5701系列控制系统是System 57系列的一部分
设计用于监控现场安装的工业气体探测器。校长
该系统的特点是：
*使用3U卡格式，在标准19英寸子框中提供多达16个气体检测通道。
*使用3U卡格式，在半个19英寸的子框中提供多达8个气体检测通道。
机架可用于前后访问现场布线。
*2.5mm2以下电线的简单现场连接
*高完整性系统的单通道操作模式。*通道控制卡是可拆卸的，不会干扰其他布线。
*催化桥或4-20mA输入。
*可选报警转换继电器输出。
*主报警、分区报警和表决报警的多报警模式。
