器，这通常意味着：传感器的mA输出需要：校准。
76零信号过高零信号过高信息为：当传感器校准时显示
零信号高于预先配置的电平并且不能实现零校准。
这是检测其目标气体和零气体应适用于：传感器。或者对于催化传感器，
这通常意味着存在较大的二者检测不平衡
传感器的元件
传感器应检查安装是否有松动的电线或者更换传感器。
对于mA传感器，这通常意味着：
传感器的mA输出需要：校准。
75校准信号过低
校准信号过低信息为：当传感器校准时显示量程信号低于预配置值
液位和量程校准不能实现。这表明由于以下原因之一，传感器过低：
a、 可能中毒的传感器故障或损坏。
b、 校准气体不正确。检查校准气瓶证书和年龄
c、 粘性气体，如氯或氨没有到达传感器。
Uncalibrated
The uncalibrated message is displayed
for new channel cards that have never been
calibrated.
The channel card should be calibrated and
its operation checked.
78 Calibration Overdue
The calibration overdue message is displayed
when the pre-configured calibration interval
has expired.
This is a warning message that the sensor
is due for calibration. Once the calibration
has been completed the message will clear
If required, this function can be disabled
using the Engineering Interface Software
configuration program.
77 Zero Signal Too Low
The zero signal too low message is displayed
during calibration when the sensor zero
signal is below the pre-configured levels and
a zero calibration can not be achieved.
For catalytic sensors this would typically
signify there is a large imbalance between
the two detecting elements of the sensor.
The sensor installation should be checked
for loose wires or the sensor replaced.
For mA sensors this would typically signify
that the mA output from the sensor requires
calibrating.
76 Zero Signal Too High
The zero signal too high message is
displayed during calibration when the sensor
zero signal is above the pre-configured levels
and a zero calibration can not be achieved.
This is typical of the sensor detecting its
target gas and zero gas should be applied to
the sensor. Alternatively, for catalytic sensors,
this would typically signify there is a large
imbalance between the two detecting
elements of the sensor. The sensor
installation should be checked for loose wires
or the sensor replaced.
For mA sensors this would typically signify
that the mA output from the sensor requires
calibrating.
75 Calibration Signal Too Low
The calibration signal too low message is
displayed during calibration when the sensor
span signal is below the pre-configured
levels and a span calibration can not be
achieved.This indicates that the output from the
sensor is too low due to either:
a. a faulty sensor which may be poisoned
or damaged.
b. the calibration gas is incorrect. Check
the calibration gas bottle certificate and
age.
c. sticky gas such as chlorine or
ammonia is not reaching the sensor.
