EMC Compliance
The MVME2700 is a board-level product and is meant to be used in
standard VME applications. As such, it is the responsibility of system
integrators to meet the regulatory guidelines pertaining to a given
application. The MVME2700 has been tested in a representative chassis
for CE class B EMC certification. Compliance was achieved under the
following conditions:
❏ Shielded cables on all external I/O ports.
❏ Cable shields connected to earth ground via metal shell connectors
bonded to a conductive module front panel.
❏ Conductive chassis rails connected to earth ground. This provides
the path for connecting shields to earth ground.
❏ Front panel screws properly tightened.
For minimum RF emissions, it is essential that the conditions above be
implemented. Failure to do so could compromise the EMC compliance of
the equipment containing the module.Introduction
As described in previous chapters of this manual, the MVME2700 serial
communications interface has four ports. Two of them are combined
synchronous/asynchronous ports; the other two are asynchronous only.
Both synchronous and asynchronous ports supply an EIA-232-D
DCE/DTE interface via P2 and the MVME712M transition module.
Asynchronous Serial Ports
The MVME2700 uses a PC87308 ISASIO chip from National
Semiconductor to implement the two asynchronous serial ports (in
addition to the disk drive controller, parallel I/O, and keyboard/mouse
interface).
The asynchronous ports provided by the ISASIO device are routed through
P2 and the associated transition module. The TTL-level signals from the
ISASIO chip are buffered through TTL drivers and series resistors, then
routed through EIA-232-D drivers and receivers to complete the
asynchronous serial interface enroute to the MVME712M transition
module.
The MVME2700 hardware supports asynchronous serial baud rates of
110B/s to 38.4Kb/s. For detailed programming information, refer to the
PCI and ISA bus discussions in the MVME2600/2700 Series Single Board
Computer Programmer’s Reference Guide and to the vendor
documentation for the ISASIO device (listed in Appendix D, Related
