The rack clock is located in the Engineering Card, however since the
Engineering Card has no display, a control card must be selected to
enable the time and date to be displayed. It does not matter which
control card is selected.
If the Engineering Key is fitted to the Engineering Card, the time and date
can be adjusted.
3.3.14 INHIBIT Push-button
When the INHIBIT push-button is operated, the selected control card is
placed in the inhibit mode. This prevents the operation of any configured
relay output alarm functions.
Inhibit can only be used if the Engineering Key is fitted to the Engineering
Card, however, if the Engineering Key is subsequently removed the
selected control card remains in the inhibit mode.
3.3.15 Engineering Serial Port
The Engineering Serial Port is a miniature DIN socket which provides
three functions:
a. Connection point for the Engineering Key to unlock the engineers
functions.
b. Connection point for the External Engineering Interface which allows
each control card to be configured by an external PC running the
configuration software.
c. Connection point for a serial printer which can be used to provide a
hard copy of the control card configuration data and status.
The Engineering Serial Port and its Engineering Key are shown below:For installations in the EU, refer to EN60079-14:1997, ‘Electrical
Installations in Hazardous Areas (other than mines).
Additionally, the code of practice regarding Selection, installation,
use and maintenance of apparatus for the detection and
measurement of combustible gases or oxygen must be complied
with. Refer to EN 50073.
The above standards apply to the System 57 since the SENSORS
may be installed in potentially hazardous atmospheres.
In addition, appropriate local or national regulations shall be
used.”
IMPORTANT NOTICES
1. Zellweger Analytics Limited can take no responsibility for
installation and/or use of its equipment if this is not done in
accordance with the appropriate issue and/or amendment of
the manual.
2. The user of this manual should ensure that it is appropriate in
all details to the exact equipment to be installed and/or operated.
If in doubt, the user should contact Zellweger Analytics Limited
for advice.
3. The System 57 cards contain no user serviceable parts. Refer
all servicing to qualified service personnel.
4. When inserting or removing system components ensure that
the power is switched off. Failure to do this may result in
damage to the system.
